Kaba Saflok SYSTEM 6000 Reference Manual page 91

TM
System 6000 Reference Manual_Section 5
Programming and Interrogating Locks (continued)
The handheld will then display the following menu:
Hand Held Terminal options explained
Using the arrow down key will scroll down to additional functions on
the menu screen. Below are two other screens with options they
display:
Option 3. Update locks clock (Used for updating the clock in the lock)
Option 4. Interrogate Locks (Used to extract all the keys used in the
lock)
Option 5. Lock vers/LED Diag (Used to display version and diagnose
key problems)
13. Take the terminal and probe to the lock. Select 2 and enter to
bring up the Program Lock screen shown. This screen will display all
the locks that have been downloaded into the unit
Note: Only four rooms can be displayed on each screen. To select a room number, type the number that appears
in front of the room to be programmed then press enter. To display additional rooms in memory, type 0 then
enter.
© SAFLOK
06-16-11 11:01A
1. Reconnect to PC
2. Program Lock
Select choice ?
06-16-11 11:01A
3. Update Lock Clock
4. Interrogate Locks
Select choice
06-16-11 11:01A
4. Interrogate Locks
5. Lock Vers/LED Diag
Select choice
S005: Program Lock
1. 101
2. 104
enter 1-2 (0=More) 0
Page 16 of 24
STD
STD
STD
06/11
