Summary of Contents for KickAss KARTSP170
- Page 1 170W MONOCRYSTALLINE FIXED GLASS SOLAR PANEL USER MANUAL KARTSP170 V0.2...
-
Page 2: Table Of Contents
TABLE OF CONTENTS ................WHY KICKASS? .... IMPORTANT WARNING AND SAFETY INSTRUCTIONS ..KA 170W MONOCRYALLINE SOLAR PANEL FEATURES ......KARTSP170 DIMENSIONS / SPECIFICATIONS ........SOLAR POSITION OPTIMIZATION GUIDE ..............INSTALLATION GUIDE ..........RECOMMENDED CONFIGURATION ............AVAILABLE ACCESSORIES ....... RECOMMENDED CONNECTION DIAGRAM ............. -
Page 3: Why Kickass
WHY KICKASS? KickAss is focused on bringing the luxury of home to the outdoors. Your one stop shop for 12V products. All of our products are designed to be plug and play, for the ultimate camping experience. Designed by the KickAss team in Australia. - Page 4 CAUTION! Ÿ This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they are supervised or have been properly instructed on how to use the appliance by a person responsible of their safety.
-
Page 5: Ka 170W Monocryalline Solar Panel Features
FEATURES Tempered glass coating Pre drilled mounting holes Black aluminium frame Heavy duty extrusion PV Connector IP67 rating Diode protected junction boxes A Grade monocrystalline cells... -
Page 6: Kartsp170 Dimensions / Specifications
KARTSP170W DIMENSIONS / SPECIFICATIONS 657.50 6.50 900mm SPECIFICATIONS Application class: Class A SKU: KARTSP170 Cell type: High efficiency A-grade monocrystalline Fire safety class: Class C Max power (Pmax): 170W Maximum system voltage: 1000VDC Max power voltage (Vmp): 18.46V Operating temperature: -40°C to 85°C... -
Page 7: Solar Position Optimization Guide
SOLAR POSITION OPTIMIZATION GUIDE KickAss Solar Panel will perform at their peak with the panel face angled directly towards the sun. In the field this is not alway possible. KickAss recommends angling the panel between 20° and 40° from the ground. This ensure the most efficient total power output from your Solar Panel during the course of the day, in all seasons. -
Page 8: Installation Guide
INSTALLATION GUIDE When choosing installation positions for the Solar Panels, be aware of shading that can occur as a result of fixed existing accessories near to the panels. Shading on sections of the Solar Panels will significantly reduce the output performance of the panels. -
Page 9: Recommended Configuration
RECOMMENDED CONFIGURATION 00.88 CURRENT 12.75 VOLTAGE 26.70 DISCHARGING TEMP 7H 43M TIME TO EMPTY PAGE 1 PAGE 2 LITHIUM LiFePO POWER STATION KA8M2.5A2A... - Page 10 PV To Anderson Style Connector 5m Cable SKU: KAPVANDO5M KickAss 12V Control Hub With 20A DCDC Charger SKU: KACTRLHBDCDC 12 VOLT - 120A/H AGM - DEEP CYCLE VISIT OUR WEBSITE FOR MORE DETAILS www.kickassproducts.com.au KickAss 12V 120AH Deep Cycle AGM Battery...
- Page 11 Connector 5m Cable SKU: KAPVANDO5M KickAss 12V Control Hub With 20A DCDC Charger SKU: KACTRLHBDCDC KICKASS Automotive Inline MAXI Fuse Holder SKU: KAMAXIFHAND 12V 120AH LiFePO4 LITHIUM BATTERY KA12120-LION KickAss 12V 120AH LiFePO4 Lithium Battery & Remote Display Unit SKU: KA12120-LIONRDU...
-
Page 12: Available Accessories
AVAILABLE ACCESSORIES PV Connector 2 in 1 Branch SKU: KAPVCONN2IN1 PV to Anderson style connector 5m cable SKU: KAPVANDO5M Mounting Bracket x4 M6x16mm Machine Screw x4 M6 Spring Washer x12 M6x40mm Machine Screw x8 M6 Plain Washer x12 M6 Nut x12 Thread Plate x4 M6x40mm Self Tapper x8 Solar Panel Mount Kit... -
Page 13: Recommended Connection Diagram
RECOMMENDED CONNECTION DIAGRAM KickAss Solar Panels can be connected in Parallel or Series as per the diagrams below, or a combination of the two. Connecting two identical panels (of the same wattage) in parallel will multiply the total output current by 2 and keep the system voltage at the same level. Conversely, connecting two identical panels (of the same wattage) in series will multiply the system voltage by 2 and keep the output current at the same level. -
Page 14: Bracket Assembly Guide
BRACKET ASSEMBLY GUIDE The optional solar panel mounting bracket kit has been designed as an all in-one solution for rack or surface mounting. Mounting Bracket x4 M6x16mm Machine Screw x4 M6 Spring Washer x12 M6x40mm Machine Screw x8 M6 Plain Washer x12 M6 Nut x12 Thread Plate x4 M6x40mm Self Tapper x8... -
Page 15: Roof Rack Mounting Guide
ROOF RACK MOUNTING GUIDE Step 1 - Locate Solar Panel on Roof Rack: Consider the following when choosing location for the Solar Panel on the roof rack of your vehicle: Alignment of mounting brackets with rack cross members so all 4 brackets are can be secured. Cable routing - Keep all wiring away from shape edges and secure with zip ties. - Page 16 Step 2. Secure mounting bracket by locating thread plate with brackets and fixing with M6x40 machine screws, flat and spring washer. Step 3. Fix M6 Nut to lock screws...
-
Page 17: Flat Roof Mounting Guide
FLAT ROOF MOUNTING GUIDE Step 1 - Locate Solar Panel on Roof Surface: Consider the following when choosing location for the Solar Panel on rack: Ÿ Alignment of mounting brackets one a flat surface so all 4 brackets are can be secured. Ÿ...
