Page 1: User Guide
ThinkCentre User Guide Machine Types: 3129, 3133, 3136, 3141, 3146, 3150, 3156, 3166, 3169, 3175, 3177, 5036, and 7338...
Page 2 “Important safety information” on page v and Appendix A “Notices” on page 107. Third Edition (December 2011) © Copyright Lenovo 2011. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-35F-05925.
Page 3: Table Of Contents
Software overview ....Software provided by Lenovo ..Adobe Reader ....
Page 4 Information resources ... . Lenovo ThinkVantage Tools ..Lenovo Welcome ... . Help and Support... .
Page 6 ThinkCentre User Guide...
Page 7: Important Safety Information
® Document Format (PDF) version from the Lenovo Support Web site at http://www.lenovo.com/support. The Lenovo Support Web site also provides the ThinkCentre Safety and Warranty Guide and this ThinkCentre User Guide in additional languages. Service and upgrades Do not attempt to service a product yourself unless instructed to do so by the Customer Support Center or your documentation.
Page 8: Power Cords And Power Adapters
or CRU, do not open the static-protective package containing the part until the instructions direct you to install it. When you handle options or CRUs, or perform any work inside the computer, take the following precautions to avoid static-electricity damage: •...
Page 9: Plugs And Outlets
Never block, cover, or disable these features. Inspect your desktop computer for dust accumulation at least once every three months. Before inspecting your computer, turn off the power and unplug the computer's power cord from the electrical outlet; then remove any dust from vents and perforations in the bezel.
Page 10: Operating Environment
For your safety and to maintain optimum computer performance, always follow these basic precautions with your desktop computer: • Keep the cover closed whenever the computer is plugged in. • Regularly inspect the outside of the computer for dust accumulation.
Page 11: Laser Compliance Statement
Do not spray any liquid detergent directly on the computer or use any detergent containing flammable material to clean the computer. Spray the detergent on a soft cloth and then wipe the computer surfaces. © Copyright Lenovo 2011...
Page 12 ThinkCentre User Guide...
Page 13: Chapter 1. Product Overview
Chapter 1. Product overview This chapter provides information about the computer features, specifications, software programs provided by Lenovo, and locations of connectors, components, parts on the system board, and internal drives. Features This section provides information about the computer features. The following information covers a variety of models.
Page 14 • Ability to store power-on self-test (POST) hardware test results • Desktop Management Interface (DMI) Desktop Management Interface provides a common path for users to access information about all aspects of a computer, including processor type, installation date, attached printers and other peripherals, power sources, and maintenance history.
Page 15 The operating system(s) listed here are being certified or tested for compatibility at the time this publication goes to press. Additional operating systems might be identified by Lenovo as compatible with your computer following the publication of this manual. This list is subject to change. To determine if an operating system has been certified or tested for compatibility, check the Web site of the operating system vendor.
Page 16: Specifications
Minimum: 200 V ac Maximum: 240 V ac Input frequency range: 50 to 60 Hz Voltage-selection switch setting: 230 V ac Software overview The computer comes with a preinstalled operating system and several software programs provided by Lenovo. ThinkCentre User Guide...
Page 17: Software Provided By Lenovo
To access the Lenovo ThinkVantage Tools program, click Start ➙ All Programs ➙ Lenovo ThinkVantage Tools. The following table lists the programs that you can access from the Lenovo ThinkVantage Tools program. To access a program, double-click the corresponding icon.
Page 18: Product Recovery
• The ThinkVantage Password Manager program is only available on computers preinstalled with the Windows 7 operating system from Lenovo. • If the Password Vault icon in the Lenovo ThinkVantage Tools program is dimmed, it indicates that you need to install the ThinkVantage Password Manager program manually before enabling its features. To install the ThinkVantage Password Manager program, do the following: 1.
Page 19: Adobe Reader
The Adobe Reader program is a tool used to view, print, and search PDF documents. Antivirus software Your computer comes with antivirus software that you can use to detect and eliminate viruses. Lenovo provides a full version of antivirus software on your hard disk drive with a free 30-day subscription. After 30 days, you must renew the license to continue receiving the antivirus program updates.
