- Page 1 USER MANUAL PM-839 2 CHANNEL BLUETOOTH WALL AMPLIFIER WITH ANDROID Manual to download in PDF format on www.majorcom.fr...
- Page 2 PM-839 WALL-MOUNTED AMPLIFIER WALL-MOUNTED AMPLIFIER PM-839 1. PACKING LIST • PM-839 in-wall amplifier X1 (including terminal blocks) • Back box X1 INDEX • Screw X2 • User manual X1 • Remote control 1 1. PACKING LIST ..........................p.3 2. COMMON TROUBLESHOOTING ....................p.3 3.
- Page 3 PM-839 WALL-MOUNTED AMPLIFIER WALL-MOUNTED AMPLIFIER PM-839 3. DESCRIPTION 5. FEATURES This 2 channel small bluetooth audio system equipped with micro USB/TF can power 2 to 4pieces of speakers. It uses a high- • With RJ45 interface for both hard cat 5 cable or WIFI connection efficiency class-D amplifier for a maximum output of 2*25 watts and low-impedance speakers.
- Page 4 PM-839 WALL-MOUNTED AMPLIFIER WALL-MOUNTED AMPLIFIER PM-839 7. CONNECTIONS 6. REMOTE CONTROL 1. On / Off : press to turn on or shut down. 1. 485 interface (optional): 485A + 485B + GND 2. Audio source : press this button to switch the audio source.
- Page 5 PM-839 WALL-MOUNTED AMPLIFIER WALL-MOUNTED AMPLIFIER PM-839 8. MAIN INTERFACE FUNCTIONS 8.3 SETTING INTERFACE 8.1 MAIN INTERFACE After the host boots, it will directly enter in the main interface as shown picture below. : Play mode Local player switching Press « Online Music », « Audio Content » icon for 3 seconds, you can replace the application.
- Page 6 PM-839 WALL-MOUNTED AMPLIFIER WALL-MOUNTED AMPLIFIER PM-839 8.4 APPLICATION MANAGEMENT 8.5 SYSTEM SETTING INTERFACE • Internet management : set WIFI • Display management : set auto lock screen time • Time management : set time mode, 12h or 24h • Timing play : scheduled playback •...
- Page 7 10. CONNECTION 86 back Wall 10.1 CONNECT WITH 1 PIECE OF 8 OHM SPEAKER IN ONE CHANNEL TOTALLY 2 PIECES FOR PM-839 Screw Bracket 10.2 CONNECT WITH 2 PIECES OF 8 OHM SPEAKERS IN ONE CHANNEL SERIES CONNECTION TOTALLY 4 PIECES FOR PM-839 1.
- Page 8 PM-839 2 CHANNEL BLUETOOTH WALL AMPLIFIER WITH ANDROID User manual 5 6 , c h e m i n d e l a F l a m b è r e • 3 1 3 0 0 To u l o u s e • F R A N C E • T é l . 3 3 ( 0 ) 5 6 1 3 1 8 6 8 7...
