DMF RW-1630 Installation And Parts & Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

DIVERSIFIED METAL FABRICATORS, INC.
SERIAL NUMBER (FRONT)
SERIAL NUMBER (REAR)
Please refer to the serial numbers when ordering parts or
* This manual applies to both DMF's RW-1630 Railgear, and DMF's higher capacity
RW-1630/50 Railgear, including all configurations (standard, behind cab, and under cab)
Parts (404) 607-1684 Parts Fax (404) 879-7888 parts@dmfatlanta.com
Service Department (404) 879-7882 service@dmfatlanta.com
Phone (404) 875-1512  Fax (404) 875-4835 info@dmfatlanta.com
Parts & Service Manual
RW-1630
RW-1630/50*
November 2017
inquiring about warranty items.
DMF  665 Pylant Street  Atlanta, Georgia 30306
http://www.dmfatlanta.com
&
________________________
________________________
NOTE:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RW-1630 and is the answer not in the manual?

Questions and answers

Related Manuals for DMF RW-1630

Summary of Contents for DMF RW-1630

  • Page 1 Please refer to the serial numbers when ordering parts or inquiring about warranty items. * This manual applies to both DMF’s RW-1630 Railgear, and DMF’s higher capacity RW-1630/50 Railgear, including all configurations (standard, behind cab, and under cab) DMF  665 Pylant Street  Atlanta, Georgia 30306 Parts (404) 607-1684...
  • Page 2 For purposes of this manual, we will refer to RW-1630 when discussing either RW-1630 or RW1630/50, and we will explicitly call out any differences when appropriate.

  • Page 3: Table Of Contents

    6.2 Valve Assemblies and Hydraulic Schematic ..... 6-4 6.3 Rear Hydraulic Cylinder Drawings ......6-5 6.4 Front Hydraulic Cylinder Drawings ......6-9 6.5 Cylinder Assembly Procedures ......6-11 6.6 Fitting Installation ..........6-12 © 2017 DMF, Inc. All Rights Reserved.
  • Page 4 7.5 Extra-Short Links ..........7-7 7.6 Short Links ............7-8 7.7 Long Links ............7-9 7.8 RW-1630 Wheel & Rear Axle Assembly (Detail) ..7-10 7.9 RW-1630 Stub Axle Assembly, Rear, Double Insulated ............7-11 7.10 RW-1650 Wheel & Rear Axle Assembly (Detail) ..7-12 7.11 RW-1650 Stub Axle Assembly, Rear, Double...
  • Page 5 Figure 5.3.6 Brake Inspection and Alignment ....... 5-12 Figure 5.3.8 Cobra Air Brake Assembly ........5-13 Figure 5.4 RW-1630/50 Insulated 2-Pc. Wheel Assembly .... 5-15 Figure 5.5 Stub Axle Shunt Wiring ........... 5-17 Table 3.4.1 Troubleshooting On-Track Problems ......3-7 Table 4.1.5...
  • Page 6 Behind Cab Front Railgear Components ............1-4     1.2.3 Under Cab Front Railgear Components ............. 1-4     REAR RAILGEAR ..................... 1-5     1.3.1 Rear Railgear Components (Including RW-1630 and RW-1650) ......1-5     © 2017 DMF, Inc. All Rights Reserved.

  • Page 7: General Description

    Installation: Both DMF front and rear guide wheel units bolt to the truck frame using only hand tools found in any shop. They are designed to minimize the amount of space required and in many cases fit within the existing boundaries of the vehicle.

  • Page 8: Front Railgear

    FRONT RAILGEAR DMF’s Heavy Duty Front Railgear is available in 3 different variations. The standard front Railgear uses a 1630 axle (see section 1.2.1), the Behind Cab variation uses an extra heavy duty 1650 axle and wheels (see section 1.2.2), and the Under Cab variation uses the 1630 axle (see section 1.2.3).

  • Page 9: Behind Cab Front Railgear Components

    For parts drawings, see Section 8.0, and for installation instructions, see Section 4.0. 1.2.3 Under Cab Front Railgear Components DMF Under Cab Front Railgear uses the RW-1630 axle and wheels. Front Railgear mounted to truck frame underneath the vehicle cab, with 16” guide wheels GVWR Range: 33,000 lbs.

