EDEN
Spare Parts
Customer Support
www.argos-support.co.uk
0045 7668 8055
Help@ClickSpares.co.uk
0370 112 1928
Issue 1 - 28/04/22

Advertisement

loading
Need help?

Need help?

Do you have a question about the EDEN 484/5041 and is the answer not in the manual?

Questions and answers

Summary of Contents for Habitat EDEN 484/5041

  • Page 1 EDEN Spare Parts Customer Support www.argos-support.co.uk 0045 7668 8055 Help@ClickSpares.co.uk 0370 112 1928 Issue 1 - 28/04/22...
  • Page 2: Product Details

    Safety and Care Advice Product Details Rose 484/5041 White 474/6841 IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY. • Keep children and animals • Assemble on a soft level • We do not away from the work area. Small surface to avoid damaging the recommend the parts could choke if swallowed.
  • Page 3: Important! Keep For Future Reference

    80-35101 Singlebed IMPORTANT! KEEP FOR FUTURE REFERENCE PLEASE DISPOSE OF PACKAGING MATERIAL. PLASTIC BAGS CAN BE DANGEROUS TO YOUNG CHILDREN WARNI N G! Not suitable for children under 4 years. WARNING! Do not place this child’s bed near heat sources, windows and other furniture. WARNING! Do not use this child’s bed if any of the parts are broken, torn or missing.
  • Page 4: Tools Required

    Tools required Ruler/tape Phillips screwdriver measure (small & medium) Flatblade screwdriver Eye protection (small & medium) (when using a hammer or glue) Small hammer Allen key 4mm (included) No. 4033-002 Allen key 5mm (included) No. 4033-005...
  • Page 5 Components Bed end x2 Cross rail x2 Slat x15 (948x160x19mm) (901x54x26mm) (897x65x14,7mm) No. 4350-1909481-40 White No. 12-02609012 No. 12-01506971 No. 4350-1909481-26 Rose Bed side x2 List x2 Leg x4 (1900x152x19mm) (1888x26x20mm) (Ø48x215mm) No. 4301-1919004-40 White No. 12-02018882 No. 1341-02151 No. 4301-1919004-26 Rose...
  • Page 6 Fittings (Shown to scale) Bag 1 Dowel Ø8x40mm x8 Confi rmat screw Ø7x40mm x24 Barrel nut M6 Ø10x14mm x4 No. 3930-08040 No. 3908-70040 No. 3922-06014 Sleeve nut Ø10/M8x16mm x4 Chipboard screw Ø4x30mm x30 Dowel Ø10x50mm x8 No. 3923-08016 No. 3901-40030 No.
  • Page 7 Confi rmat screw Ø7x40mm x24 DO NOT OVERTIGHTEN! Dowel Ø8x40mm x8 Dowel Ø10x50mm x8...
  • Page 8 Sharp edge Large holes upwards! Sharp edge Connecting bolt M6x65mm x4 Barrel nut M6 Ø10x14mm x4...
  • Page 9 Connecting bolt M6x65mm x10 Sleeve nut Ø10/M8x16mm x4...
  • Page 10 Chipboard screw Ø4x30mm x6 5 mm 5 mm 847 mm Chipboard screw Ø4x30mm x24 65 mm Ref.no. 44-02007 A Stand: 280422 Page 10 (80-35101-26/-40)

This manual is also suitable for:

Eden 474/6841
