- Page 1 DIAMOND STONE INSTRUCTION MANUAL INSTRUCTIONS FOR ROUTER BIT SHARPENER CREDIT CARD STONE SINGLE HANDLE FILE 8” BENCH STONE read re-cycle version...
- Page 2 MPOWER Diamond Stones are intended to be used to sharpen steel, tungsten carbide & high speed steel tools. For both professional and domestic use. SAFETY Please read and understand these instructions before use. Users must be competent in using Woodworking equipment before using our products.
-
Page 3: Technical Data
The diamond is extremely abrasive so what would normally take 5-10 minutes on an oilstone may take approximately 20 seconds on the Diamond Stone. Dry the Diamond Stone thoroughly after use. Any wet steel filings left on the stone will cause surface rust to form. - Page 4 MAGNETIC NON-SLIP Diamond Stone HOLDERS (PAIR) - Optional Inc. with MPOWER Bench Stone. Not inc. with Credit or Router Bit Sharpener. Note: Also fits other brands of credit card and Stones. MOUNTING YOUR DIAMOND STONES 8” Bench Stone Router Bit Sharpener...
- Page 5 OPERATION Router Bits/Cutters Suggested: Router Bit Sharpener Fine: For Tungsten Carbide. Coarse: For High Speed Steel. Always sharpen the flat face, never the profile/relief. Slide the cutter with slight pressure along the whetstone. Repeat same number of strokes on each cutting edge.
- Page 6 Circular Sawblades Suggested: Single Handle File or Router Bit Sharpener Fine: For regular maintenance Coarse: For dull blades Keep the diamond surface flat to the face of saw tooth. Use a few light, smooth, back and forth strokes on each tooth. Repeat the same number of strokes on each tooth.
- Page 7 Chisel/Plane Irons Suggested: 8” Bench Stone Fine: For edge honing Coarse: Areas of minor damage Keep the bevel of the chisel/plane iron flat on the stone. Finish with one light stroke on the back of the chisel.
- Page 8 Suggested: 8 “ Bench Stone Fine: To keep a razor edge Coarse: To restore an edge Keep the same angle as the knife bevel on the Diamond Stone. for most knives. Stroke away from the body, alternating on each said of the knife.
- Page 9 Fine: To maintain an edge Coarse: To restore a dull edge Keep the bevel on the back of the gouge flat on the Diamond Stone. Gently roll the tool bevel to hone. Small tools should be honed as per chisels, pointed tools should be...
- Page 10 Fine: To hone the edge Coarse: To prepare the edge Dismantle the shears to work on the cutting blade. Lay the Diamond Stone flat on the cutting edge bevel. Stroke smoothly towards the tip of the blade. Lay the stone flat on the sliding face and remove the burr with a light stroke (as per the main image above).
-
Page 11: Environmental Protection
ACCESSORIES Non-slip, Magnetic Diamond Stone Holder (pair) Diamond Lapping Fluid - (New from June 2021) Abrasive Polishing Wax - (New from June 2021) Diamond Stone MAINTENANCE Continual satisfactory operation depends upon proper tool care and regular cleaning. Cleaning Clean with a damp cloth or Eraser Block. - Page 12 MPOWER Tools Limited cannot be held liable for any material rendered unusable, or for any form of consequential loss. Manufactured by MPOWER Tools Ltd Tel: 0044 (0)1980 629 526 Email: technical@m-powertools.com Email: customercare@m-powertools.com Web: www.mpower-tools.com © Copyright MPOWER Tools Ltd 2021...