  • Page 10: Rear Railgear

    RW-1630 REAR RAILGEAR 1.3.1 Rear Railgear Components (Including RW-1630 and RW-1650) DMF offers two different variations of Rear Railgear, RW-1630 and RW-1650. The components are the same, other than the axles and wheels, which have different weight capacities. RW-1630 GVWR Range: 33,000 lbs. and above Approx.
  • Page 11 Lower Front Guide Wheels ................2-4     2.4.4 On the Tracks ..................... 2-5     GETTING OFF THE RAIL ................... 2-5     2.5.1 Removing Truck from Track ................2-5     © 2017 DMF, Inc. All Rights Reserved.

  • Page 12: Before You Operate The Railgear

    Cable Remote Pin-Offs  Air Remote Pin-Offs NOTE: DMF’s Rear Cylinders are equipped with integral locking valves, however, pin-offs are still required in both the rail and highway positions. Operation Controls  Locate and familiarize yourself with the front and rear Railgear operating controls ...

  • Page 13: Anti-Lock Brake System (Abs)

    This will clear the ABS light after a few seconds. If the amber light remains on during road operation, the truck’s brake system may have an active fault and should be checked out. Please refer to the truck’s operation manual. © 2017 DMF, Inc. All Rights Reserved.

  • Page 14: Highway Operation

    16. Disengage the truck’s parking brake when you are ready to proceed. NOTE: The front guide wheel assembly is an over-center design and does not require safety pin-off pins engaged in rail mode. © 2017 DMF, Inc. All Rights Reserved.

  • Page 15: Getting Off The Rail

    If the amber light remains on during road operation, the truck’s brake system may have an active fault and should be checked out. Please refer to the truck’s operation manual. © 2017 DMF, Inc. All Rights Reserved.
  • Page 16     Lubrication Specification ................. 3-3     Wheel Wear Gauge ..................3-5     Troubleshooting ....................3-7     3.4.1 Troubleshooting On-track Problems ............... 3-7     Derailment ...................... 3-8     © 2017 DMF, Inc. All Rights Reserved.

  • Page 17: Inspection And Maintenance

    For adjustment information, see Section 7.0 & 8.0 for appropriate axle assembly drawings. If your vehicle is equipped with DMF “two piece” wheels, check the bolt torque indicators  (the tabs around each bolt) to ensure that they have not moved. If torque indicators are missing or damaged, please contact DMF for replacements.

  • Page 18: Lubrication Specification

    (2) The brakes properly release when the brake pedal is released. If brakes do not function properly, contact a Service Representative at DMF. 3.1.3 Bi-annually Perform standard daily and weekly inspection points as listed above, and then check the...

  • Page 20: Wheel Wear Gauge

    RW-1630 Wheel Wear Gauge A metal wheel wear gauge (DMF part number 800115) is available to aid in inspecting worn wheels. The drawing on the next page illustrates how to use the gauge and also lists specifications for minimum wall thickness on the wheel tread as well as tolerance on wheel back-to-back spacing.

  • Page 22: Troubleshooting

    Replace Worn Wheel Wear Wheels Insufficient traction Rail Wheel Load set See Section 4.10 Set Rail Wheel Load or braking too low Tires worn Inspect Tires Replace tires Table 3.4.1 Troubleshooting On-Track Problems © 2017 DMF, Inc. All Rights Reserved.

  • Page 23: Derailment

    Ensure axle threads are not stripped or damaged Any items noted should be repaired using specifications in the manual, to ensure they are repaired to initial install standards. Please contact DMF for any assistance you may require. © 2017 DMF, Inc. All Rights Reserved.
  • Page 24     4.7.2 Final Steps ....................4-25     UNDER CAB FRONT UNIT INSTALLATION ............4-26     4.8.1 Under Cab General Information ..............4-26     4.8.2 Dismantle ....................4-27     © 2017 DMF, Inc. All Rights Reserved.
  • Page 25     4.12 FINAL WELD-OUT .................... 4-34     4.13 INSTALL DECALS ..................... 4-36     4.14 VELCRO STEERING WHEEL LOCK ..............4-37     4.15 INSTALLATION REVIEW CHECKLIST ..............4-38     © 2017 DMF, Inc. All Rights Reserved.

  • Page 26: Pre-Install

    PRE-INSTALL NOTE: The proper installation of this equipment is solely the responsibility of you, the installer. When in doubt, contact DMF for assistance. NOTE: During Railgear installation, there are 3 different alignments - front Railgear to truck frame, rear Railgear to truck frame, and a final procedure that aligns both sets of Railgear to each other.

  • Page 28: Initial Instructions

    Also the condition of the rear tires needs to be determined. If the rear tires are worn, they should be replaced. Alignment - Rear truck axle must be square with truck frame. DMF recommends that a ...

