Project No：XW-01

Date：2020.04.20

Rev：V1.0

Customers name：

Model：

B&T part no.:

Description ：

Factory Signature:

Edition

XieYJ

Office：Room410, Building C, Huafeng Intelligence Innovation Port,

Gushu, Xixiang, Baoan District, Shenzhen China 518126

Factory ： 3/F, Building A, Dongfang Industrial Park, Dache Village, Nanlang Town, Zhongshan

City, Guangdong Province.528400

Tel ：0755-29162996、0760-88580932

Web：http://www.tech-now.com

Contact persion：

Specification

XW-01 802.11 b/g/n Wi-Fi Module

Form Number：B&T-QR-EN-002

深圳市博安通科技股份有限公司

SHENZHEN B&T TECHNOLOGY Co., Ltd

Recognition

XW-01 802.11 b/g/n Wi-Fi Module

Approve

Xuhong

Contact：

Mob：

Version：B2

中山市博安通通信技术有限公司

ZHONGSHAN B&T TECHNOLOGYCo., Ltd

XW-01

Ratification

Fax：0760-89961414

Email：

第 1 页共 20 页

Table of Contents

Need help?

Do you have a question about the XW-01 and is the answer not in the manual?

Questions and answers

Summary of Contents for b&t XW-01

Page 1 Project No：XW-01 Date：2020.04.20 Rev：V1.0 Recognition Customers name： Model： XW-01 B&T part no.: Description ： XW-01 802.11 b/g/n Wi-Fi Module Factory Signature: Edition Approve Ratification XieYJ Xuhong Contact： Office：Room410, Building C, Huafeng Intelligence Innovation Port, Gushu, Xixiang, Baoan District, Shenzhen China 518126 Factory ：...
Page 2 深圳市博安通科技股份有限公司中山市博安通通信技术有限公司 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd XW-01 Version: V1.0 Disclaimer and copyright notice The information in this article, including the URL address for reference, is subject to change without prior notice.The Documentation is provided "as is" without any warranty, including any warranties of merchantability, fitness for a particular purpose, or non-infringement, and any warranties mentioned in the proposal, specification or sample.
Page 3 深圳市博安通科技股份有限公司中山市博安通通信技术有限公司 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd The test data obtained in this paper are all obtained by B&T Technology , and the actual results may be slightly different.The Wi-Fi alliance membership mark is owned by the WiFi alliance. All trade mark names, trademarks and registered trademarks mentioned herein are the property of their respective owners and are hereby declared.
Page 4 深圳市博安通科技股份有限公司中山市博安通通信技术有限公司 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd Document development/revision/revocation resume Revised content Approve Version Date Edition V1.0 2020.06.20 First Edition XieYJ Form Number：B&T-QR-EN-002 Version：B2 第 4 页共 20 页...
Page 5: Table Of Contents
深圳市博安通科技股份有限公司中山市博安通通信技术有限公司 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd Contents 一、 Product Overview............................6 二、 Electrical parameters..........................9 三、 Appearance Size............................12 四、 Pin definition............................13 五、 Schematic diagrams..........................15 六、 Design guidance............................16 七、 Reflow soldering curve........................19 八、 Packaging information........................20 Form Number：B&T-QR-EN-002 Version：B2 第...
Page 6: 一、 Product Overview
XW-01-KIT special in low power sleep + cold start mode: refers to the cold start from the chip reset state to the configured network process, mainly used to meet the needs of the application of ultra-low power standby and fast networking at the same time, Complete network configuration in 150 ms~180 ms interval.
Page 7 深圳市博安通科技股份有限公司中山市博安通通信技术有限公司 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd Characteristics  Support 802.11 b/g/n,2400~2483.5 MHz  Very low power consumption, suitable for demanding low power consumption occasions  Support interface type: UART/GPIO/PWM/ADC/I2C  Cold connection, wake up to the network only 150 ms-200ms( measured), making the total power consumption lower ...
