Hercules HC61PB Owner's Manual & Safety Instructions

Cordless 4-1/2" / 5" paddle switch brushless angle grinder
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual &
Safety Instructions
22a
Model
HC61PB
Battery and Charger Sold Separately
/
Cordless 4-1/2"
5" Paddle Switch Brushless Angle Grinder
WARNING:
To prevent serious injury, User must read and understand
Owner's Manual. SAVE THIS MANUAL.
When unpacking, make sure that the product is intact and undamaged.
If any parts are missing or broken, please call 1-888-866-5797
as soon as possible. Reference 58260.
