- Page 1 ASSEMBLY INSTRUCTIONS COASTER FINE FURNITURE Fine Furniture for every stage of life 200704 Mirror REVISION 0 : 01/05/2009 REVISION 1 : 01/09/2012 COASTERFURNITURE.COM REVISION 2 : 12/22/2020 PAGE 1 OF 4...
- Page 2 200704 ITEM: ASSEMBLY INSTRUCTIONS ASSEMBLY TIPS: 1. Remove hardware from box and sort by size. 2. Please check to see that all hardware and parts are present prior to start of assembly. 3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
- Page 3 200704 ITEM: ASSEMBLY INSTRUCTIONS STEP 1 STEP 2 **BACK VIEW** PAGE 3 OF 4 COASTERFURNITURE.COM...
- Page 4 200704 ITEM: ASSEMBLY INSTRUCTIONS STEP 3 Arrow mark must be inline STEP 4 COMPLETE PAGE 4 OF 4 COASTERFURNITURE.COM...
- Page 5 200704 ITEM: 0.87" 34.84" 29.33" 39.17" 33.66" 4.53" 4.53" 6.89" 40.55" 25.98" Note : Dimension tolerence ± 5% PAGE 5 OF 5 COASTERFURNITURE.COM...
