IGM Vega FD 330-4-1 User Manual

Flame detector

Advertisement

Quick Links

«IGM-Detector» Co Ltd
Address: 27 Engels Prospect,
building 5, litera A
Saint-Petersburg
194156, Russia,
Tel: 8 (800) 234-66-90
Website: www.igm-pribor.com
E-mail: support@igm-pribor.ru
Flame detector
FD 330-4-1 «Vega»
User manual
MRBP.425241.001-01 UM
2022
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vega FD 330-4-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for IGM Vega FD 330-4-1

  • Page 1 «IGM-Detector» Co Ltd Address: 27 Engels Prospect, building 5, litera A Saint-Petersburg 194156, Russia, Tel: 8 (800) 234-66-90 Website: www.igm-pribor.com E-mail: support@igm-pribor.ru Flame detector FD 330-4-1 «Vega» User manual MRBP.425241.001-01 UM 2022...
  • Page 2: Table Of Contents

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» Contents Page Introduction ..........................3 Intended use ..........................3 Technical specifications ....................... 4 Contents of delivery ....................... 6 Configuration and operation ....................7 Appearance .......................... 7 Overall dimensions ......................8 Construction ........................8 Principle of operation ......................
  • Page 3: Introduction

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» 1. Introduction This user manual (UM) is intended to describe design, principle of operation and operating routine of flame detectors «Vega» 330-4-1 (hereinafter FD 330-4-1 «Vega»). The UM contains basic technical data, guidelines for connection, maintenance service, as well as other information, necessary for the correct operation, storage and repair of flame detectors «Vega».
  • Page 4: Technical Specifications

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» 3. Technical specifications Housing material - Aluminium - Marine grade stainless 1 Ex d IIC T6…Т4 Gb Х; Ex tb IIIC T85°C EX-marking …135°C Db Х Sign Х, following the ex-marking, means that while mounting a detector you should use a cable gland and a plug, certified according to TR CU and having a marking according to...
  • Page 5 MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» Shelf life and conservation of detectors 10 years in the manufacturer's packaging Warranty storage period 6 months since manufacturing Warranty life - 18 months from the day of commissioning; more than months since manufacturing.
  • Page 6: Contents Of Delivery

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» 4. Contents of delivery Package includes: Name Identification Number FD 330-4-1 «VEGA» Flame detector User manual MRBP.425241.001-01UM 1 in a set Datasheet MRBP.425241.001-01 DS Approval documentation 1 package in a set, (certificates delivered –...
  • Page 7: Configuration And Operation

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» 5. Configuration and operation 5.1 Appearance Figure 1 – FD 330-4-1 «VEGA» appearance...
  • Page 8: Overall Dimensions

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» 5.2 Overall dimensions Figure 2 - Overall dimensions of the detector with a mounting bracket 5.3 Construction The detector housing is a flameproof enclosure, inside which all detector devices are located, including sensitive elements that convert the electromagnetic radiation of the flame into an electrical signal, electronic amplifiers and filters, digital-to-analog converters, a microprocessor, display elements, optical elements for checking the operability of channels.
  • Page 9 MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» Notice: It is not recommended to operate FD 330-4-1 «VEGA» in places where combined disturbance may occur (welding + radio station 5 W 100 MHz, welding + device vibration with an acceleration > 10 It is not recommended to use radio station in a distance less than 1 m away from FD 330-4-1 «VEGA»...
  • Page 10: Safety Precautions

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» 6. Safety precautions Any person who is familiar with the configuration, has studied this UM, has been briefed on safety precautions when working with electrical installations and have an electrical safety qualification group of at least III, including in hazardous areas, is admitted to operate the flame detector.
  • Page 11: Mounting

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» 7. Mounting 7.1 Mounting location For the correct mounting of the detector, the following factors must be taken into account:  The location of the detectors must ensure unobstructed control of the entire protected area;...
  • Page 12: Preparation

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega»  Availability of a sufficient number of detectors to protect the controlled area;  The detector must be mounted on a rigid surface that is not subject to vibrations;  The detector must be easily accessible for periodic maintenance service; ...
  • Page 13: Detector Connection

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» 8. Detector connection 8.1 Power source requirements Before connection it is necessary to: - Calculate the total power consumption rate of the gas detection system in watts, taking into account cold start. - Select a power source with the appropriate power for the calculated load.
  • Page 14: Connection Diagrams