Page 20: Locating Connectors, Controls, And Indicators On The Front Of Your Computer
Locating connectors, controls, and indicators on the front of your computer Figure 1 “Front connector, control, and indicator locations” on page 8 shows the locations of the connectors, controls, and indicators on the front of your computer. Figure 1. Front connector, control, and indicator locations Hard disk drive activity indicator Power indicator Power switch...
Page 21: Locating Connectors On The Rear Of Your Computer
Locating connectors on the rear of your computer Figure 2 “Rear connector locations” on page 9 shows the locations of the connectors on the rear of your computer. Some connectors on the rear of your computer are color-coded to help you determine where to connect the cables on your computer.
Page 22 Connector DVI monitor connector Used to attach a DVI monitor or other devices that use a DVI monitor connector. Ethernet connector Used to attach an Ethernet cable for a local area network (LAN). Note: To operate the computer within FCC Class B limits, use a Category 5 Ethernet cable.
Page 23: Locating Components
Locating components Figure 3 “Component locations” on page 11 shows the locations of the various components in your computer. To remove the computer cover, see “Removing the computer cover” on page 32. Figure 3. Component locations Heat sink and fan assembly Microprocessor Memory modules Front bezel...
Page 24: Locating Parts On The System Board
Locating parts on the system board Figure 4 “System board part locations” on page 12 shows the locations of the parts on the system board. Figure 4. System board part locations 4-pin power connector Microprocessor Microprocessor fan connector Memory slot 1 (DIMM1) Memory slot 2 (DIMM2) Thermal sensor connector 24-pin power connector...
Page 25: Locating Internal Drives
Locating internal drives Internal drives are devices that your computer uses to read and store data. You can add drives to your computer to increase storage capacity and enable your computer to read other types of media. Internal drives are installed in bays. In this manual, the bays are referred to as bay 1, bay 2, and so on. When installing or replacing an internal drive, it is important to note the type and size of the drive that you can install or replace in each bay and correctly connect the cables to the drive installed.
Page 26: Machine Type And Model Label
Machine type and model label The machine type and model label identifies your computer. When you contact Lenovo for help, the machine type and model information helps support technicians to identify your computer and provide faster service. The following is a sample of the machine type and model label.
Page 27: Chapter 2. Using Your Computer
“Creating recovery media” on page 59. Additionally, in case of a hard disk failure, you can order Product Recovery discs from the Lenovo Customer Support Center. For information about contacting the Customer Support Center, see Chapter 11 “Getting information, help, and service”...
Page 28: Using A Fingerprint Reader
To open the ThinkVantage Fingerprint Software program and use the fingerprint reader, do one of the following: • On the Windows 7 operating system, click Start ➙ All Programs ➙ Lenovo ThinkVantage Tools ➙ Fingerprint Reader. • On the Windows Vista operating system, click Start ➙ All Programs ➙ ThinkVantage ➙ ThinkVantage Fingerprint Software.
Page 29: Setting The Volume From The Desktop
Setting the volume from the desktop The desktop volume control is accessible through the volume icon in the taskbar, which is located at the bottom-right corner of the Windows desktop. Click the volume icon and move the slider up or down to control the volume, or click the Mute icon to turn the audio off.
Page 30: Handling And Storing Cd And Dvd Media
If your computer comes with a recordable DVD drive, you can use the drive to record CDs or DVDs. To record a CD or DVD, do the following: 1. Click Start ➙ All Programs ➙ Corel DVD MovieFactory Lenovo Edition. 2. Follow the instructions on the screen.
Page 31 For detailed information about using the Corel DVD MovieFactory program, see the help system for the program. You can also use Windows Media Player to record CDs and data DVDs. For more information, see “Help and Support” on page 103. Chapter 2 Using your computer...
Page 32 ThinkCentre User Guide...
Page 33: Chapter 3. You And Your Computer
The following topics provide information about arranging your work area, setting up your computer equipment, and establishing healthy work habits: Lenovo is committed to providing people with disabilities greater access to information and technology. As a result, the following information provides ways to help users that have hearing, vision, and mobility limitations get the most out of their computer experience.
