- Page 1 User Guide 031-11204 Rev. 2 08/2022 1 of 9...
-
Page 2: About Your Product
About Your Product Product Overview The CUBE Tower Mobile Charging Station The Beacon AC Outlets Power Cord Winder Power Switch 20 Foot Power Cable Locking Casters 031-11204 Rev. 2 08/2022 2 of 9... - Page 3 About Your Product Product Overview The CUBE Tower Pre-Wired Mobile Charging Station The Beacon Cord Holder Cord Grommet USB-C Power Adapters Power Adapter Access Panel 20 Foot Power Cable Power Cord Winder Power Switch Locking Casters 031-11204 Rev. 2 08/2022...
- Page 4 125V, 12A. 60Hz Rating CTWR800 supports power adapters up to 180W each, or 1,440W total Charging CTWR800USBC comes equipped with 65W power adapters For the latest information, please visit bretford.com/warranty. Warranty Certifications ETL Listed to UL 62368-1 031-11204 Rev. 2 08/2022...
-
Page 5: Using Your Product
(“RESET"). The Beacon indicator light will turn on and confirm power to the CUBE Tower The Beacon At Bretford, we like to think The Beacon indicator light helps inspire learning in the classroom. When the unit is plugged in, The Beacon is turned on and your CUBE Tower is ready to use. - Page 6 CUBE Tower CUBE Tower Pre-Wired USB-C Cable The CUBE Tower Pre-Wired USB-C cables extend 5 feet from the unit. The cable holder at the top is intended to be used to rest the cords when not in use. The hooks at the bottom can be used to wrap the cords to help with organization and storage of the unit.
- Page 7 Using Your Product CUBE Tower Power Adapter Replacement (CUBE Tower Pre-Wired Only) The power adapters can be accessed through the side access panel by removing two screws, with a torx T25 head, at the top and side - right. See image for location. To remove an adapter, feed the cable from the outside of the CUBE Tower through the grommet.
- Page 8 Important Information Safety Notice • Product for indoor use only • Do not plug the unit in if the switch or power cord has been damaged. • For safety purposes, make sure all electrical components do not exceed the maximum load rating of 12 amps. •...
-
Page 9: Additional Resources
Additional Resources Contact Support Technical support is available by contacting Bretford Customer Care via phone, email or the web: Hours of Operation: M-F, 7:30am - 4:30pm CST Telephone: +1-800-521-9614 Email: customerservice@bretford.com Website: www.bretford.com/contact Bretford, CUBE, and CUBE Tower are trademarks or registered marks of Bretford Manufacturing, Inc.
