Summary of Contents for Ignite Mini

  • Page 1 USER MANUAL...
  • Page 2 The mobility scooter that keeps on giving. . .
  • Page 3 Heated Seat as standard Brighten your day your day Learn more about your Ignite today...

  • Page 4: Table Of Contents

    Speed Controls............19 Contents 7.5.2 Freewheel Function ..........20 7.5.3 Reversing ............... 21 Welcome ................... 6 Using the Ignite Mini ............ 22 Legal ....................7 Digital LCD Display ............23 Safety ....................8 7.7.1 Odometer ..............24 Anti-Tip Wheels ..............8 7.7.2...
  • Page 5 Fuses ..................33 13 Servicing ..................39 10.4 Tyre Pressures ..............34 14 Notes ....................43 10.5 Cleaning & Maintenance ..........35 10.5.1 Rubber Mats ............35 10.5.2 Paintwork ..............35 11 Warranty ..................36 Scooterpac Ignite Mini | User Manual...

  • Page 6: Welcome

    Ignite Mini will give you many years and countless miles of rewarding experiences. This manual contains the information that you and your authorised Scooterpac Town/City ________________________ dealer will need to keep your Ignite Mini in good working order. Postcode ________________________ If you have any questions, please contact the Scooterpac...

  • Page 7: Legal

    2 Legal The Scooterpac Ignite Mini is designed to be operated by a single person, in accordance with the legal requirements for operating a Class 3 invalid carriage in the jurisdiction in which it was sold. Operating the vehicle outside of these limitations may invalidate your warranty.

  • Page 8: Safety

    3 Safety The Ignite Mini should only be operated by a single person, who is not suffering from any condition which impairs vision, hearing, eyesight or the ability to react to sudden changes in surroundings. If you suffer from any of the above, it is recommended that you seek advice from your doctor before operating the Ignite Mini •...

  • Page 9: Safe Inclines

    3.2 Safe Inclines The Ignite Mini can climb inclines of up to 15˚ without danger. On this 15˚ incline, the Ignite Mini can stop, brake and turn. It is possible to attempt steeper inclines, but we strongly suggest that you do not. To reduce the possibility of tipping backwards on inclines, lessen the load on the back of the scooter by sliding the seat forward as much as possible and leaning forward.

  • Page 10: Introduction

    4 Introduction Your Ignite Mini is a high-tech piece of mobility equipment that will give you years of faithful service and enjoyment. This manual introduces you to the operation, maintenance and care of your Ignite. If you have any questions, or are unsure of anything, please contact the dealer your originally purchased the Ignite from.

  • Page 11: Your Ignite Mini

    5.1 Intended Use The Ignite Mini is designed for use on smooth pavement or roadway, in accordance with local laws. The Ignite Mini can be used in wet and windy weather, but discretion should be used when planning a journey in adverse weather conditions. If there is more than 1cm of water standing on the pavement, extra care should be taken as the scooter may have reduced ability to grip and steer.

  • Page 12: Unintentional Movement

    5.2 Unintentional Movement Before operating, the Ignite Mini should always be stationary. When the Ignite Mini is switched on, it will remain stationary until one of the following: 1. The forward or reverse lever is pulled/pushed. 2. The freewheel function is engaged.

  • Page 13: Digital Tiller Guide

    6 Digital Tiller Guide Figure 2 – Digital Tiller guide Scooterpac Ignite Mini | User Manual...

  • Page 14: Operating Your Ignite

    7 Operating Your Ignite 7.1 Keys & Fobs The Ignite Mini is delivered with several keys which operate various functions: For instructions on how to use the Bluetooth Fob please see page 30. Ignition Lockable Box Radio / Speaker Keys...

  • Page 15: Seat Adjustments

    Backrest Adjustment The pitch of the seat can be changed by the lifting lever located on the right- hand side of the seat when seated. Figure 4 – Pull black handle to adjust the backrest Scooterpac Ignite Mini | User Manual...
  • Page 16 To change the angle of the seat, sit on the seat, pull the swivel handle towards the front of the scooter and turn the seat anti-clockwise. Figure 5 – Pull black handle to control the swivel adjustment Scooterpac Ignite Mini | User Manual...

  • Page 17: Tiller Adjustments

    Try to find a position that allows a good view of the digital control panel and allows full left and right movement of the steering. Figure 6 – Press the black handle down to adjust tiller pitch Scooterpac Ignite Mini | User Manual...

  • Page 18: Steering

    For the most accurate steering the Ignite Mini should be moving forwards or backwards at a controllable speed. Gently push one side of the tiller away from you, allowing the Ignite Mini to begin turning. Make sure that you are continually observing your surroundings during any manoeuvre.

  • Page 19: Acceleration & Braking

    7.5 Acceleration & Braking 7.5.1 Speed Controls The Ignite Mini has several methods for controlling speed; the High and Low Speed Modes, the Min/Max Speed Limiter and the Throttle Levers. 7.5.1.1 High and Low Speed Modes The high (“H”) and low (“L”) speed modes are controlled by the right-hand dial on the tiller.

  • Page 20: Freewheel Function

    7.5.2 Freewheel Function You may need to move the Ignite Mini without engaging the motor. This can be achieved by pressing and holding the “Freewheel” button. The scooter must be switched on, with keys in the ignition and power to the main display.

  • Page 21: Reversing

    7.5.3 Reversing To engage reverse mode, ensure that the Ignite Mini is stationary and on even ground. Before moving, check that the area is clear of obstructions and your planned path is of adequate size. Gently squeeze the red lever, and the Ignite Mini will begin to slowly move backwards.