  • Page 29: Hydraulic System

    Figure 4.2.4 Installation Rails NOTE: Inside-to-Inside measurement of 56-1/2” is the standard gage for the United States. If your equipment is to be operated on any other gauge, adjust measurements according. © 2017 DMF, Inc. All Rights Reserved.

  • Page 30: Installation Of Rear Railgear

    See Section 7.0 for different link measurements and contact DMF for final consultation before ordering a different set of links. DMF will not be responsible if the links are changed from the initial order without consulting with DMF.

  • Page 31: Diagram Of Key Components

    Figure 4.3.2 shows the individual parts of the installed rear Railgear. Please familiarize yourself with these item descriptions as they will be used throughout this installation manual. Figure 4.3.2 Diagram of Key Components © 2017 DMF, Inc. All Rights Reserved.

  • Page 32: Location Of Rear Railgear

    (see Figure 4.3.4). It is important that nothing encroach upon this space (e.g., outriggers, lift-gates, and body tie-down bolts). Figure 4.3.4 Location and Clearance of Railgear © 2017 DMF, Inc. All Rights Reserved.

  • Page 33: Shimming And Temporarily Spacing Rear Bracket

    Railgear bracket centered. Note that DMF provides shims of different thicknesses, and it is important that the same amount of shim measurement is achieved on both sides.

  • Page 34: Squaring Up Rear Railgear To Truck Frame

    Also, temporarily tack the spacers into place, so that if further adjustment is necessary, the welds can easily be ground off and spacers added/removed as necessary. NOTE: Only use Grade 5 bolts on rear Railgear. © 2017 DMF, Inc. All Rights Reserved. 4-11...

  • Page 35: Mounting Plate Installation

    Final Rear Railgear Alignment and Weight Settings Rear Railgear alignment and weight settings can only be performed after front Railgear is installed. The procedures for these final steps can be found in Section 4.10. 4-12 © 2017 DMF, Inc. All Rights Reserved.

  • Page 36: Varying Front Railgear Configurations

    RW-1630 VARYING FRONT RAILGEAR CONFIGURATIONS Due to the numerous variations between chassis, DMF has designed several different mounting configurations to supply our customers with the perfect fit for their application. These configurations fall into three main categories as listed below. Each of these categories, though similar, requires varying installation procedures.

  • Page 37: Traditional Long Arm Assembly Installation

    However, before starting the front Railgear installation, check the vehicle’s front tire spacing. The front Railgear operates between the front steering tires; therefore, you must have a minimum of 65" between the tires. If this is not the case, contact DMF. ...

  • Page 38: Frame Extension Installation

    Figure 4.5.3 Bolted Joint Cross Section NOTE: DMF front frame extensions are designed to support the Railgear only. It is the installer’s responsibility to properly engineer brackets for rail racks, boom rests and etc. In normal applications, mount the Front Valve Plate Assembly between the Frame Extensions (with the Front Valve on the underside and the handle facing forward) and weld in place.
  • Page 39 DIVERSIFIED METAL FABRICATORS, INC. RW-1630 FRAME RAIL BRIDGE TUBE CROSS TUBE BRIDGE TUBE FRAME RAIL 25 1/2" ±1/2" 12 3/4" ±1/2" FRONT MOUNTING REAR MOUNTING Figure 4.5.4.A Below Frame Rail Bridge Kit 4-16 © 2017 DMF, Inc. All Rights Reserved.
  • Page 40 DIVERSIFIED METAL FABRICATORS, INC. RW-1630 FRAME RAIL BRIDGE GUSSET BRIDGE TUBE CROSS TUBE FRAME RAIL 25 1/2" ±1/2" FRONT MOUNTING 12 3/4" ±1/2" REAR MOUNTING Figure 4.5.4.B Between Frame Rail Bridge Kit © 2017 DMF, Inc. All Rights Reserved. 4-17...

  • Page 41: Front Mounting Dimensions

    1” x 2” flat bar Spacer (already supplied) on top of the Rubber Spacer and two 3/4”-10 hex nuts per stud. The top Spacer has no effect on the height of the Railgear and is only used for clamping purposes. 4-18 © 2017 DMF, Inc. All Rights Reserved.
  • Page 42 The minimum heights (with railgear stowed for highway travel) are 23” for the Front Mounting Pin and 10” for Rear Mounting Pin. These heights will allow the Railgear to have 8” of ground clearance when stowed. © 2017 DMF, Inc. All Rights Reserved. 4-19...

