PCB Piezotronics Shear ICP M350B01 Installation And Operating Manual page 16

4
PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
B
A
RECOMMENDED MOUNTING TORQUE ON .375 [9.52] HEX 2.5-4 FOOT POUNDS [3.4 - 5.4 NEWTON METERS]
1
4
3
1.04  .03 26.5 [  .8 ]
.26 [6.5]
.20 [5.1]
MOUNTING HOLE PREPARATION

Ø.22 [5.4] 30 [7.6] MIN
1/4-28 UNF-3B  20 [5.1] MIN
(M) OPTION
.40 [10.2]
Ø.21 [5.3]  30 [7.6] MIN
M6 X 0.75-6H  20 [5.1] MIN
3
2

2X .37 [9.4]
031 AD010EB CABLE
10 FEET [3 METERS] LONG
TERMINATING IN A 10-32 UNF-2B
THREADED ELECTRICAL CONNECTOR
.375 [9.52] HEX 1
.02 [0.5]
1/4-28 UNF - 3A
(M) OPTION: M6x0.75-4g6g
Ø .38 [9.7] MIN
63 [1.6]
.013 [.033] A

 .001 [.03]
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES DIMENSIONS IN MILLIMETERS
[ IN BRACKETS ]
DECIMALS XX ±.01 DECIMALS
XXX ±.005
ANGLES  2 DEGREES ANGLES 
FILLETS AND RADII FILLETS AND RADII
.003 - .005 0.07 - 0.13
2
REV
REVISED NOTE 1; CHANGED TOLERANCE ON HEX
C
DRAWN CHECKED ENGINEER
KRM 9/14/18 KRM 9/14/18 BAM 9/14/18
TITLE
X ± 0.3
XX ± 0.13
INSTALLATION DRAWING
2 DEGREES
MECHANICALLY FILTERED
SHOCK ACCELEROMETER
1
REVISIONS
DESCRIPTION DIN
48646
DIMENSION
B
A
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
52262
IDENT. NO.
52681
SCALE: 4X SHEET 1 OF 1
1