Page 34: Glare And Lighting
Adjust the monitor so the top of the screen is at, or slightly below, eye level. Place the monitor at a comfortable viewing distance, usually 51 to 61 cm (20 to 24 inches), and position it so you can view it without having to twist your body.
Page 35: Register Your Computer With Lenovo
Registering your computer also enables Lenovo to notify you about possible technical information and upgrades. When you register your computer, information is entered into a database, which enables Lenovo to contact you in case of a recall or other severe problem. In addition, some locations offer extended privileges and services to registered users.
Page 36: Replacement Power Cords
If you relocate your computer to a country or region that uses an electrical outlet style different from the type you are currently using, you will have to purchase either electrical plug adapters or new power cords. You can order power cords directly from Lenovo. For power cord information and part numbers, go to: http://www.lenovo.com/powercordnotice...
Page 37: Chapter 4. Security
Your computer is able to log in to the operating system without keyboard or mouse connected. • Trusted Platform Module (TPM) Trusted Platform Module is a secure cryptoprocessor that can store cryptographic keys that protect information stored in your computer. © Copyright Lenovo 2011...
Page 38: Locking The Computer Cover
Locking the computer cover Locking the computer cover helps prevent unauthorized people from gaining access to the inside of your computer. Your computer comes with a padlock loop so that the computer cover cannot be removed when a padlock is installed. Figure 7.
Page 39: Attaching An Integrated Cable Lock
The cable lock also locks the buttons used to open the computer cover. This is the same type of lock used with many notebook computers. You can order an integrated cable lock directly from Lenovo by searching for Kensington at: http://www.lenovo.com/support Figure 8.
Page 40: Windows Passwords
Your computer is preinstalled with an antivirus program to help you guard against, detect, and eliminate viruses. Lenovo provides a full version of antivirus software on your computer with a free 30-day subscription. After 30 days, you must renew the license to continue receiving the antivirus software updates.
Page 41 For more information about how to use your antivirus software, refer to the help system of your antivirus software. Chapter 4 Security...
Page 42 ThinkCentre User Guide...
Page 43: Chapter 5. Installing Or Replacing Hardware
Attention: Do not open your computer or attempt any repair before reading and understanding the “Important safety information” on page v. Notes: 1. Use only computer parts provided by Lenovo. 2. When installing or replacing an option, use the appropriate instructions in this section along with the instructions that come with the option.
Page 44: Removing The Computer Cover
Removing the computer cover Attention: Do not open your computer or attempt any repair before reading and understanding the “Important safety information” on page v. This section provides instructions on how to remove the computer cover. CAUTION: Turn off the computer and wait three to five minutes to let the computer cool before removing the computer cover.
Page 45 This section provides instructions on how to remove and reinstall the front bezel. To remove and reinstall the front bezel, do the following: 1. Turn off the computer and disconnect all power cords from electrical outlets. 2. Remove the computer cover. See “Removing the computer cover” on page 32. 3.
Page 46: Installing Or Replacing A Pci Card
4. To reinstall the front bezel, align the three plastic tabs on the right side of the front bezel with the corresponding holes in the chassis, then pivot the front bezel inwards until it snaps into position on the left side. Figure 11.
Page 47 3. At the rear of the computer, remove the screw that secures the PCI card latch. Figure 12. Removing the screw that secures the PCI card latch 4. Depending on whether you are installing or replacing a PCI card, do one of the following: •...
Page 48 Figure 13. Removing the PCI card Notes: a. The card fits tightly into the card slot. If necessary, alternate moving each side of the card a small amount until it is removed from the card slot. b. If the card is held in place by a retaining latch, press the card retaining latch disengage the latch.
Page 49: Installing Or Replacing A Memory Module
7. Pivot the card latch to the closed position to secure the PCI card. Figure 14. Installing a PCI card 8. Reinstall the screw to secure the PCI card latch in place. What to do next: • To work with another piece of hardware, go to the appropriate section. •...
