- Page 1 BMB Zada & Zada Pro Installation Guide V2.0 A step-by-step installation guide for the BMB Zada and Zada Pro by Hommix UK. If you have any questions or anything you believe that needs to be added to this manual, please email us at info@hommix.co.uk for future updates of this document...
- Page 2 Table of Contents PACKAGE CONTENTS........................... 3 PREPARING THE FITTINGS ........................... 4 ......................... 4 EMOVING THE BLANK FITTINGS ........................4 NSERTING THE LBOW ONNECTORS FEED WATER CONNECTION ......................... 5 TAP CONNECTION ............................6 MOUNTING THE ZADA / ZADA PRO ......................7 HOMMIX 3-WAY TAP CONNECTION ......................
- Page 3 Package Contents Elbow Connections Diverter Valve Metal Ball Valve 2 x 2m Tubing Tap Assembly Kit PTFE Tape BMB Zada BMB Zada Pro Please note: if you have purchased the BMB Zada or the BMB Zada together with a Hommix 3-Way Tap, the “Tap Assembly Kit”...
- Page 4 Preparing the Fittings Both the Zada and Zada Pro have blank fittings applied by default, this is to protect the inlet and outlet of the filtration systems during transport. First of all, let’s remove the blank fittings. Removing the blank fittings To remove the blank fittings, simply push the collar in towards the fitting with whilst pulling the blank fitting away from the main fitting.
- Page 5 Feed Water Connection The purpose of the feed water connection is to feed the system with water to be purified by tapping the cold-water supply which is usually located under the kitchen counter. Before you start, please ensure you have turned off the main water supply and always ensure there is a bucket or bowl and dry cloth for unforeseen circumstances.
- Page 6 Tap Connection First of all, a proper location to mount the tap needs to be selected, paying close attention to the placement of the tap stem under the counter. Ensure you use the correct type of drill bit for your counter type Hammer Drill Bit: Cement, Tile, Granite, Marble &...
- Page 7 Mounting the Zada / Zada Pro Mounting the Zada or the Zada Pro is really simple as it is already supplied with the mount and the parts for mounting it. Please ensure that there is at least 10cm empty below the bottom of the filter system to ensure you have enough space to pull the filter(s) down when the filter is due to be replaced.
- Page 8 Replacing the Filters Please make sure the Metal Ball Valve is turned off to ensure water flow is stopped before removing the filter Replacing the filters have never been so simple. By default, the filters will be locked; simply unlock the filter then twist and pull it down to remove.
