Related Manuals for Electrolux WH6-6
Summary of Contents for Electrolux WH6-6
- Page 1 User manual Washer extractor WH6–6 Type W.55H.. 438917890/EN Original instructions 2022.08.09...
-
Page 3: Table Of Contents
Contents Contents 1 Safety Precautions ..........................5 General safety information......................6 Commercial use only........................6 Ergonomics certification ......................6 Symbols............................6 2 Warranty terms and exclusions......................7 3 Program description ..........................8 General.............................8 Program description ........................8 Option buttons .........................10 4 Handling ............................11 Load ............................11 Detergent ..........................11 How to start the machine ...................... -
Page 5: Safety Precautions
User manual 1 Safety Precautions • Servicing shall be carried out only by authorized personnel. • Only authorized spare parts, accessories and consumables shall be used. • Only use detergent intended for water-wash of textiles. Never use dry cleaning agents. •... -
Page 6: General Safety Information
User manual person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. – This appliance is intended to be used in household and similar applications such as: (IEC 60335-2-7) staff kitchen areas in shops, offices and other working environments, farm houses, by clients in hotels, motels and other residential type environments, bed and breakfast type environments, areas for communal use in blocks of flats or in launderettes. -
Page 7: Warranty Terms And Exclusions
Warranty will be applicable where the customer has used only genuine spare parts and has performed maintenance in accordance with Electrolux Professional user and maintenance documentation made available in paper or elec- tronic format. Electrolux Professional strongly recommends using Electrolux Professional approved cleaning, rinse and descaling agents to obtain optimal results and maintain product efficiency over time. -
Page 8: Program Description
— different segments use different programs. The following program description is a short description of some exam- ples of programs that can be used. For a complete and detailed information about all the available wash programs, please refer to Electrolux Professio- nal web-site. - Page 9 User manual The following table shows some examples of different groups of programs that are used for special markets such as hospitals, restaurants, farms etc. and a short description of those: Group of program Description General Programs for normal household textiles and textiles in hotels and restaurants. Programs for mops.
-
Page 10: Option Buttons
User manual 3.3 Option buttons The machine is equipped with a number of options adapted to the range of use to which the machine is intended — different markets use different options. The following table shows some examples of available options and a short description of those: Option button Description Washes using less water and energy. -
Page 11: Handling
User manual 4 Handling 4.1 Load Load the goods into the machine according to recommendations and close the door. The recommended maximum load is 6 kg. 4.2 Detergent Add the correct amount of detergent and softener according to recommendations. (Not valid if automatic detergent dosing is used). fig.X00963 Softener, liquid. -
Page 12: Ahl And General
User manual 4.3.1 AHL and General Select program by turning the control knob. It is also possible to select one of the wash triangle options and/or other options. Note! Some programs do not allow options. Example of programs Wash triangle options Example of other options NORMAL COLOUR PREWASH... -
Page 13: Mop
User manual 4.3.2 Select program by turning the control knob or select program with the quick selection buttons (if some of the buttons are programmed with this function). It is also possible to select options (if some of the buttons are programmed with this function). Note! Some programs do not allow options. - Page 14 User manual Buttons The buttons 1 and 2 on the panel can be programmed to be option buttons, quick selection buttons (used to select a program) or both. The buttons 3–6 on the panel are always used as option buttons and can not be changed. At delivery the buttons are programmed to work as options buttons.
-
Page 15: Hygiene
User manual 4.3.3 Hygiene Select program by turning the control knob or select program with the quick selection buttons (if some of the buttons are programmed with this function). It is also possible to select options (if some of the buttons are programmed with this function). Note! Some programs do not allow options. -
Page 16: Restaurant
User manual 4.3.4 Restaurant Select program by turning the control knob or select program with the quick selection buttons. Example of programs MICROFIBRE 90 WHITE Different temperatures can be selected. 60°C - 95°C. DELICATE 30 Start the machine by pressing the control knob. Buttons The buttons 1–6 on the panel are programmed to be quick selection buttons (used to select a program). -
Page 17: Camping
User manual 4.3.5 Camping Select program by turning the control knob or select program with the quick selection buttons. Example of programs NORMAL Different temperatures can be selected. 30°C - 95°C. MILD 40 DELICATE 30 Start the machine by pressing the control knob. Buttons The buttons 1–6 on the panel are programmed to be quick selection buttons (used to select a program). -
Page 18: Coin Operated Machines
User manual 4.3.6 Coin operated machines Select program by turning the control knob. It is also possible to select options. Note! Some programs do not allow options. Example of programs Options COLD HEAVY SOIL WARM EXTRA RINSE Insert correct amount of coins to start the machine. (On some machines you also need to press the control knob to start the machine). -
Page 19: Additional Functions
User manual 4.4 Additional functions There is a menu with additional functions available for selection after start. When pressing the control knob / start but- ton (on machines without control knob) the menu will appear on the display. Select from the menu by turning the control knob / pressing the temperature button/-s and press the control knob / start button to activate. -
Page 20: When Program Has Ended
User manual Auto restarts Select AUTO RESTARTS and activate. Set the number of automatic restarts that the machine will perform of the selected program. Press the control knob / start button to confirm the settings. 4.5 When program has ended Leave the door open when ready and do not close the detergent container all the way in (it shall be a bit open). -
Page 21: Timer
User manual 5 Timer The timer is used to start a part of the program (for example the last rinse of the udder cloth program) after pause on a pre-set time. The time can be set for all days or for selected days. To program the timer you need to activate the machines service mode. -
Page 22: Error Codes
User manual 6 Error codes A fault in the program or in the machine is indicated by an error code on the display. Some of these error codes can be solved easily without contacting service personnel. Error Text Cause/Action code 11:1 NO WATER Water level acknowledgement not reached in time. -
Page 23: Maintenance
User manual 7 Maintenance 7.1 General It is the responsibility of the owner of the machine/the laundry manager to make sure that maintenance is periodically performed. Note! Lack of maintenance may deteriorate the performance of the machine and may cause damage to components. -
Page 24: Detergent Container
User manual 7.4 Detergent container Clean the detergent container at regular basis to avoid that it is being clogged by detergent residue. Remove the detergent container from the machine. Remove the siphons (A) and clean the detergent container and siphons with hot water and for example a small brush. Also clean the plastic parts in the space where the detergent container was placed in the machine. -
Page 25: Drain
User manual 7.5 Drain If the machine is equipped with a drain pump, check the drain pump at regular basis. Clean if necessary. Open the door to the drain pump and pull out the hose. Remove the plug (A) to empty the drain into for example a baking plate or similar. -
Page 26: Water Inlet
User manual At regular basis, check the drain connection, joints in the drain pipe etc and remove any lint and dust. Clean with for example a small brush. When remounting, make sure the connections are tight. 7.6 Water inlet At regular basis, check the filter at the water inlet. Clean if necessary. Demount the hose to the water inlet and pull out the filter (A). -
Page 27: Disposal Information
User manual 8 Disposal information 8.1 Disposal of appliance at end of life Before disposing of the machine, make sure to carefully check its physical condition, and in particular any parts of the structure that can give or break during scrapping. The machine’s parts must be disposed of in a differentiated way, according to their different characteristics (e.g. - Page 28 Electrolux Professional AB 341 80 Ljungby, Sweden www.electroluxprofessional.com...