Page 50 6. Depending on whether you are installing or replacing a memory module, do one of the following: • If you are replacing an old memory module, open the retaining clips and gently pull the memory module out of the memory slot. Figure 15.
Page 51: Installing Or Replacing The Optical Drive
7. Position the new memory module over the memory slot. Make sure that the notch module aligns correctly with the slot key down into the slot until the retaining clips close. Figure 17. Installing a memory module 8. Reinstall the PCI Express x16 graphics card if you have removed it. What to do next: •...
Page 52 4. Remove the three screws that secure the optical drive. Then, slide the optical drive out of the front of the computer. Figure 18. Removing the optical drive 5. Slide the new optical drive into the drive bay from the front and align the screw holes in the new optical drive with the corresponding holes in the drive bay.
Page 53: Replacing The Battery
6. Connect one end of the signal cable to the rear of the new optical drive and the other end to an available SATA connector on the system board. See “Locating parts on the system board” on page 12. Then, locate an available five-wire power connector and connect it to the rear of the new optical drive.
Page 54: Replacing The Heat Sink And Fan Assembly
5. Install a new battery. Figure 22. Installing a new battery 6. Reinstall the computer cover and connect the cables. See “Completing the parts replacement” on page 56. Note: When the computer is turned on for the first time after replacing the battery, an error message might be displayed.
Page 55 6. Follow this sequence to remove the four screws that secure the heat sink and fan assembly to the system board: a. Partially remove screw b. Partially remove screw Note: Carefully remove the four screws from the system board to avoid any possible damage to the system board.
Page 56: Replacing The Power Supply Assembly
Replacing the power supply assembly Attention: Do not open your computer or attempt any repair before reading and understanding the “Important safety information” on page v. This section provides instructions on how to replace the power supply assembly. Although there are no moving parts in your computer after the power cord has been disconnected, the following warnings are required for your safety and proper Underwriters Laboratories (UL) certification.
Page 57: Replacing The Microprocessor
8. Install and tighten the four screws to secure the power supply assembly. Note: Use only screws provided by Lenovo. 9. Reconnect the power supply assembly cables to the system board and each of the drives.
Page 58 This section provides instructions on how to replace the microprocessor. CAUTION: The heat sink and microprocessor might be very hot. Turn off the computer and wait three to five minutes to let the computer cool before removing the computer cover. To replace the microprocessor, do the following: 1.
Page 59 Figure 26. Removing the microprocessor Notes: a. Your microprocessor and socket might look different from the one illustrated. b. Note the orientation of the microprocessor in the socket. You can either look for the small triangle on one corner of the microprocessor or note the orientation of the notches This is important when installing the new microprocessor on the system board.
Page 60: Installing The Solid State Drive
11. Lower the new microprocessor straight down into the microprocessor socket on the system board. Figure 27. Installing the microprocessor 12. Close the microprocessor retainer and lock it into position with the small handle to secure the new microprocessor in the socket. 13.
Page 61: Replacing The Primary Hard Disk Drive
1. Install the solid state drive into the storage converter. Then, install the 4 screws to secure the solid state drive to the storage converter. Figure 28. Installing the solid state drive into the storage converter 2. Connect the signal cable and the power cable to the solid state drive. 3.
Page 62 5. Remove the four screws that secure the hard disk drive. Then, slide the hard disk drive out of the chassis. Figure 29. Removing the hard disk drive ThinkCentre User Guide...
Page 63: Replacing The Rear Fan Assembly
6. Slide the new hard disk drive into the hard disk drive bay and align the screw holes in the new hard disk drive with the corresponding holes in the drive bay. Then, install the four screws to secure the new hard disk drive in place.
Page 64 This section provides instructions on how to replace the rear fan assembly. To replace the rear fan assembly, do the following: 1. Turn off the computer and disconnect all power cords from electrical outlets. 2. Remove the computer cover. See “Removing the computer cover” on page 32. 3.
