Leviton D3200 Software Manual

Table Of Contents

Data Manager ................................................................................... 1

Startup Screen .............................................................................. 1

Open Existing System: The following screen appears.
Pick one of the existing files ................... 2

New System ................................................................................... 2

Config Device Screen .................................................................... 2

Config Names Tab ..................................................................... 2

Setup Tab ................................................................................... 3

Zone Properties window ............................................................ 3

Time Events Tab ............................................................................ 3

Holiday Window ......................................................................... 4
The screen shows any existing systems. The user must click on the existing
Scene Names Tab ......................................................................... 5 system, or enter the desired system name.

Location Setup Screen .................................................................. 5

Open Existing System:

Time Zone and Location Tabs ................................................... 5

the existing files.

Data Manager Menus .................................................................... 5

System menu ............................................................................. 5
Window Menu ............................................................................ 6
Report Menu .............................................................................. 6
Utils Menu .................................................................................. 6

D3200 Preferences ................................................................... 6

HELP Menu ............................................................................... 6
About D3200 DM ....................................................................... 6
Export Screen ................................................................................ 6
Download Manager .......................................................................... 7
Download Manager Menus ........................................................... 7
File Menu ................................................................................... 7
Network Menu ........................................................................... 8
New System:
Config Window ...................................................................... 8
Tools Menu ................................................................................ 8
When creating a new file, the D3200 Setup screen appears. This screen is
Dimmer Setup Screen ........................................................... 8 used to enter basic system information.
Advanced Functions .............................................................. 9
Load Scenes .......................................................................... 9
Reset Fade Rates .................................................................. 9
Fade Rates – Advanced ........................................................ 10
Merge Images... .................................................................... 10
Web Menu ................................................................................. 10
Help Menu ................................................................................. 10
About Window ........................................................................ 11
Dimensions Software
For the latest version of the D3200 software,
please visit www.leviton.com/D3200
Leviton provided software can be used to assist in setting up an individual
Dimensions D3206 or D3208 Multizone Controller, as well as configuring a
system of many D3206/8 units networked together. A device or system can
be configured before or after the devices are installed.
• When a new system is created, the D3200 Setup window will appear. This
The process of setting up a device involves 3 stages. First the information
screen can also be accessed through the Panel Setup button.
must be entered into the D3200 Data Manager. The Data Manager is a
• When opening an existing system, the D3200 Configuration window will
database with a graphical user interface to assist the user in entering the
appear. This window can be accessed using the Config Device button.
proper information. Next, the user chooses to export certain information for
downloading to the devices. Exporting is a process in which the selected
Panel Setup Screen:
information in the database is translated into a simple text format. The third
step is to download the information into the D320x. The Download Manager, Pull down
a separate program (included with the Data Manager) translates the simple menu to
choose the
text format into bytes the D3200 can understand.
Panel
The Download Manager uses the Leviton HTTP Server to facilitate the number, from
transfer data from the Download Manger to the D3200. When using the Panels 1-31.
Download Manager, the user must be sure that the Leviton HTTP Server is
Enter the
running.
Panel name
for the Panel
Data Manager
number
chosen.
Double-clicking on the Data Manager Icon opens up the following
window: Enter the
name for
each zone.
The SAVE button
stores all of the
information into
the database.
The SAVE button
must be used
Startup Screen
after making
changes.
There are three options: Create New System, Open Existing System and
Exit D3200 Data Manager.
Notes:
Create New System: This is for starting a new
• Zone names are different for every panel. If you have multiple panels, and
system.
you want to have customized names, you must enter the zone names for
each panel. Whichever zones you do not enter custom names for will
retain their default name.
Open Existing System: Open a system that
• Choosing the Panel number from the pull down list tells the software
has already been created.
which panel you are currently working with. However, before downloading
the information to the actual devices, they must have their Panel numbers
