- Page 1 Guidebook for installation, handling and maintenance – ENG Adveco S50÷S60 Electric Boilers Electric hot water boiler for heating systems with thermoregulatory microprocessor FG-Adveco S 50~60kW-08/2022...
-
Page 2: Table Of Contents
CONTENT Content 1. Explanation of symbols and instructions for safe work 7.3.5 Warnings and errors Explanation of symbols 7.3.6 Error and warning priorities Instructions for safe work 7.3.7 Protective elements 2. Device information Switchboard Overview of types 7.4.1 Arrangement of components on the switchboard 2.1.1 Declaration of conformity 7.4.2... -
Page 3: Explanation Of Symbols And Instructions For Safe Work
Explanation of symbols and instructions for safe work Explanation of symbols and instructions for safe work Explanation of symbols Make sure that device is available only to professionals. Installation and commissioning, and maintenance and repair, must be done only by service authorised for Warnings electrical works. -
Page 4: Device Information
55014-2:2015 – Electromagnetic compatibility - Requirements for This manual applies to the following types: household appliances, electric tools and similar apparatus - Part 1: Adveco Standard Emission - Part 2: Immunity - Product family standard ÷ 60 kW Electric Boilers ... -
Page 6: Product Description
Dashboard Part Pieces Boiler can be installed as integral part of the central heating system, Adveco Standard Electric Boiler floor heating, hybrid, or accumulation systems. Installation set The boiler bowl is made of steel sheet, tested at a pressure of 6bar and the maximum working pressure is 4bar. -
Page 7: Dimensions And Technical Data
6. Boiler thrust pipe DN40 PN16 7. Boiler return pipeline DN40 PN16 8. Safety valve 3/4'' 4bar 9. Automatic vent valve 10. Tap for filling and emptying ½'' 11. Cable inputs Image 2: Components of Adveco Standard 50 ÷ 60kW... - Page 8 Dimensions and technical data Technical data for Adveco Standard Electric Boilers 50 ~ 60kW Unit S 50 S 60 Power Usability level Number of power grades 5×10 6×10 Division of power grades 3N ~ 400/230V 50Hz V AC Network voltage...
-
Page 9: Installation Of The Device
Installation of device Installation of device CAUTION: Human material damages occurred because of irregular installation! Never install boiler without expansion dish (AG) and safety valve The boiler must not be installed in protected areas where there is moisture, as well as in places with high concentrations of soot and dust NOTE: Material damage due to freezing! -
Page 10: Boiler Mounting
Installation of device Boiler mounting NOTE: Damage to the installation due to poor water quality! This chapter describes the installation of the boiler. Depending on the characteristics of the water, The boiler is designed for floor mounting with minimum the installation of the heating system can be distances (Image 3) damaged by corrosion or by the formation of... -
Page 11: Electrical Connection
Electrical connection Electrical connection DANGER: Risk of life from electric shock! When connecting boiler on electric installation take Electric works must be done only by care on connections scheme and connecting plans. qualified person Respect mandatory diameters of cables and fusses power outside the boiler Turn off voltage supply before opening ... -
Page 12: Connecting Power (Voltage) Cable
Electrical connection Connecting power (voltage) cable Phase guides to be connected to the following clamps: RSL1, RSL2 and RSL3 The neutral (zero) supply connects to the conect clamp (RSN). Make the connection according to the assembly diagram Connecting clamp of neutral (zero) supply is blue. (Image 7). -
Page 13: Electrical Schemes
Electrical connection Electrical schemes All cable cross sections listed are minimal. The size of the cable cross section to be set depends on the length and method of installation Dimensions of the cable cross-section should be sized according to local regulations Legend Connecting clamp of protecting guide (25 ÷... - Page 14 Electrical connection Image 8: Boiler electric scheme (Adveco S) with nominal power of 50 kW...
- Page 15 Electrical connection Image 9: Boiler electric scheme (Adveco S) with nominal power of 50 kW...
- Page 16 Electrical connection Image 10: Boiler electric scheme (Adveco S) with nominal power of 60 kW...
- Page 17 Electrical connection Image 11: Boiler electric scheme (Adveco S) with nominal power of 60 kW...