Page 65: Replacing The Front Audio And Usb Assembly
7. Pull on the tips of the rubber mounts until the rear fan assembly is secured in place. Figure 33. Installing the rear fan assembly 8. Connect the rear fan assembly cable to the system fan connector on the system board. What to do next: •...
Page 66: Replacing The Keyboard
6. Remove the screw that secures the front audio and USB assembly bracket to the chassis to remove the bracket from the chassis. Figure 34. Removing the screw that secures the front audio and USB assembly to the chassis 7. Remove the two screws that secure the front audio and USB assembly to its bracket and remove the failing front audio and USB assembly from the bracket.
Page 67: Replacing The Mouse
4. Connect a new keyboard to the appropriate connector on the computer. Your keyboard might be connected to a PS/2 keyboard connector to connect your keyboard, see “Locating connectors, controls, and indicators on the front of your computer” on page 8 or “Locating connectors on the rear of your computer” on page 9. Figure 35.
Page 68: Completing The Parts Replacement
What to do next: • To work with another piece of hardware, go to the appropriate section. • To complete the replacement, go to “Completing the parts replacement” on page 56. Completing the parts replacement After completing the installation or replacement for all parts, you need to reinstall the computer cover and reconnect cables.
Page 69: Obtaining Device Drivers
9. To update your configuration, refer to Chapter 7 “Using the Setup Utility program” on page 67. Note: In most areas of the world, Lenovo requires the return of the defective Customer Replaceable Unit (CRU). Information about this will come with the CRU or will come a few days after the CRU arrives.
Page 70 ThinkCentre User Guide...
Page 71: Chapter 6. Recovery Information
Recovery program or the Product Recovery program installed. If the Enhanced Backup and Restore icon in the Lenovo ThinkVantage Tools program is dimmed, it indicates that you need to install the Rescue and Recovery program manually before enabling its features. To install the Rescue and Recovery program, do the following: a.
Page 72: Using Recovery Media
“creating Product Recovery discs.” • To create recovery media on the Windows 7 operating system, click Start ➙ All Programs ➙ Lenovo ThinkVantage Tools ➙ Factory Recovery Disks. Then, follow the instructions on the screen.
Page 73: Performing A Recovery Operation
• To perform a backup operation using the Rescue and Recovery program on the Windows 7 operating system, do the following: 1. From the Windows desktop, click Start ➙ All Programs ➙ Lenovo ThinkVantage Tools ➙ Enhanced Backup and Restore. The Rescue and Recovery program opens.
Page 74: Creating And Using A Rescue Medium
• To create a rescue medium on the Windows 7 operating system, do the following: 1. From the Windows desktop, click Start ➙ All Programs ➙ Lenovo ThinkVantage Tools ➙ Enhanced Backup and Restore. The Rescue and Recovery program opens.
Page 75: Using A Rescue Medium
Reinstalling preinstalled applications This section provides instructions on how to reinstall preinstalled applications. To reinstall the selected applications preinstalled on your Lenovo computer, do the following: 1. Turn on the computer. 2. Use Windows Explorer or Computer to display the directory structure of your hard disk drive.
Page 76: Reinstalling Software Programs
• To reinstall most commercially available programs in your system, see Microsoft Windows help system for more information. • To reinstall selected application programs that came preinstalled from Lenovo, do the following: 1. Turn on the computer. 2. Use Windows Explorer or Computer to display the directory structure of your hard disk drive.
Page 77: Reinstalling Device Drivers
5. Open the appropriate application subfolder. 6. In the application subfolder, look for a SETUP.EXE file or other appropriate EXE files for setup. Double-click the file and follow the instructions on the screen to complete the installation. Reinstalling device drivers To reinstall a device driver for an option you installed, refer to the documentation that comes with the option.
Page 78 ThinkCentre User Guide...
Page 79: Chapter 7. Using The Setup Utility Program
• Administrator Password • Hard Disk Password You do not have to set any passwords to use your computer. However, using passwords improves computing security. If you decide to set any passwords, read the following sections. © Copyright Lenovo 2011...