  • Page 22: Using The Ignite Mini

    7.6 Using the Ignite Mini The Ignite Mini will start once the ignition key is inserted into the housing on the tiller and turned clockwise (figure 10). The Ignite Mini is powered on and ready to be used when the digital dashboard displays visual data (figure 11).

  • Page 23: Digital Lcd Display

    7.7 Digital LCD Display Figure 12 – Digital LCD Display Scooterpac Ignite Mini | User Manual...

  • Page 24: Odometer

    7.7.1 Odometer The displayed miles/kilometres on the Digital LCD Display are cumulative and represent the total distance the Ignite Mini has travelled. 7.7.2 Setting the Clock To set the clock follow the below instructions: 1. Press and hold the headlight button for five seconds 2.

  • Page 25: Indicators

    The electric horn is activated by pressing the button on the tiller top. The horn should only be used in compliance with the Highway Code. The horn will only sound if the ignition is switched on. Scooterpac Ignite Mini | User Manual...

  • Page 26: Usb Charging Ports

    7.11 USB Charging Ports The Ignite Mini is equipped with USB charging ports on the right-hand side of the tiller column. The two USB ports provide different power outputs. USB Port 1 is located next to the LED light and USB Port 2 can be found on right hand side.

  • Page 27: Cup Holder

    7.12 Cup Holder For your convenience, the Ignite Mini is fitted with a bottle/cup holder. It can be opened by pulling down on the upper ring. The lower ring will follow. TOP TIP – The cup holder should not be used to store alcoholic beverages.

  • Page 28: Charge Port

    7.13 Charge Port Charging the Ignite Mini can be completed by using the charge port on the tiller. The port is located on the tiller column on the right-hand side. To charge the scooter, simply connect the supplied charge cable to the port.

  • Page 29: Heated Seat

    When the heated seat button is LED is not illuminated this indicates illuminated this indicates the heated that the heated seat function is off. seat function is on. Figure 16 – Heated seat button Scooterpac Ignite Mini | User Manual...

  • Page 30: Audio Player

    Press VOL – (3), short press to switch the previous music or previous radio, long press to reduce the volume. Press VOL + (4), short press to switch the next music or the next radio station, long press to increase the volume. Scooterpac Ignite Mini | User Manual...

  • Page 31: Bluetooth Setup

    To pair your mobile device with the audio player: Ensure there no USB drives are connected Turn on the Ignite Mini’s ignition Press PADLOCK (1) on the Bluetooth Key Fob – the Digital LCD Display will display ‘MP3 mode’ Navigate to the Bluetooth settings on your mobile device and connect to ‘scooter’...

  • Page 32: Maintenance

    10.2 Battery Care The battery assembly in your Ignite Mini should not require any maintenance on a day-to-day basis, however access may be required. The batteries are located under the seat, protected by a plastic shroud – secured by one thumb screw.

  • Page 33: Fuses

    10.3 Fuses The fuses used on the Ignite Mini are accessible through a covered hatch on the front of the tiller. To access the fuse board, simply pull down on the retaining clip and slide the cover out of place. Fuses should only be changed by professionals, as improper work may damage the Ignite Mini electrical system.

  • Page 34: Tyre Pressures

    The tyres should always have at least 3mm of tread to provide adequate grip on the road surface. If the tyres become worn, they should be replaced before the Ignite Mini is used again.

  • Page 35: Cleaning & Maintenance

    10.5.2 Paintwork To care for the paint, regularly wash the Ignite Mini using soft cloths and a mild automotive detergent. Apply automotive polish to achieve a high-shine finish. It is highly recommended that polish is applied in areas where the paintwork may be exposed to adverse weather conditions.

  • Page 36: Warranty

    Scooterpac dealer from which it was purchased. If a repair cannot be completed a replacement part will be fitted. If a manufacturing defect is found, it must be reported in writing to the Scooterpac dealer from which the Ignite Mini was purchased from within 28 days of purchase.

  • Page 37: Specifications

    12.1 Technical Specification Rear Wheel Drive Sealed Transaxle Dual 12V Motor Batteries 950w (4 Pole) 75Ah 24 Volt DC Digital Dashboard Display 6-button Tiller Dashboard Tyres Pneumatic 13” Max Speed Dial Speed Mode Dial Scooterpac Ignite Mini | User Manual...

  • Page 38: Sizes & Weights

    Length 1350 mm variance of +/-3%. Width 650 mm Varies with user weight, terrain type, battery charge, Tyres 13” pneumatic tyres battery condition, tyre condition. Wheel Size 8 inches Maximum Slope 15 degrees Scooterpac Ignite Mini | User Manual...

  • Page 39: Servicing

    13 Servicing In order to ensure continued safe operation, the Ignite Mini must be serviced every 12 months. We recommend recording the servicing dates and locations on the sheets below. Always have your Ignite Mini serviced at an authorised Scooterpac dealer, using original Scooterpac parts.
  • Page 40 Next Service Year Service Dealer Name Technician Name Date of service Mileage Notes Signed Next Service Year Service Dealer Name Technician Name Date of service Mileage Notes Signed Scooterpac Ignite Mini | User Manual...
  • Page 41 Next Service Year Service Dealer Name Technician Name Date of service Mileage Notes Signed Next Service Year Service Dealer Name Technician Name Date of service Mileage Notes Signed Scooterpac Ignite Mini | User Manual...
  • Page 42 Next Service Year Service Dealer Name Technician Name Date of service Mileage Notes Signed Next Service Year Service Dealer Name Technician Name Date of service Mileage Notes Signed Scooterpac Ignite Mini | User Manual...

  • Page 43: Notes

    14 Notes Scooterpac Ignite Mini | User Manual...
  • Page 44 Brighten your day Tel: 0330 124 1733 E-mail: info@scooterpac.com Web: www.scooterpac.com SP/IGM/M/EN/2022-B...