programmed. Programming a device's Panel number must be done
Exit Data Manager: Exits the program.
through the menu screen on the device.
• Only 16 characters are allowed for all names.
Config Device Screen:
Create New System:
The following screen appears, requesting a
system name. All system files are saved in the following directory:
The Config Device screen has four different tabs. The tabs are: Config
c:\...\Program Files\Leviton\D3200/DB
Names, Setup, Time Events, and Scene Names.
Config Names Tab
This screen is used to add/remove and customize the configuration
names. For example, Wedding, Conference, etc... This screen should not
1 be used unless there is a D3208 in the system.
The NUM
column
indicates the
configuration
number.
The arrow
indicates
which row is
the active row
for entering
text.
Notes:
• After entering a name, press the up or down arrow to navigate to
adjacent rows.
The following screen appears. Pick one of
• There are 255 possible configurations. Only provide names for the
configurations you are using. Download time increases with each
additional configuration used.
Setup Tab
The Setup Tab is used to make zone settings, including zone names,
channel mapping, group, zone type, load type, minimum level, and enable
or disable of the auxiliary channels.
When this screen is first opened, everything is grayed out. You must
choose the panel from the Panel Name box. Once the panel is chosen,
the zone names will appear. If the panel chosen is a D3206, then the
Configuration name box will remain grayed out. If the panel chosen is a
D3208, then you must choose for which configuration you want to make
settings. Once the configuration is chosen, the rest of the screen will
become active.
The Zone The Panel Name pull down list shows all 31 panels,
names that displaying any custom names that were entered in the
are entered Panel setup screen. The active panel is displayed in the
and saved in window.
the Panel
setup window
appear here.
You can also
edit the
names here.
These icons
show the
channel
mapping. See
direction below
to change a
channel
mapping. The
dimmers
represent
channel controls,
These buttons are used to
and the light
make zone (dimmer) settings.
bulbs represent
Pressing this button will
the load
open a new window.
terminal.
Channel Mapping: To change a channel mapping, follow these steps:
A. Click on the channel control (dimmer icon) to change. Notice it turns
Yellow.
B. Now click on the load terminal (light bulb icon) that should be
controlled by the channel control chosen.
C. A new line will form between the two.
Notes:
• In the case of duplicate links, the previous connection is removed.
• The Disconnect Zone button can also be used to remove a
connection between a channel and a zone.
Zone Properties window:
Select the type of device, either a
D3206 or D3208.
The button will access the Zone Properties window in which a zone's
individual parameters can be set.
If a D3208 is
selected
Pull down list
under Panel
to choose
type, the
which group
boxed area
this zone is a
shows.
part of.
AUX I Zone 1 - 7
AUX II Zone 1 - 8 Pull down list
to select Load
Type. If the
The CLOSE
zone is set as
button closes
a dimmer,
the Panel
select either an
setup window
Incandescent
without
or Fluorescent
saving the
Mark 10™
data.
dimmer.
The DEFAULT button restores the current
panel's zone names to the default names.
Notes:
• When the Load Type is set to Fluorescent, the minimum level will be
adjusted to 29%, which corresponds to 56V on the output, as per the
spec for the Mark 10™ ballast.
• Press the OK button to close the window. The OK button will not save
the information entered. When complete, press the Save Configuration
button on the Setup tab to save these settings.
Time Events Tab:
This window is for Time Events or Timers. Timers can be created, sorted,
edited removed and printed. This window is also used to access the holiday
setup window.
When the Time Events Tab is selected, the panel selection for Timers screen
shown below comes up. Timers must be entered for a specific panel. All
Timers should only be created for a single panel . Timers should NOT be
duplicated among multiple panels.
2
Dimensions D3200 Setup Software
Instruction Manual
www.leviton.com
The SAVE
button stores
all of the
information
into the
database.
The SAVE
button must
be used after
making
changes.
Once the panel to work with is chosen, the Timer entry screen will appear.
Notes:
• Start by choosing which panel to create the Timers for. Next, enter the
Timer name, Status, Action, Timer Type, Time Setup and Time. When this
information is entered, press the Add button. Press the Save button to
The Configuration
save the Timer.
Name pull down
list shows only A Timer cannot be added to the list until all of the information is
the configurations
entered.
that were named
• To edit a Timer already in the Time Events list, select the Timer by clicking
in the Config.
on the row the Time event occupies in the list. This Timer's information will
Names tab. The
appear in the Timer entry area. Make the necessary changes, and press
active
configuration is the Edit button. The changes will show in the Time Event list. Press the
displayed in the Save button to save the changes.
window.
• The list of Time Events in the Time Event list can be printed for reference.
The Save
With the D3200 Configuration window open, go to the Report menu and
Configuration
click on Print Events.
button stores all
of the information Time Events List. Pull down list of panels.
into the database. Scroll down to see all Choose which panel to
The SAVE button Timers. enter the Timers for.
must be used to
apply the
changes.
These check boxes The last two rows are
enable or disable the active for D3208
auxiliary zones for a panels. Otherwise,
D3208. they are grayed out.
Timer entry
area.
Enter Timer name Pull down list to select Timer Pull down list to
here. type. Choose from: One Time, select Time of Day,
Daily, Weekdays, Weekends, Dawn or Dusk.
Weekly or Holidays.
For the Time
of Day, enter
Time. For
Dawn or Dusk,
enter Offset.
Pull down list
For the Time of Day, Saves all Timers. Remove all Timers
to select Zone
enter Time. For Dawn from the Timer
Type. Set this
or Dusk, enter Offset. Event List.
zone to act as
either a
Example of Timer Type: One Time