-
Page 18: Commissioning
Commissioning Commissioning When complete below described works fill First start Commissioning log (chapter 6.4). NOTE: Material damage due to incorrect Before commissioning handling! NOTE: Material damage occurred due to Instruct client/user how to handle device unprofessional operating! Start-up without sufficient quantity of water Before commissioning for the first time, make sure that the destroys device heating installation is filled with water and vented... -
Page 19: Operation Of The Device
Operation of the device The user can only switch on the boiler (except for the first Operation of the device start-up), set the temperature on the control and put the boiler out of operation. All other work must be performed by Safety instructions an authorized servicers. -
Page 20: Modes Of Operation
Operation of the device 7.2.2 Modes of operation The boiler can operate in manual mode when the set In order for the heaters to be switched on, it is temperature is manually adjusted, or OPTIONAL in OTC necessary that the circulation pump is switched on, (Outdoor Temperature Compensation) mode, when the microcontroller determines the required system temperature according to one of two operating curves set in the settings or... -
Page 21: Setting Temperature
Operation of the device 7.2.5 Setting temperature 7.2.6 Setting power By briefly pressing the '' SET '' button, it enters the mode for If a change is confirmed after setting the temperature (presses setting the temperature and the set power. By briefly pressing OK), the thermostat switches to power setting - flashing set the '' SET '' button, it enters the mode for setting the power. -
Page 22: Otc (Outdoor Temperature Compensation) Boiler Operation Mode (Optional)
Operation of the device OTC (Outdoor Temperature Compensation) Boiler Operation Mode (OPTIONAL) In this mode, the microcontroller determines the required system temperature according to one of the two operating curves set in the settings, or maintains a constant temperature also set in the settings for the OTC mode. 7.3.1 Choice of boiler operating mode Press the '' OK '' key for 5 seconds to enter the mode selection. -
Page 23: 24-Hour Programming
Operation of the device 7.3.2 24-hour programming To set 24 hour programming press '' OK '' when there is a sign next to it (Image 11). A display (Image 12) appears on the display, at which the desired operating curve or const must be selected for each hour from 0 to 24. temperature. At the beginning of the setting, the bar for the period 0 ÷... - Page 24 Operation of the device The same way is for entering submenu and setting for an economical work curve (). To adjust the Constant Temperature (Const) value in the O.T.C. mode, use the button to select (Const) (the sign should be next to it), then confirm with the ''OK'' button.
-
Page 25: Symbols On Display In Otc Mode
Operation of the device 7.3.4 Symbols on display in OTC mode Sun symbol: The boiler operates in OTC mode, and currently, according to daily (24-hour) programming, thrust line temperature is calculated according to the operating line for a comfortable system temperature (indicated by the sun symbol ☼). -
Page 26: Warnings And Errors
Operation of the device 7.3.5 Warnings and errors Pressure below 0.8 bar: The boiler operates normally up to 0.4 bar and the alarm signal lamp blinks. Recommendation: Fill the system to a pressure above 0.8 bar Pressure above 2.3 bar: The boiler operates normally up to 2.3 bar and the alarm signal lamp blinks. Recommendation: Drain water to keep pressure below 2.2bar Temperature below 5 °... -
Page 27: Error And Warning Priorities
Operation of the device 7.3.6 Error and warning priorities Switchboard Multiple warnings and errors may occur at the same time during 7.4.1 Arrangement of components on the operation. Only one can be displayed, so the one with the switchboard highest priority will be displayed. After fixing it, an error with the next priority (if any) will be displayed. -
Page 28: Switchboard And The Top Plate Of The Boiler Basic
Operation of the device 7.4.2 Switchboard and the top plate of the boiler BASIC 50/60kW RE 1 Relay external conditions (room thermostat) PR1 ÷ PR2 Relay plate for heating groups turn on Network Board Power supply EK_CPU_1_3 and PLR K1, ..., K5 (K6) Contactor BENEDICT (Ith = 25A) E1, ..., E5 (E6) 3P C40A Three-phase automatic fuse... -
Page 29: Cleaning And Maintenance
Cleaning and maintenance Cleaning and maintenance Establish a working pressure of at least 1 bar, DANGER! Life threat of electric power shock! depending on the height of the highest point of the installation. If, due to the height of the installation, the Electric power work must be done only by ... -
Page 30: Inspection And Maintenance Log
Cleaning and maintenance Inspection and maintenance log The commissioning, inspection and maintenance record serves as an attachment for copying At least once a year perform maintenance or when a Executed works should be authorised by signature check shows the status of installations that require and date maintenance Date:... -
Page 31: Environment Protection /Waste Disposal
Environment protection / Waste disposal Environment protection /Waste disposal One of the basic concepts of business is environment protection. Quality of products, thriftiness and environment protection are equally valuable goals for us. It is critical to strictly comply with law and regulations on environment protection. -
Page 32: Troubles And Troubleshooting
Troubles and troubleshooting Troubles and troubleshooting Troubleshooting on regulations and hydraulics must be done by an authorised firm For repairs use only original spare parts TROUBLE DESCRIPTION CAUSE MEASURE Provide power supply Boiler is out of power supply ... -
Page 33: Product Data Sheet
EU regulation no. 811/2013 11. Product data sheet (in accordance with EU regulation no. 811/2013) Manufacturer MIKOTERM DOO Brand name Adveco Standard Models Adveco Standard 50kW Adveco Standard 60kW Room heating: Seasonal energy- efficiency class Room heating: Nominal heat rated... - Page 34 Contact Details The Adveco Electric Boiler range, this manual, and all information contained within, are supplied by Adveco Ltd. Adveco Ltd. Unit 7&8 Armstrong Mall, Southwood Business Park, Farnborough, Hampshire, GU14 0NR T: 01252 551 540 enquiries@adveco.co www.adveco.co Adveco Sales Department...
