- Page 1 18V CORDLESS IMPACT WRENCH TYPE18 ORIGINAL INSTRUCTION MANUAL For use with all variants of KWT-085 Cordless Impact Wrench K I E L D E R 1 8 V B AT T E RY S Y S T E M www.kielder.co...
- Page 2 KWT-085-IMB22 Kielder WT Ltd...
- Page 3 EN 60745-2-2:2010 EN 55014-1:2006+A1:2009+A2:2011 Tel: 0114 242 3794 EN 55014-2:1997+A1:2001+A2:2008 Email: tools@kielder.co All documentation is held in KWT-085 Technical File and is available, on request for review. Intended Use Authorised Signatory: The tool is intended for the fastening and Steven Bulloss unfastening of threaded bolts and nuts.
- Page 4 • If devices are provided for the connection rate for which they were intended. of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards. KWT-085-IMB22 Kielder WT Ltd...
- Page 5 Service are caused by poorly maintained power tools. Have your power tool serviced or repaired by Kielder or a qualified technician using • Keep cutting tools sharp and clean. only identical replacement parts. This will Properly maintained cutting tools with...
- Page 6 • Secure the workpiece. A workpiece pay attention to these additional instructions: is held more securely in a vice than by hand. • Always wait until the tool has stopped KWT-085-IMB22 Kielder WT Ltd...
- Page 7 • Do not use other than the Kielder battery packs that are designed for use with this rechargeable tool. Li-Ion • Kielder is not responsible for any damage or...
- Page 8 Friction Ring (11) Battery Release Button Square Drive Shoulder (12) Battery; attached to tool Forward / Reverse / Lock Selector (13) Charger Trigger (14) Battery Insert Slide Hand Grip (15) Charging Indicator Belt Clip Speed Selector KWT-085-IMB22 Kielder WT Ltd...
- Page 9 Conforms to CE Wear Hearing Protection standard Revolutions Per Minute Do not burn or Wear Safety Glasses incinerate Electrical Capacity Wear Vibration Absorbing Maximum safe ambient Class II construction Gloves temperature for battery (double insulated) MAX 45ºC Kielder WT Ltd KWT-085-IMB22...
- Page 10 Slide the battery pack until it locks into against the square drive shoulder (C) position with an audible “CLICK”. To further secure the socket, your Kielder Impact Wrench is equipped with a friction ring (D). The rubber ring keeps the socket on the square drive and makes it easier to remove.
- Page 11 • The brake operates and tool stops immediately when the trigger is released. • After use, move the lever to the centre (I), this is the trigger lock position and how the tool should be stored. Kielder WT Ltd KWT-085-IMB22...
- Page 12 If this happens, check BEAM the battery power remaining by pressing – LED lights are very bright and the small circular button (J) on the indicator may cause injury to the eye. panel and charge the battery pack accordingly. KWT-085-IMB22 Kielder WT Ltd...
- Page 13 • Do not store the battery pack in locations where the temperature may reach or exceed 45°C. • Do not incinerate the battery pack even if it is severely damaged or is completely worn out. The battery pack can explode in a fire. Kielder WT Ltd KWT-085-IMB22...
- Page 14 If any dirt is found on the pack to cool down before recharging. This terminals clean the terminals before will allow the battery to be recharged to its charging the battery pack. full capacity. KWT-085-IMB22 Kielder WT Ltd...
- Page 15 • Once charging is complete slide the original, have the charger tested by a battery out of the charger, disconnect the qualified person. charger from power supply and store. Kielder WT Ltd KWT-085-IMB22...
- Page 16 CHART fouled in some way. 1 & CHART 2, with the torque curve flattening between 10 and around 20 KWT-085 MODEL seconds depending on application. Torque (Nm) Threaded Fastening Standard Tensile • For stubborn fastenings such as rusted...
- Page 17 • If the inside of the tool or battery pack is exposed to water, drain and allow to dry thoroughly as soon as possible. If you experience any problems when operating the tool, contact Kielder WT. Kielder WT Ltd KWT-085-IMB22...
- Page 18 • Use of the machine in the UK only, overseas Why is Registration a Requirement? users should contact the official importer or For Kielder to be able to fully support & retailer for that country. service a product warranty over a 3 year...
- Page 19 Kielder WT Ltd KWT-085-IMB22...
- Page 20 KWT-085-IMD22 Kielder WT Ltd Kielder K I E L D E R W O R K S T E A M Kielder WT Ltd Sheffield, UK T: +44 (0)114 242 3794 E: tools@kielder.co W: http://www.kielder.co Kielder Tools Registered in England & Wales: 09426163...