dimmer or a
switched Timer: One Time.
Load.
Shows the
Set the chosen date.
minimum level
for the zone. Clicking on the
down arrow in
Date area opens
a calendar
window for date
selection.
Example of Time Type: Dawn
Offset settings:
• Pull down list for choosing + or –.
• Scrolling arrow buttons for selecting hours (h) and minutes (m).
Holiday Window
Holidays can be created through this window. The Holiday window can
be opened either through the Utils menu, or the Holidays button in the
Time Events tab.
Holidays can be printed in the same manner as Time Events.
3
Holiday List. After entering the
Holiday information,
Scroll down to
press Add to add the
see all Holidays.
Holiday to the list.
Click on a Holiday
in the list, make
changes in the
Holiday entry area
and press Edit.
Click on a Holiday in
Holiday entry
the List and press
area.
Remove.
Enter the Date.
Removes all
Scroll through the
Holidays from the
months or days.
List.
Pull down list of Status Holiday entry area. Saves all Holidays.
options. Choose from Enable,
Disable and Delete.
Scene Names Tab:
Scene names can be entered for the first 16 scenes of each group. Only
16 characters are allowed per name.
Pull down list to
select group.
Choose the
group to enter
scene names for.
The NUM column
indicates the
Scene number.
The pencil
indicates which
row is the active
row for entering
text.
The Save button stores all of the information into the
database. The Save button must be used after making
changes.
Location Setup Screen:
The Location Setup screen is used to program the Time Zone, Latitude and
Longitude. It contains the Time Zone and Location Tabs.
Time Zone and Location Tabs
The Save button
Change the size of the
saves all
columns, or sort the list by
settings.
column.
Press this
Pull down list for
button to open
the Holiday selecting the
window. Time Zone.
Choose the
appropriate Time
Zone from the
list.
Check the box to
program the
device to
automatically
adjust for
daylight savings.
Note: Daylight savings auto adjust is automatically checked for
After all data has
locations that comply. Uncheck the box to NOT automatically adjust.
been entered in the
Timer area, press
Add to add the Timer
The Save button
to the list.
saves all
settings.
Click on a Timer in
the Time Event list,
Pull down list for
make changes in the
selecting the
Timer entry area,
State. Choose
and press Edit.
the appropriate
State from the
Click on a Timer in list.
the Time Event list
and press Remove. The Latitude and
Longitude of the
chosen city will
appear here.
Pull down list for selecting the City. Choose the appropriate
City from the list. Only Cities in the selected State will appear.
Data Manager Menus:
The menu bar contains the following menus: System, Window, Utils, Reports
and Help.
System Menu
Time Setup: Dawn.
The system menu offers the options of New, Open, Save As and Exit.
These are general system manipulation functions similar to any other
windows based program.
• The New menu is the same function as the New button in the toolbar.
New will close an existing system file, if open, and create a new one.
The Save As screen will appear for entering the name of the new
system file.
• The Open menu is the same function as the Open button in the
toolbar. Open will close an existing system file, if open, and open a
new one. The Open screen will appear.
• The Save As menu is the same function as the Save As button in
the toolbar. The Save As screen will appear. This will be used when
making a copy of an existing system.
The Save buttons on each screen save the information entered,
so there is no need for a Save menu.
• Exit will exit the program.
4
DG-000-NE100-00A
Window Menu
The Window Menu offers options to arrange the open windows. This
function is similar to any standard Window based program.
Report Menu
The Report Menu offers options to print a list of the existing Timers or
Holidays. This menu will only be visible when the Config Device window is
open . The report is generated as plain text.
Utils Menu
The Utils menu contains the options of: Setup Holidays, Download
Manager and D3200 Preferences.
• Setup Holidays opens the Holiday Setup window. Holidays can be
entered as discussed in the Timers Tab.
• The Download Manager item will open the Download Manager.
See the section on the Download Manager.
• D3200 Preferences will open a window to change some program
settings.
D3200 Preferences
This screen is for advanced use of the Download Manager.
Opens a file
Displays the
navigation
current location
window to point
of the
to the Download
Download
Manager
Manager.
location.
Displays the
location of the Check this box
HTTP Server to automatically
(LPDS). start the
Download
OK closes the
Manager after
window, saving
export.
the changes.
Cancel closes the window
without saving changes.
• It is not recommended to change the location of the Download
Manager. If necessary, first move the Download Manager
executable file to the desired location, then using the file navigation
button, point to the new location.
• If the HTTP Server (LPDS) must be run on a different computer,
the name must be entered here. The HTTP Server Location line
may look like this:
HTTP:// server_computer_name: Port number /Leviton
Where server_computer_name is the network name of the
computer running the HTTP Server software, and Port number is
the HTTP port used if different than default (80).
• Un-checking the Automatically start Download Manager after
export check box will force the user to manually run the Download
Manager and load the .INI file created after the Export function.
HELP Menu
The help menu offers the about screen, which provides revision information.
About D3200 DM
Hyperlink
points to
the D3200
Version
website to
number. See
look for
release notes
updates to
for changes by
the
version.
software or
instructions.
Database
identifier.
Export Screen:
Once all of the information about the system has been entered into the
database, it must be compiled into language that can be sent to the
devices. This is performed through the Export screen. When an export is
started, the software compiles the database into the proper format, and
creates a file that is used by the Download Manager. This file has a .ini
extension, and is saved in the:
5 \Program Files\Leviton\D3200\INI directory 6