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» 4. It is recommended to connect the detectors in a branch line from the main interface line. Branches should be formed by installing repeater-splitters with galvanic isolation of the type at the nodal points of the line. Each branch must serve a separate tank. Extension of the main line beyond 1200 m must be carried out by inserting an interface repeater into the line.
  • Page 15 MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» Figure 5 – Connection diagram for an ultra-explosion-proof detector EEx de. Figure 6 – Connection diagram for a detector with uninsulated output 4-20 mA...
  • Page 16 MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» Figure 7 – Connection diagram for an explosion-proof detector ЕЕх via RS-485 interface Figure 8 – Connection diagram for two explosion-proof detectors EEx via RS-485 interface...
  • Page 17 MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» Terminal box Figure 9 – Connection diagram for two detectors and a digital channel RS-485 via terminal...
  • Page 18: Commissioning

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» Notice: 250 Ohm is necessary to ensure the correct operation of the HART interface, in case of 4-20 mA controller low resistance, it is not necessary to install resistance at the FD 330-4-1 «VEGA»...
  • Page 19: Output Signals And Led Indicators Description

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» 3.OPEN THE DETECTORS IN A HAZARDOUS AREA WITH POWER ON Detector’s housing must be grounded. Output signal and LED indicators description FD 330-4-1 «VEGA» generates the following output signals: - analogue signal with the following meanings: a) (2 ±...
  • Page 20 MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» It is possible to change the sensitivity and signal processing time to reduce the effect of interference when identifying a fire or a nearby location of the alleged fire site («far/near» and «fast/slow»...
  • Page 21: Functionality Check

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» 9.1 Functionality check After the equipment mounting and wiring it is necessary to perform FD 330-4-1 «VEGA» functionality check. In addition, this check should be carried out regularly at intervals of once every 6 months during maintenance. 9.1.1 Manual mode To check the detector’s functionality by the method of illumination, a special test radiation source is used.
  • Page 22: Automatic Mode

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» For switching, it is necessary to: - put the magnet to the recess on the detector (see figure 12) (a click will be heard), - turn off the power for 5 seconds, - turn on the power and remove the magnet in 5-10 seconds.
  • Page 23: Factory Default

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» 9.2 Factory default Table 2 № Operation Description Factory Notice mode default «Far – Far 25 meters Switching using the service near» Near 15 meters program «Fast-slow» Fast – standard mode Slow In the slow mode, high noise Slow –...
  • Page 24: Maintenance Service

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» 10. Maintenance service Maintenance service includes: FD 330-4-1 «VEGA» visual inspection; FD 330-4-1 «VEGA» clearing; Grounding and explosion-protection state check; Functionality check. Visual inspection. It is necessary to make sure that there are no external mechanical damages and contamination.
  • Page 25: Packaging

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» Troubleshooting must be done in the following order: 1. Disconnect all fire extinguishing equipment connected to the detector. 2. Make sure that there is no contamination on the viewing windows. Full information about viewing window clearing is given in “Maintenance service”...
  • Page 26: Warranty

    FD 330-4-1 «VEGA» must be sealed with the manufacturer’s seals. 16. Warranty The manufacturer Co Ltd «IGM-Detector» guarantees the compliance of the flame detector FD 330-4-1 «VEGA» with the requirements of the technical conditions provided that the consumer follows operating, transportation and storage terms of this UM.
  • Page 27 MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» Appendix A FD 330-4-1 «VEGA» digital output protocol parameters * Modbus RTU protocol support is included in the basic version, On request detectors are deliveres with Hart interfaces support Flame detector FD 330-4-1 «VEGA» is designed to issue an alarm to fire alarm control and indicating equipment in the event of a fire in their field of vision.
  • Page 28 MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» One must bear in mind, that an attempt to change the detector’s number automatically leads to a change in the exchange rate (and vice versa), therefore, when changing the detector’s number, it is necessary to monitor the contents of the byte responsible for the exchange rate (and vice versa).
  • Page 29: Ex-Protection Drawing

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» Appendix B Ex-protection drawing...
  • Page 30: Revision History Sheet

    MRBP.425241.001-01 UM version 1.1 01.05.2022 FD 330-4-1 «Vega» Revision history sheet № of Sheet number (pages) № Total accom Chang sheet of the panyin Signature Date change replace number docum null (pages) docum ent and date...
