BD-HDMI-RF
Encoder modulator
User's manual V1.0
BD-HDMI-RF Series
Encoder + Modulator
User's Manual
V1.0
SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Website:
http://www.baudcom.com.cn
Email:
info@baudcom.com.cn
Tel: +86 21 37709251
Fax: +86 21 37709302
1 / 18

Advertisement

loading
Need help?

Need help?

Do you have a question about the BD-HDMI-RF Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Baudcom BD-HDMI-RF Series

  • Page 1 BD-HDMI-RF Encoder modulator User’s manual V1.0 BD-HDMI-RF Series Encoder + Modulator User’s Manual V1.0 SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD Website: http://www.baudcom.com.cn Email: info@baudcom.com.cn Tel: +86 21 37709251 Fax: +86 21 37709302 1 / 18...
  • Page 2 BD-HDMI-RF Encoder modulator User’s manual V1.0 BD-HDMI-RF-24 BD-HDMI-RF-12 2 / 18...
  • Page 3: Product Overview

    User’s manual V1.0 1 Product Overview The BD-HDMI-RF series is the latest cost-effective HD encoder modulator. It supports 4 / 8 / 12 / 16 / 20 / 24 channels HDMI input, 1 channel Gigabit IP input / output; 4 channel(ATSC, ISDBT, DTMBT, DVB-C/-T) output, 4 MPTS or SPTS output.
  • Page 4 BD-HDMI-RF Encoder modulator User’s manual V1.0 3 Specifications Input HDMI(4/8/12/16/20/24 HDMI) 2*ASI input RF output 4 frequencies(DVB-C/DVB-T/ATSC/ISDBT/DMBT) Output 2*ASI output IP output, SPTS/ MPTS Video Encode Format MPEG-4 AVC/H.264 Encoding Input port HDMI Input 1920×1080P/1920×1080i/1280×720P/720x576i/ Resolution 720x480i @50/59.94Hz Output 1920×1080_30P,1920×1080_30P,1280×720_30P, Resolution 720x576_25P,720x480_25P 1Mbps~13Mbps(each channel)
  • Page 5 BD-HDMI-RF Encoder modulator User’s manual V1.0 4 Outlook Front pannel: RF Out LCD Display Indicator lights Bottons ASI In ASI OUT NMS、DATA Input/ output Rear Pannel: HDMI input Power switch Power socket 5 / 18...
  • Page 6 BD-HDMI-RF Encoder modulator User’s manual V1.0 6 / 18...
  • Page 7: Web Management

    BD-HDMI-RF Encoder modulator User’s manual V1.0 6 Web Management 6.1 Description The device is connected to the input signal, connected to the power supply, and the equipment is controlled through the browser after the equipment starts normally. Web Management is for the control, managing and settings of the digital headend equipment.
  • Page 8 BD-HDMI-RF Encoder modulator User’s manual V1.0 6.2.4 Band menu,(L1L2L3)Indicates the state of each type of panel for the first, second, and third boards of the lower rear panel (4 interfaces for each board). H1H2H3 indicates the first, second, and third boards of the upper layer of the rear panel (4 interfaces each).
  • Page 9 BD-HDMI-RF Encoder modulator User’s manual V1.0 6.2.5 Program Mux menu(Mainly for the code program reuse, parameter modification and other settings) A. In the output window, at frequency point, click the program name and pop up the following window to modify the parameters of the program.
  • Page 10 BD-HDMI-RF Encoder modulator User’s manual V1.0 B. In the output window, click "Edit" on the right side of the frequency point, and the following window pops up to modify the parameters at that frequency point. 10 / 18...
  • Page 11 BD-HDMI-RF Encoder modulator User’s manual V1.0 C. Click on the right “MPTS” to output the MPTS program selection 11 / 18...
  • Page 12 BD-HDMI-RF Encoder modulator User’s manual V1.0 6.2.6 Output->Modulator Menu A. Click "Edit All" , pop up the following settings window, display the output frequency of the various parameters, to modify the 12 / 18...
  • Page 13 BD-HDMI-RF Encoder modulator User’s manual V1.0 required parameters. lick "Edit" after Channel to control the output of this frequency point C. Two ASI outputs that can be output by selecting a stream on any frequency point 6.2.7 Output->Network ,Network communication parameters of equipment 13 / 18...
  • Page 14 BD-HDMI-RF Encoder modulator User’s manual V1.0 6.2.8 MPTS output A. MPTS output,Output protocol B. MPTS output,address parameter,click "Edit All" 6.2.9 SPTS output 14 / 18...
  • Page 15 BD-HDMI-RF Encoder modulator User’s manual V1.0 multi-modulation selection output 6.2.10 Selected modulation mode output,New modulation will work after device reboot 15 / 18...
  • Page 16 BD-HDMI-RF Encoder modulator User’s manual V1.0 Existing modulation modes in output devices Equipment upgrade 6.2.11 A. Upgrade-> device modulation mode 16 / 18...
  • Page 17 BD-HDMI-RF Encoder modulator User’s manual V1.0 B. Upgrade-> each card in the device 6.2.12 Save Menu Can be saved quickly from the top right of the page, click "Save Config" 17 / 18...
  • Page 18 BD-HDMI-RF Encoder modulator User’s manual V1.0 6.2.13 Date/time,No operation, only test 6.2.14 State information monitoring,No operation, only test 6.2.15 After the device parameter is modified, it must be saved so as not to set the device parameter again after the power is off 18 / 18...
