1819196COM
Fireplace / TV Stand
Date of Purchase ___ / ___ / ___
Lot Number:
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-800-489-3351 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.ameriwoodhome.com
WARNING
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
All manuals and user guides at all-guides.com
Easy
Assembly Difficulty Meter
Follow Ameriwood Home
You
Tube
B341819196COM0
Tough

Advertisement

loading
Need help?

Need help?

Do you have a question about the 1819196COM0 and is the answer not in the manual?

Questions and answers

Related Manuals for Ameriwood HOME 1819196COM0

Summary of Contents for Ameriwood HOME 1819196COM0

  • Page 1 Visit: www.ameriwoodhome.com Tough Assembly Difficulty Meter WARNING Follow Ameriwood Home - Unit can tip over causing severe injury or death. - Anchor unit to stud in wall (if instructed to). - Do Not allow children to climb on unit. Tube...

  • Page 2: Helpful Hints

    All manuals and user guides at all-guides.com Contact Us! Do NOT return this product! Contact our friendly customer service team first for help. Assembly Tips Call us! 1-800-489-3351 Monday-Friday 9am - 5pm CST Tube Visit ameriwoodhome.com to view the limited warranty valid in the U.S. and Canada. Helpful Hints PEOPLE NEEDED FOR ASSEMBLY: 1-2 ESTIMATED ASSEMBLY TIME: 1 HOUR...

  • Page 3: Before You Start

    All manuals and user guides at all-guides.com Before You Start Read through each step carefully and follow the proper order Separate and count all your parts and hardware Give yourself enough room for the assembly process Have the following tools: Flat Head Screwdriver, #2 Phillips Head Screwdriver and Hammer Caution: If using a power drill or power screwdriver for screwing, please be aware to slow down and stop when screw is tight.

  • Page 4: Board Identification

    All manuals and user guides at all-guides.com Board Identification Not actual size Left Panel Right Partition Right Panel Left Partition 31819323010 31819323040 31819323020 31819323030 Bottom Adjustable Shelf (x2) 31819323060 31819323050 31819323070 Partition Rail (x2) End Panel Rail (x2) Back (x2) 31819323100 31819323090 31819323080...
  • Page 5 All manuals and user guides at all-guides.com Board Identification Not actual size Foot (x4) TV Rail 31819323140 31819323150 ameriwoodhome.com Tube...

  • Page 6: Part List

    All manuals and user guides at all-guides.com Part List Actual Size (x12) (x12) (x18) (x12) (x16) (x12) #A22610 #A21660 #A53510 #A22620 #A22920 #A22910 cam bolt wood dowel angle bracket cam lock connector connector bolt (x12) (x39) (x8) #A23030 #A12120 #A80250 shelf support confirmat screw 7/16"...
  • Page 7 All manuals and user guides at all-guides.com STEP 1 Quick Assembly (x2) (x3) (x3) #A22620 #A21660 #A22920 Proper orientation of CAM LOCK You will need to tap the connector (4) with a hammer to fully insert. Be sure the connector is positioned as shown before tapping into hole.
  • Page 8 All manuals and user guides at all-guides.com STEP 2 Quick Assembly (x3) (x2) (x3) #A22620 #A21660 #A22920 Proper orientation of CAM LOCK You will need to tap the connector (4) with a hammer to fully insert. Be sure the connector is positioned as shown before tapping into hole.
  • Page 9 All manuals and user guides at all-guides.com STEP 3 (x6) #A22910 ameriwoodhome.com...
  • Page 10 All manuals and user guides at all-guides.com STEP 4 Turn screw clockwise to lock in place. end view end view ameriwoodhome.com...
  • Page 11 All manuals and user guides at all-guides.com STEP 5 Quick Assembly (x3) (x2) (x3) #A22620 #A21660 #A22920 Proper orientation of CAM LOCK You will need to tap the connector (4) with a hammer to fully insert. Be sure the connector is positioned as shown before tapping into hole.
  • Page 12 All manuals and user guides at all-guides.com STEP 6 Quick Assembly (x3) (x2) (x3) #A22620 #A21660 #A22920 Proper orientation of CAM LOCK You will need to tap the connector (4) with a hammer to fully insert. Be sure the connector is positioned as shown before tapping into hole.
  • Page 13 All manuals and user guides at all-guides.com STEP 7 (x2) (x6) #A21660 #A22910 ameriwoodhome.com...
  • Page 14 All manuals and user guides at all-guides.com STEP 8 Ends will be flush. Turn screw clockwise to lock in place. end view Ends will be flush. end view ameriwoodhome.com...
  • Page 15 All manuals and user guides at all-guides.com STEP 9 (x8) #A21660 ameriwoodhome.com...
  • Page 16 All manuals and user guides at all-guides.com STEP 10 (x4) #A23030 finished surface finished edge NOTE: Paper seam surface on foot will face to back. ameriwoodhome.com...
  • Page 17 All manuals and user guides at all-guides.com STEP 11 (x4) #A23030 finished edge ameriwoodhome.com...
  • Page 18 All manuals and user guides at all-guides.com STEP 12 finished surface ameriwoodhome.com...
  • Page 19 All manuals and user guides at all-guides.com STEP 13 (x4) #A23030 Press the partitions against the edge of the backs (H), making sure the wood dowels insert into the holes in the partitions. Then attach the partitions to the bottom using screws. ameriwoodhome.com...
  • Page 20 All manuals and user guides at all-guides.com STEP 14 (x8) #A22610 ameriwoodhome.com...
  • Page 21 All manuals and user guides at all-guides.com STEP 15 (x4) (x4) (x8) #A22610 #A12120 #A53510 ameriwoodhome.com...
  • Page 22 All manuals and user guides at all-guides.com STEP 16 ameriwoodhome.com...
  • Page 23 All manuals and user guides at all-guides.com STEP 17 ameriwoodhome.com...
  • Page 24 All manuals and user guides at all-guides.com STEP 18 (x24) (x12) #A12120 #A53510 With the help of another person, turn unit onto it's top. ameriwoodhome.com...
  • Page 25 All manuals and user guides at all-guides.com STEP 19 (x2) (x6) #A43100 #A43490 ameriwoodhome.com...
  • Page 26 All manuals and user guides at all-guides.com STEP 20 Insert fireplace into opening as shown. Fasten flange of fireplace to partition rails (J) with screws (7). You will screw into the groove of the partition rails (J). (x6) #A12120 Groove in partition rail.
  • Page 27 All manuals and user guides at all-guides.com STEP 21 Secure the fireplace insert into the opening by attaching one bracket (16) onto the bottom (E). Tighten bracket so it is snug against the fireplace insert. (x1) (x1) #A53655 #A12120 ameriwoodhome.com...
  • Page 28 All manuals and user guides at all-guides.com STEP 22 (x8) #A80250 finished edge ameriwoodhome.com...
  • Page 29 All manuals and user guides at all-guides.com Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. No CRT (tube type) TV permitted. This item is designed for most flat panel TV's having up to 64" (162.6cm) diagonal screen size. TV warning label 95 lbs 43.2 kg...
  • Page 30 Visit your local retailer's website, rate your purchased product and leave us some feedback! We would like to extend a big "Thank You" to all of our customers for taking the time to assemble this Ameriwood Home product, and to give us your valuable feedback. ameriwoodhome.com...
