- Page 1 Model: DHM-30A Ultrasonic Electronic Height and Weight Body Scale USER MANUAL Installation and Adjustment THANKS FOR USING OUR HEALTHCARE PRODUCTS...
- Page 2 I. Installation instruction Installation Diagram Height Sensor Box M6 Bolt Weight Sensor Socket Figure 1 Figure 2 Figure 3 Figure 4 Whole Structure Diagram ①② ③ ④ ⑤ ⑤ ⑤ Power Switch RS-232 Plug Plug for 12 Volt power supply Power Adapter Foot Margin Bolt 1.
- Page 3 II. Operation Instruction 1. Turn on the machine: Connect the power wire well; turn on the power switch which is at the back of the machine body to make machine self-checking: Measure: The machine can automatically measure as long as a person stands on the saddle. (if have coin acceptor, people make measurement after inputting the setting number of coins.) 3.Display: Standby...
- Page 4 1. Date adjustment: Press into the state of adjustment. Write down Date and Time into(Input Box). Press Enter to save the adjustment results and exit. Press Cancel do not save the adjustment results and exit. 2.Weight adjustment： Press into the state of adjustment. Please follow the instruction of display to adjust weight.
- Page 5 Press Enter to save the adjustment results and exit. Press Cancel do not save the adjustment results and exit. 5.Print adjustment： Press into the state of adjustment. Press the print result you want. Press Enter to save the adjustment results and exit. Press Cancel do not save the adjustment results and exit.
- Page 6 Press “Print” button to print the measurement count. Press Enter to save the adjustment results and exit. Press Cancel do not save the adjustment results and exit. 9. Language setting： Press into the state of adjustment. Select the Language you need. Press Enter to save the adjustment results and exit.