  • Page 43: Front Railgear Clearance

    Railgear near the Rear Mounting Pin moves more than the part near the Front Mounting Pin, and attention needs to be paid to the possible clearance problems that can be caused by this movement. 4-20 © 2017 DMF, Inc. All Rights Reserved.

  • Page 44: Cargo Arm Front Assembly Installations

    If this is the case, DMF supplies a front Railgear unit that includes much shorter long arms (Referred to as Cargo Arms). With some modifications that will be detailed further, the rear of...
  • Page 45 “I” beam. The flat bar is to be welded securely to the spring hanger and attached to the axle “U” bolt as shown. 4-22 © 2017 DMF, Inc. All Rights Reserved.

  • Page 46: Completing Front Installation

    Section 5.3. With the Axle Tubes now centered and brake configuration determined, the Axle Tubes should be temporarily tacked (at final adjustment, the tacks can be ground off and the axle re- © 2017 DMF, Inc. All Rights Reserved. 4-23...
  • Page 47 NO WELDING ON AXLE TUBE OUTBOARD OF SHUNT BOLT MUST BE WELDED IN RAIL POSITION RECOMMENDED TACK LOCATION IN OPENING ON DRIVER SIDE SLEEVE FOR FRONT STUB AXLE Figure 4.7.1.B Recommended Tack Location for Front Stub Axle 4-24 © 2017 DMF, Inc. All Rights Reserved.

  • Page 48: Final Steps

    (see CLEARANCE NOTE and Figure 4.5.7). NOTE: Remount the truck front bumper or use 8" standard channel welded onto the ends of the Frame Extensions. © 2017 DMF, Inc. All Rights Reserved. 4-25...

  • Page 49: Under Cab Front Unit Installation

    11” Rail wheel G.C. in Highway mode. This can be reduced for fitting under lower tanks; but you must contact DMF. Another option would be to reinstall the tanks higher during re-assembly. Is there room to move the tanks higher? 4.

  • Page 50: Dismantle

    This may be done on the inboard sides of the lower arms. Follow the established procedure for welding the axle tubes to the pivot arms found in Sections 4.7 and 4.12. © 2017 DMF, Inc. All Rights Reserved. 4-27...

  • Page 51: Remote Air Pin-Off Installation

    If this check is being performed off the rail (such as a concrete shop floor), note that the rail wheel flange is roughly 1.25” tall. RW-1630 Under Cab Railgear can be installed closer to the ground to increase front tire clearance above the rail.

  • Page 53: Behind Cab Front Unit Installation

    The guide wheels are reversible at installation. If the wheels are insulated, it is noted that DMF installs the insulation on the driver’s side wheel, which in this case, locates the brakes to the rear of the axle.

  • Page 54: Dismantle

    4 lower axle straps removed, raise the assembly up to the upper spring seats. Install the 4 bolts through the springs and secure nylock nuts. Next, install the 4 axle straps and secure with the sixteen 5/8-11 bolts and lock washers. © 2017 DMF, Inc. All Rights Reserved. 4-31...

  • Page 55: Overall Alignment Procedure

    4.9.4 Front Tire Clearance Check DMF recommends a minimum of 2” of front tire clearance above rail in applications where the front truck tires are lifted in the air for use on rail. If this check is being performed off the rail (such as a concrete shop floor), note that the rail wheel flange is roughly 1.25”...

  • Page 57: Rail Test

    ONCE FINAL ALIGNMENT & WEIGHTS ARE SET, THE INBOARD SIDE OF THE OUTER PIVOT ARM S MUST BE FULLY WELDED (COMPLETE STRUCTURAL WELDS) ALL THE WAY AROUND. Figure 4.12.A Standard Railgear Final Weld-out 4-34 © 2017 DMF, Inc. All Rights Reserved.
  • Page 58 4.12.D.  If multiple spacers are used, spacers must be fully welded to one another on the rear, and tack welded on the sides, as shown in figure 4.12.D. © 2017 DMF, Inc. All Rights Reserved. 4-35...

  • Page 59: Install Decals

    Install decal kit 800190 provided with the railgear. This kit includes 2 pages of decals. There is a drawing on the backside of each page to show where the decals belong on the vehicle. 4-36 © 2017 DMF, Inc. All Rights Reserved.

  • Page 60: Velcro Steering Wheel Lock

    6) To remove the lock simply pull on the ‘D’ ring and store the piece of Velcro fabric. © 2017 DMF, Inc. All Rights Reserved. 4-37...

