Music Surround - Lexicon CP-3 Plus Supplementary Manual

PLUS
CP-3 Theory
and Design

Music Surround

14
The Music Surround mode in the CP-3
conventional stereo music through any system which includes side or side-
located rear speakers.
Conventional stereo generally relies on the acoustics of the playback room
to regenerate the important side, or lateral, energy which is present in nearly
all music performance spaces. Speakers which are arranged for film view-
ing, however, often have the front loudspeakers too close together for
optimal reproduction of the spaciousness of the original soundfield. With
the CP-3 , additional speakers located near the sides of the listeners can
PLUS
add to the playback spaciousness. In the Reverb and Ambience modes, the
CP-3 PLUS calculates and generates the ambient sound from a larger room and
presents this sound through the additional speakers. This works well, but
the ambience is generated by the processor — not contained in the recording.
In the Surround modes, surround channel information is extracted from
signals encoded on the recording by the sound mixer — the CP-3
not add anything to the sound.
On films, this surround information is intended to be reproduced in
monaural from an array of speakers all around the rear of the listener.
Unless there is enough energy accidentally encoded into the surround
channel to give significant sideways energy, surround speakers won't
contribute very much to the listening experience of ordinary stereo music.
In addition, with all speakers except the fronts reproducing the same
monaural signal, no directional effects are possible. There may be some
sense of the music coming from all around you, but the violins and cellos are
equally loud from both sides.
Music Surround solves this problem in a novel way. The side speakers
reproduce the left and right front loudspeaker signals with two additions:
delay and inverse steering.
The delay serves a simple purpose. Sounds are kept from being localized to
the sides by an approximately 20ms delay inserted between the front and
side speakers. The center speaker is steered, and can be delayed relative to
the fronts. The center delay allows the center speaker to appear to be at
exactly the same distance from the listener as the front speakers, even if it
is placed (as usual) on a line between the front speakers.
Inverse steering acts to remove a strongly steered signal from certain
directions. As an example, assume you have a strong signal in the left
channel of a film. With normal steering the processor enhances the level of
that signal in the left speaker, and actively removes it from the other
speakers. Inverse steering actively removes this signal from the left side
speaker, while keeping its level strong in the left front speaker. This signal
removal is done cleverly, so the level of any unsteered signal which might
be present at the same time (such as music in a film, or the rest of the
orchestra in a music recording) is not significantly reduced. The sonic result
is a much wider soundstage and a very spacious sound. When music is
played, any loud instrument or sound effect is reproduced from the front
speakers, not distractingly located off to the side.
PLUS is designed to optimally play
Lexicon
does
PLUS
