- Page 1 Assembly Instructions Product No. TM21RD32FPT1 32" Faux Stone Fire Pit Questions, problems, or missing parts? Before returning to the store, call Customer Service. 1-866-988-3300 8 a.m. - 5 p.m., PST Monday - Friday Retain this manual for future use.
-
Page 2: Table Of Contents
Contents Safety Instructions Parts List Assembly Operation Cleaning & Maintenance Troubleshooting Warranty This appliance complies with “ANSI Z21.97-2017/CSA 2.41-2017, Outdoor Decorative Gas Appliances.” IMPORTANT: RETAIN FOR FUTURE REFERENCE, AND READ CAREFULLY. TM21RD32FPT1... -
Page 3: Safety Instructions
DANGER which has no odor. Using it in an enclosed space can kill you. Do NOT leave this appliance unattended • For outdoor use only. while it is in operation. • Never use in the unventilated or enclosed areas. TM21RD32FPT1... - Page 4 More crack. frequent cleaning may be required as necessary. • You must follow all steps to properly assemble this heating item. Makesure the gas valve is turned “OFF” before assembling. Do NOT attempt to assemble without proper tools. TM21RD32FPT1...
- Page 5 • This unit is to be used with propane gas only! (sold separately) • Do not attach a remote gas supply to this unit. TM21RD32FPT1...
-
Page 6: Parts List
Burner - 1 Body - 1 Injector - 1 Ignition Screen - 1 Thermocouple - 1 Corrugated Pipe - 1 Gas Valve - 1 Base Plate - 1 Regulator - 1 Ground Wire - 1 Ignition Pin - 1 TM21RD32FPT1... -
Page 7: Assembly
Lift off the carton carefully and be wary of the accessories inside falling away. Take all the packing materials away except for the paper honeycomb board rounding the top of the firebowl. STEP 2 Turn the firebowl heads up on a flat ground. Remove all the paper honeycomb board rounding the top of the firebowl. TM21RD32FPT1... - Page 8 Check each part before using the product. Make sure the gas supply system is turned off before assembling. STEP 4 Open the storage door on the firebowl for the gas tank. Take away the box containing lava rock. LAVA ROCKS TM21RD32FPT1...
- Page 9 Turn the wing screw on the outer part of metal stand clockwise to secure the gas tank tight. STEP 6 Evenly distribute the lava rocks in the firebowl. Do not cover the ignition screen. Always keep the Ignition Screen visible. The burner of the firebowl must be covered by lava rocks completely. INCORRECT CORRECT TM21RD32FPT1...
- Page 10 Connect the Pressure-Regulating Valve to the gas tank. Pressure Relief Valve Cylinder Valve Black Coupling Nut Bleed-off Turn Clockwise to Connect Valve Turn Clockwise Regulator to Reseal STEP 8 Turn the cylinder valve clockwise to close the gas supply on the gas tank. TM21RD32FPT1...
- Page 11 Assembly STEP 9 Screw Regulator Coupling clockwise by hand only. Make sure it is fastened. TM21RD32FPT1...
-
Page 12: Operation
TO EXTINGUISH • Push the Control Knob and turn clockwise to the "OFF" position. • Turn the cylinder valve on the gas tank clockwise to close the gas supply if not in use for a long time. (See figure below) TM21RD32FPT1... -
Page 13: Cleaning & Maintenance
• Always place lid (if applicable) or protective cover on heating item when not in use. Turn control knob OFF. NOTE: In a salt-air environment (such as near to ocean), corrosion occurs more quickly than normal. Frequently check for corroded areas and repair them promptly. TM21RD32FPT1... -
Page 14: Troubleshooting
1. Clear burner/venturi tube 2. Check for bent or kinked hose Disengagement of burner to valve Re-engage burner and valve Spider webs or insect nest in Clean burner/venturi tube burner/venturi tube Burner ports clogged or blocked Clean burner ports TM21RD32FPT1... -
Page 15: Warranty
After cleaning cushions tip on end and allow to drip dry. (Never use a commercial or home dryer to tumble dry fabric goods). Do not use bleach or solvents to clean any product! This will void the warranty. TM21RD32FPT1... - Page 16 TO BE DEFECTIVE UNDER THE TERMS AND CONDITIONS AS STATED IN THIS WARRANTY. NEITHER ARISING OUT OF ANY BREACH OF THIS WARRANTY OR NEGLIGENCE EVEN IF IT HAS BEEN ADVISED ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES OTHER THAN THE WARRANTY DESCRIBED OR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESSLY DISCLAIMED. TM21RD32FPT1...
