Bath Royale MB0419 Installation Instructions Manual

Thank you for selecting Bath Royale,
the benchmark of quality and function.
To ensure that your installation proceeds smoothly,
please read these instructions carefully before you begin.
7
6
5
3
8
1
10
4
5
6
2
7
IMPORTANT: Make sure your water supply line is fully ushed
before installation of this product.
© 2022 Marcobelle Company. All Rights Reserved
Questions? Visit BathRoyale.com
13
12
14
15
9
15
11
8
MB0419 SHOWER KIT
Recomended tools and materials
Te on Tape Tape Measure
No. Part name
1 Slide Bar
2 Wall Fixation Bracket (Fixed)
3 Wall Fixation Bracket (Floating)
4 Handspray Holder
5 Wall Bracket Fixation Screws
6 Wall Inserts (if need)
7 End Cap For Slide Bar
8 End Cap For Wall Fixation Bracket
9 Hand Shower
10 Combined Flow Regulator /
Check Valve 1.75 GPM
11 Shower Hose 1.5M
12 Shower Arm
13 Wall Flange
14 Vacuum Breaker
15 Sealing Washer
COMPLIES WITH:
• IPC / IRC / UPC
• EPA WaterSense®
• ASME A112.18.1 / CSA B125.1
Screwdriver Level
MB0419 07.03.22
Page 1
Drill
Qty.
1
1
1
1
2
2
2
2
1
1
1
1
1
1
2
