- Page 1 Axis Pulse User Manual...
-
Page 2: Technical Support
Introduction From all of us here at PurePressure, thank you for purchasing the PurePressure Axis Pulse! If these steps are followed, you can be sure to enjoy uninterrupted operation day in and day out. The instructions in this user manual specifically focuses on the Axis Pulse, but please contact us with any other needs and we’d be happy to help! Sales Inquiries:... -
Page 3: Technical Specifications
Technical Specifications Specification Axis Pulse Min: 27 PSI | Max: 87 PSI Mounting & control kit included 1920 VPM @ 27 PSI | 2580 VPM @ 87 PSI Pneumatic adjustable operation VPM (Vibrations Per Minute) @ X number of PSI Speed 80 (5.5 bar) Operational PSI... - Page 4 Mount Axis Pulse adapter plate to Mount Axis Pulse to Axis Pulse Connect ¼” NPT exhaust muffler to existing 44 gallon dolly using (4) adapter plate using (4) ¼-20 x 1 ½” Axis Pulse. 5/16-18 x 1 ¼” SS socket head screw SS button head screw and (4) ¼-20 and (4) 5/16-18 SS self-locking nuts.
- Page 5 Connect Needle Valve and Bracket to Insert push-to-connect tee by splicing pre-installed pneumatic tubing on pump tand. Hash Pump Stand using 5/16” SS self- drilling screws provided. Approximate Run ¼” pneumatic tubing off push-to-connect tee to port 1 of needle valve. mounting location to be centered on the stand.
- Page 6 Contact Us gopurepressure purepressure.com Reliability, Guaranteed PurePressure is committed to making operators as efficient as possible. The team is legendary for exceptional customer service and solventless extraction trainings. The Axis Pulse includes a 1-year manufacturer warranty.
