MODEL BD-E1-ETH
10/100Base T-E1 Converter
User's Reference Manual
SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD
Address : Room 1101,Building 31,Lane 1508,Mei jia bang Road,Songjiang district,Shanghai ,China.
Website:
http://www.baudcom.com.cn
Email:
info@baudcom.com.cn
Tel:
+86 21 37709251
Fax: +86 21 37709302
1
Advertisement
Table of Contents
Related Manuals for Baudcom BD-E1-ETH
Summary of Contents for Baudcom BD-E1-ETH
- Page 1 MODEL BD-E1-ETH 10/100Base T-E1 Converter User’s Reference Manual SHANGHAI BAUDCOM COMMUNICATION DEVICE CO.,LTD Address : Room 1101,Building 31,Lane 1508,Mei jia bang Road,Songjiang district,Shanghai ,China. Website: http://www.baudcom.com.cn Email: info@baudcom.com.cn Tel: +86 21 37709251 Fax: +86 21 37709302...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1 GENERAL INFORMATION 2 PRODUCT CHARACTERISTIC ENVIRONMENT REQUIREMENT 3.1 Power 3.2 Power consumption 3.3 E1 Interface 3.4 10/100Base-T Interface DIMENSIONS 5 CONFIGURATION AND OPERATION 5.1 Display of the front panel 5.2 Loop-back Button 5.3 Display of the rear panel 5.4 Dial code in the panel 5.5 Description of E1 connector PACKING... -
Page 3: General Information
1 GENERAL INFORMATION Model BD-E1-ETH is a single port E1 with Ethernet Bridging that provides high-speed LAN-to-WAN connectivity. Plugging directly into the 10/100Base-T port of a hub or LAN switch, the E1-ETH provides E1 access at connection data rates of 2.048 Mbps. The E1-ETH is an excellent choice for... -
Page 4: Environment Requirement
3 ENVIRONMENT REQUIREMENT The temperature requirement is not very strict, the device can be working well under terrible environment. working temperature: 0° C - 50° C relative humidity: 95%(without coagulation) No erosive and impregnant gas, no rising dust, no strong magnetic field disturbing 3.1 Power Adapting module power, voltage range can be wide, with strong ant-jamming... -
Page 5: 10/100Base-T Interface
Jitter tolerance : finer than G.742 and G.823 3.4 10/100Base-T Interface Rate: 10/100M, full/duplex auto-negotiation Protocol: Support IEEE 802.3, IEEE 802.1Q (VLAN) MAC Address Entiries: 4096 Entiries Total Memory Sizes: 64MBits SDRAM Physical interface: RJ45, support AUTO-MDIX 4. DIMENSIONS 210(W) ×... -
Page 6: Loop-Back Button
5.2 LED Indicator There are 7 indicator LED on front panel. From left to right is as following: Name Color Status Description flick E1 port has date receive and transmit green On/off E1 port has no date receive and transmit Flick/on Indicates Ethernet has connected yellow Ethernet has no connect... - Page 7 DIG: 10/100BASE-T Local loop-back, to check the opposite device and E1 circuit REM: E1 interface loop-back outward to test E1 line E1 line PATT: PBRS test. To produce and transmit the PBRS to the 10/100BASE input connector, and to check whether the output signal of the 10/100BASE accord with PBRS standard.
-
Page 8: Display Of The Rear Panel
Note: when the test LED on, the normal communication will be terminated During the PATT model testing, the circuit should be cycle by itself, otherwise, the PATT code can’t come back. 5.4 Display of the rear panel Rear panel（AC 220V） Real panel（DC -48V）... -
Page 9: Description Of E1 Connector
1 (clk1):E1 master clock and line clock set E1 clock set Clk1 Master (main clock) Slave (line clock) Note pls: during communicating, one master and one slave is necessary and the rate of the slave will follow the master 2 (clk2): LAN set Clock2 10/100M full/duplex auto-negotiation... -
Page 10: Packing
LAN Interface In the back panel there are two RJ45 jack, one is for DTE mode (MDI) the other is for DCE mode (MDIX), easy for you to use it 6 PACKING 6.1 Packing pattern The following are things listed in each package: E1-10/100BT Converter AC220V power wire User’s manual... -
Page 11: Malfunction Diagnoses And Elimination
6.2 Power Installing Power of AC220V/ DC-48V is suitable for the device. If the power of DC-48V is used, the positive and negative terminal can be optional because there is the self-test circuit for the polarity inside the device. 7 MALFUNCTION DIAGNOSES AND ELIMINATION When the device works well, the light of PWR and LNK should be on and DATA should be flick.on, and others should be off 7.1．Power failure... -
Page 12: Application
Press the PATT and REM buttons, (or make the opposite device loop back the LAN data), if the E1 line transmit has problem PTOK light off, it means transmission channel has problem. Press PATT on one device, E1 transmit has cycle line（like if PTOK ON, it means has SDH E1 cycle line has no cycle line;...