Page 8 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd end control  General AT instructions can be used quick and easy Main parameters Table 1 main parameter descriptions Model XW-01 Package SMD-22 Size 24*16*3(±0.2)MM Antenna On-board PCB antenna or IPEX antenna Frequency 2400 ~ 2483.5MHz...
Page 9: 二、 Electrical Parameters
ESD sensitive components. The correct ESD processing and packaging procedures must be adopted throughout the processing, transportation and operation of any application combined with the XW-01 module. Do not touch the module by hand or use non-static soldering iron to avoid damage to the module.
Page 10 深圳市博安通科技股份有限公司中山市博安通通信技术有限公司 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd RF parameters Description Unit 2400 ~ 2483.5 Operating frequency Output power 11n mode ，PA output power 15±2 11g mode，PA output power 16±2 18±2 11b mode，PA output power Receiving sensitivity CCK, 1 Mbps ＜＝-97 CCK, 11 Mbps...
Page 11 深圳市博安通科技股份有限公司中山市博安通通信技术有限公司 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd Sleep Standby 102.2 μA Hibernation μA Power Off μA 表单编号：B&T-QR-EN-002 版本：B2 第 11 页共 20 页...
Page 12: 三、 Appearance Size
深圳市博安通科技股份有限公司中山市博安通通信技术有限公司 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd 三、 Appearance Size 表单编号：B&T-QR-EN-002 版本：B2 第 12 页共 20 页...
Page 13: 四、 Pin Definition
深圳市博安通科技股份有限公司中山市博安通通信技术有限公司 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd 四、 Pin definition XW-01 module is connected to 22 interfaces, refer to pin diagram as below, pin function definition table is interface definition 。 pin diagram XW-01 Function definition of pin...
Page 14 深圳市博安通科技股份有限公司中山市博安通通信技术有限公司 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd PA10 GPIO 10/gpadc input Ground Not connect PA11 GPIO 11/gpadc input PA07 GPIO 7 PA19 GPIO 19/ Awaken IO pin PA20 GPIO 20/ Awaken IO pin Not connect GPIO 0 GPIO 1 Power enable pin GPIO 3...
Page 15: 五、 Schematic Diagrams
深圳市博安通科技股份有限公司中山市博安通通信技术有限公司 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd Schematic diagrams 五、表单编号：B&T-QR-EN-002 版本：B2 第 15 页共 20 页...
Page 16: 六、 Design Guidance
深圳市博安通科技股份有限公司中山市博安通通信技术有限公司 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd Design guidance 六、 1、Application circuit 2、天线布局要求 1、Antenna layout requirements （1）、 The installation position on the motherboard is recommended in the following two ways: Scheme 1: put the module on the edge of the motherboard, and the antenna area extends out of the edge of the motherboard.
Page 17 深圳市博安通科技股份有限公司中山市博安通通信技术有限公司 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd 3、Power supply （1）、Recommend 3.3V voltage, peak current above 50mA （2）、It is recommended to use LDO for power supply; if DC-DC is used, the ripple is recommended to be controlled within 30mV. （3）、DC-DC the power supply circuit, it is suggested to reserve the position of output ripple can be optimized when the load changes greatly.
Page 18 深圳市博安通科技股份有限公司中山市博安通通信技术有限公司 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd match the IO level of the module, require to add the level conversion circuit. （4）、 When the IO port is connected directly to the peripheral interface, or the pin header and other terminals, it is recommended to reserve ESD device near the terminal.
Page 19: 七、 Reflow Soldering Curve
深圳市博安通科技股份有限公司中山市博安通通信技术有限公司 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd 七、 Reflow soldering curve 表单编号：B&T-QR-EN-002 版本：B2 第 19 页共 20 页...
Page 20: 八、 Packaging Information
深圳市博安通科技股份有限公司中山市博安通通信技术有限公司 SHENZHEN B&T TECHNOLOGY Co., Ltd ZHONGSHAN B&T TECHNOLOGYCo., Ltd Packaging information 八、 As shown in below image，the package of XW-01 is in reel. 表单编号：B&T-QR-EN-002 版本：B2 第 20 页共 20 页...