Page 80: Password Considerations
Password considerations A password can be any combination of up to 64 alphabetic and numeric characters. For security reasons, it is recommended to use a strong password that cannot be easily compromised. To set a strong password, use the following guidelines: •...
Page 81: Erasing Lost Or Forgotten Passwords (Clearing Cmos)
Note: A password can be any combination of up to 64 alphabetic and numeric characters. For more information, see “Password considerations” on page 68. Erasing lost or forgotten passwords (clearing CMOS) This section provides instructions on how to erase lost or forgotten passwords, such as a user password. To erase a lost or forgotten password, do the following: 1.
Page 82: Selecting A Startup Device
Selecting a startup device If your computer does not start up from a device such as the disc or hard disk drive as expected, do one of the following to select the startup device you want. Selecting a temporary startup device Use this procedure to select a temporary startup device.
Page 83: Exiting From The Setup Utility Program
• Pressing the power switch • Enabling the wake up on alarm feature The wake up on alarm feature enables your computer to wake up at a set time. To enable the wake up on alarm feature, do the following: 1.
Page 84 ThinkCentre User Guide...
Page 85: Chapter 8. Updating System Programs
Utility program by starting your computer with a system-program-update disc or running a special update program from your operating system. Lenovo might make changes and enhancements to the POST and BIOS. When updates are released, they are available as downloadable files on the Lenovo Web site at http://www.lenovo.com. Instructions for using the POST and BIOS updates are available in a TXT file that is included with the update files.
Page 86: Updating (Flashing) The Bios From Your Operating System
Updating (flashing) the BIOS from your operating system Note: Because Lenovo makes constant improvements to its Web sites, the Web page contents are subject to change without notice, including the contents referenced in the following procedure. To update (flash) the BIOS from your operating system, do the following: 1.
Page 87 14. Turn on the computer to restart the operating system. Chapter 8 Updating system programs...
Page 88 ThinkCentre User Guide...
Page 89: Chapter 9. Preventing Problems
Attention: Do not download updated device drivers from the Windows Update Web site. The device drivers provided on the Windows Web site have not been tested by Lenovo and using them might cause unexpected problems. Obtain updated device drivers from Lenovo.
Page 90: Using System Update
The System Update program helps you keep the software on your computer up-to-date. Update packages are stored on Lenovo servers and can be downloaded from the Lenovo Support Web site. Update packages can contain applications, device drivers, BIOS flashes, or software updates. When the System Update...
Page 91: Cleaning Your Computer
• Do not place items on top of the monitor or cover any of the vents in the monitor or computer. These vents provide airflow to keep your computer from overheating. • Keep food and drinks away from all parts of your computer. Food particles and spills might make the keyboard and mouse stick and unusable.
Page 92: Good Maintenance Practices
A log book can help you or a Lenovo technician determine if a problem is related to change in hardware, change in software, or some other action that might have taken place.
Page 93 1. Back up all files and data from the hard disk drive. There are a variety of backup programs available commercially. Your operating system also might have a backup program that you can use. Lenovo provides the Rescue and Recovery program to help you back up and restore data. See “Performing backup and recovery operations”...
Page 94 ThinkCentre User Guide...
Page 95: Chapter 10. Troubleshooting And Diagnostics
Note: If you cannot correct the problem, have the computer serviced. For a list of service and support telephone numbers, refer to the ThinkCentre Safety and Warranty Guide that comes with your computer or go to the Lenovo Support Web site at http://www.lenovo.com/support/phone. Symptom...
Page 96: Troubleshooting Procedure
See Chapter 11 “Getting information, help, and service” on page 103 for more information. • If you are unable to run the diagnostic programs, contact the Lenovo Customer Support Center. See Chapter 11 “Getting information, help, and service” on page 103 for more information.
Page 97: Audio Problems
1. Remove the new hardware option or software. If you must remove the computer cover to remove a hardware option, make sure you review and follow the electrical safety information provided with your computer. For your safety, do not operate the computer with the cover removed. 2.
Page 98: Cd Problems
Note: When external-speaker or headphone cables are attached to the audio connector, the internal speaker, if present, is disabled. In most cases, if an audio adapter is installed in one of the expansion slots, the audio function built into the system board is disabled; use the audio jacks on the adapter. •...
