User Guide | Optyma™ control AK-RC 111 single phase
10 | BC309238530328en-000101
CE1
Duration of compressor ON time in the case of
faulty ambient probe
(emergency mode).
If CE1=0 the emergency mode in the presence of
error E0 remains disabled, the compressor remains
off and defrosting is prevented in order to conserve
the remaining cold.
Duration of compressor OFF time in the case of
CE2
faulty ambient probe (emergency mode).
doC
Compressor safety time for door switch:
when the door is opened the evaporator fans shut
down and the compressor will continue working for
time doC, after which it will shut down.
tdo
Compressor restart time after door opening. when
the door is opened and after tdo time, it's setted back
the normal functioning giving door open alarm (Ed)
If the door switch is closed and the light stays on for
a longer time than tdo light cell alarm is signaled
(E9). With tdo=0 the parameter is disabled.
Fst
FAN shutdown TEMPERATURE
The fans will stop if the temperature value read by
the evaporator sensor is higher than this value.
Fd
Fst differential
LSE
Minimum value attributable to setpoint.
HSE
Maximum value attributable to setpoint.
Auxiliary/alarm relay 1 control
AU1
Auxiliary/alarm relay 2 control
AU2
StA
Temperature setting for auxiliary relay
nSC
Correction factor for the SET button during night
operation (energy saving)
(with In1 or In2 = 8 or -8)
During night operation the control set is:
Set Control = Set + nSC
In night mode decimal point flashes.
0 – 240 min
0 = disabled
5 – 240 min
0 – 5 min
0 – 240 min
0 = disabled
-45 – 99 °C
1 – 10 °C
-45 – (HSE-1) °C
(LSE+1) – 99 °C
-6 (NC) = relay de-energised
during stand-by
-5 (NC) = Contact for casing
element control (AUX
relay closed with
compressor output
inactive).
-4 (NC) = pump down function
(NC, see CHAP 5.16)
-3 (NC) = automatic auxiliary
relay managed by StA
temp. setting with 2°C
differential (NC)
-2 (NC) = manual auxiliary relay
controlled via AUX key
(NC)
-1 (NC) = alarm relay (NC)
0 = relay deactivated
1 (NO) = alarm relay (NO)
2 (NO) =manual auxiliary relay
controlled via AUX key
(NO)
3 (NO) = automatic auxiliary
relay managed by StA
temp. setting with 2°C
differential (NO)
4 (NO) = pump down function
(NO, see CHAP 5.16)
5 (NO) = free voltage contact for
condensing unit (AUX
relay and compressor
relay in parallel)
6 (NO) = relay excited during
stand-by
(like AU1 )
-45 – 99 °C
-20 – 20 °C
© Danfoss | DCS (vt) | 2020.03
0 min
5 min
0 min
0 min
99 °C
2 °C
-45 °C
99 °C
-1
5
0 °C
0 °C