Page 99: Dvd Problems
An audio disc or AutoPlay-enabled disc does not automatically play when it is inserted into a CD drive Symptom: An audio disc or AutoPlay-enabled disc does not automatically play when it is inserted into a CD drive. Actions: • If you have multiple CD or DVD drives installed (or a combination of CD and DVD drives), try inserting the disc into the other drive.
Page 100 Symptom: Playback is very slow or choppy. Actions: • Disable any background programs, such as AntiVirus or Desktop Themes. • Ensure that video resolution is set to less than 1152 x 864. If these actions do not correct the problem, run the diagnostic programs (see “Diagnostic programs” on page 100 for instructions).
Page 101: Intermittent Problems
• Ensure that a DVD disc is in the drive with the shiny side of the disc facing down. • Ensure that video resolution is set to less than 1152 x 864. • On computers that have a CD-ROM or CD-RW drive in addition to a DVD-ROM drive, make sure that the DVD disc is in the drive labeled “DVD”.
Page 102 1. Click Start ➙ Control Panel. 2. Click Hardware and Sound. 3. Click Devices and Printers. 4. Double-click USB Enhanced Performance Keyboard. The USB Enhanced Performance Keyboard Customization program starts. If these actions do not correct the problem, have the computer and keyboard serviced. See Chapter 11 “Getting information, help, and service”...
Page 103: Monitor Problems
• The wireless Keyboard is located less than ten meters away from the transceiver. • The transceiver is fully installed. Action: If the Transceiver Communications LED is not on, reconnect the transceiver and the keyboard. Monitor problems Note: Many monitors have status-indicator lights and built-in controls for adjusting brightness, contrast, width, height, and other picture adjustments.
Page 104: Networking Problems
If these actions do not correct the problem, run the diagnostic programs (see “Diagnostic programs” on page 100 for instructions). If you need technical assistance, see Chapter 11 “Getting information, help, and service” on page 103. The image appears to be flickering Symptom: The image appears to be flickering.
Page 105: Ethernet Problems
• “Bluetooth problems” on page 94 For more information, see “Help and Support” on page 103. Ethernet problems For Ethernet problems, select your symptom from the following list: • “Your computer cannot connect to the network” on page 93 • “The adapter stops working for no apparent reason”...
Page 106: A Wireless Lan Problem
Actions: • Make sure that WOL is enabled in the BIOS Setup Utility program. • If it is, check with your LAN administrator for the necessary settings. If your computer is a Gigabit Ethernet model and you use a speed of 1000 Mbps, the connection fails or errors occur Symptom: If your computer is a Gigabit Ethernet model and you use a speed of 1000 Mbps, the connection fails or errors occur.
Page 107: Option Problems
Windows Vista operating system might be saved as a file with the extension .contact. Option problems Use this information to diagnose problems with Lenovo hardware options that do not have their own troubleshooting information. Select your symptom from the following list: •...
Page 108: Performance And Lockup Problems
An option that previously worked does not work now Symptom: An option that previously worked does not work now. Actions: • Verify that all option hardware and cable connections are secure. • If the option comes with its own test instructions, use those instructions to test the option. •...
Page 109 – 1. Click Start ➙ Control Panel. 2. Click Programs. 3. Click Turn Windows features on or off. 4. A list of optional Windows components is displayed. Follow the instructions on the screen. – 1. Click Start ➙ Computer. 2. Right-click your C drive entry and then click Properties. 3.
Page 110: Printer Problems
Action: Run the Windows Disk Defragmenter program. Note: Depending on the size of the hard disk drive and amount of data currently stored on the hard disk drive, the disk defragmentation process might take up to several hours to complete. •...
Page 111: Serial Port Problems
If the problem persists, run the tests described in the documentation that comes with your printer. If you cannot correct the problem, have the computer serviced. See Chapter 11 “Getting information, help, and service” on page 103. Serial port problems Use this information to troubleshoot the serial port and devices attached to the serial port.
Page 112: Usb Problems
– Your computer has the minimum memory requirements needed to use the software. See the information supplied with the software to verify memory requirements. (If you just installed an adapter or memory, you might have a memory-address conflict.) – The software is designed to operate on your computer. –...
Page 113: Lenovo Solution Center
3. If you are unable to isolate and repair the problem yourself after running the programs, save and print the log files created by the programs. You will need the log files when you speak to a Lenovo technical support representative.
Page 114: Creating A Diagnostic Disc
1. Download a self-starting bootable CD/DVD image (known as an ISO image) of the diagnostic program from: http://www.lenovo.com/support 2. Use any CD/DVD burning software to create a diagnostic disc with the ISO image. Running the diagnostic program from a diagnostic disc This section provides instructions on how to run the diagnostic program from a diagnostic disc that you created.
Page 115: Chapter 11. Getting Information, Help, And Service
You can use the information in this section to access useful resources relating to your computing needs. Lenovo ThinkVantage Tools The Lenovo ThinkVantage Tools program guides you to a host of information sources and provides easy access to various tools to help you work more easily and securely.
Page 116: Lenovo Support Web Site
Most computers come with a set of diagnostic programs that help you identify hardware problems. For instructions on using the diagnostic programs, see “Diagnostic programs” on page 100. You can also get the latest technical information and download device drivers and updates from Lenovo Support Web site at: http://www.lenovo.com/support...
Page 117: Using Other Services
These items are not covered by the warranty: • Replacement or use of parts not manufactured for or by Lenovo or non-warranted Lenovo parts • Identification of software problem sources • Configuration of BIOS as part of an installation or upgrade •...
Page 118 ThinkCentre User Guide...
Page 119: Appendix A. Notices
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead.
Page 120: Trademarks
Trademarks The following terms are trademarks of Lenovo in the United States, other countries, or both: Lenovo The Lenovo logo Rescue and Recovery ThinkCentre ThinkVantage Microsoft, Windows, and Windows Vista are trademarks of the Microsoft group of companies. Intel, Intel Core, Celeron, and Pentium are trademarks of Intel Corporation in the United States, other countries, or both.
Page 121: Appendix B. Regulatory Information
• Consult an authorized dealer or service representative for help. Lenovo is not responsible for any radio or television interference caused by using other than specified or recommended cables and connectors or by unauthorized changes or modifications to this equipment.
Page 122 Geräte der Klasse B. Dieses Gerät ist berechtigt, in Übereinstimmung mit dem Deutschen EMVG das EG-Konformitätszeichen - CE - zu führen. Verantwortlich für die Konformitätserklärung nach Paragraf 5 des EMVG ist die Lenovo (Deutschland) GmbH, Gropiusplatz 10, D-70563 Stuttgart. ThinkCentre User Guide...
Page 123: Additional Regulatory Information
Depending on the configuration of your computer and the country or region where the computer was purchased, you might have received additional printed regulatory notices. All regulatory notices are available on the Lenovo Support Web site in electronic format. To access electronic copies of the documentation, go to http://www.lenovo.com/support and click User Guides and Manuals.
Page 124 ThinkCentre User Guide...
Page 125: Appendix C. Weee And Recycling Statements
Lenovo encourages owners of information technology (IT) equipment to responsibly recycle their equipment when it is no longer needed. Lenovo offers a variety of programs and services to assist equipment owners in recycling their IT products. For information on recycling Lenovo products, go to: http://www.lenovo.com/recycling...
Page 126: Recycling Information For Brazil
If you want to replace it with a new one, contact your place of purchase or ask for a repair service provided by Lenovo. If you have replaced it by yourself and want to dispose of the disused lithium battery, insulate it with vinyl tape, contact your place of purchase, and follow their instructions.
Page 127: Battery Recycling Information For The European Union
Customer participation is important to minimize any potential effects of batteries and accumulators on the environment and human health due to the potential presence of hazardous substances. For proper collection and treatment, go to: http://www.lenovo.com/lenovo/environment Appendix C. WEEE and recycling statements...