  • Page 61: Installation Review Checklist

    In a parking lot or open area, verify that the truck tires and rims do not contact the Railgear in any bump, droop, or steering position.  Check for any rattles and vibration. 4-38 © 2017 DMF, Inc. All Rights Reserved.
  • Page 62 Cobra Air Brake Location ................5-7     5.3.2 Front Air Brake Installation ................5-8     5.3.3 Rear Air Brake Installation (RW-1630) ............5-8     5.3.4 Air Brake Plumbing Installation ..............5-9     5.3.5 Cobra Air Brake System Plumbing Overview ........... 5-9  ...

  • Page 63: Rail Sweeps

    Mounting Bracket directly to the Air Brake structure. On the front, bolt on the side facing forward; on the rear, bolt to the top of the Air Brake (which faces backward). Figure 5.1.A Rail Sweeps Figure 5.1.B Rail Sweep Position © 2017 DMF, Inc. All Rights Reserved.

  • Page 64: Pin-Off Options

    DIVERSIFIED METAL FABRICATORS, INC. RW-1630 PIN-OFF OPTIONS See drawings on next three pages. © 2017 DMF, Inc. All Rights Reserved.

  • Page 68: Brakes

    Rail wheel brakes alone are insufficient to stop the vehicle in a reasonable distance. DMF’s RW-1630 Railgear uses an optional air braking system. The same Cobra air braking system is used for both the front and rear Railgear. For a detailed drawing of the Cobra Air Brake Assembly, section 5.3.8.

  • Page 69: Front Air Brake Installation

    DIVERSIFIED METAL FABRICATORS, INC. RW-1630 5.3.2 Front Air Brake Installation Figure 5.3.2 Front Air Brake Installation 5.3.3 Rear Air Brake Installation (RW-1630) Figure 5.3.3 Rear Air Brake Installation © 2017 DMF, Inc. All Rights Reserved.

  • Page 70: Air Brake Plumbing Installation

    The brake valves are already preset at the factory (front at 75 psi, rear at 30 psi). 5.3.5 Cobra Air Brake System Plumbing Overview ** See additional detailed drawing on next page ** © 2017 DMF, Inc. All Rights Reserved.

  • Page 73: Inspection And Adjustment

    (2) the brakes properly release when the brake pedal is released. If brakes do not function properly, contact a Service Representative at DMF. NOTE: The rail wheel brake system is intended to assist the existing vehicle brakes when in the rail mode.

  • Page 75: Two-Piece Wheels

    TWO-PIECE WHEELS DMF offers a two-piece, insulated wheel option for extreme applications, such as material handlers. If your material handler will be insulated, then DMF requires the use of our two-piece wheel. DMF’s two-piece wheels require additional maintenance (over and above our standard wheels), so we only recommend them for use in heavy-duty applications.
  • Page 76 800301 KIT, 2-PC. WHEEL INDICATORS (8 GREEN/1 RED) P/N #800020 - ALL HARDWARE KIT FOR RW-1630 WHEEL (see drawing M1630103 in Section 7) P/N #800021 - ALL HARDWARE KIT FOR RW-1650 WHEEL (see drawing M1650103 in Section 7) 5/8"-11 x 4" Grade 8 Bolts See Section 5.4 for detail...

  • Page 77: Stub Axle Shunts

    DIVERSIFIED METAL FABRICATORS, INC. RW-1630 STUB AXLE SHUNTS See drawing 818808 on the next page for stub axle shunt wiring instructions. 5-16 © 2017 DMF, Inc. All Rights Reserved.
  • Page 78 SWITCH, SPST, 25 AMP 605267 FLAT WASHER, 1/4", NYLON 818809 BOLT INSULATOR, SHUNT KIT, STUB AXLE 605177 HHCS 1/4-20 UNC X 1" (USE WITH RW-1630) 605263 HHCS, 1/4-20 UNC X 1-1/4" (USE WITH RW-1650) 818810 SHUNT SWITCH STICKER (NOT SHOWN) 605262...
  • Page 79 VALVE ASSEMBLIES AND HYDRAULIC SCHEMATIC ..........6-4     REAR HYDRAULIC CYLINDER DRAWINGS ............6-5     FRONT HYDRAULIC CYLINDER DRAWINGS ............6-9     CYLINDER ASSEMBLY PROCEDURES ..............6-11     FITTING INSTALLATION .................. 6-12     © 2017 DMF, Inc. All Rights Reserved.

  • Page 80: Hydraulic System

    6.1.1 New Hydraulic System for Vehicle without Hydraulic System If only DMF Railgear is to be installed and there is not an existing hydraulic system, outfit the truck with a 5 to 7 GPM, 2500 psi pump, suction filter (such as a Vickers OFSS-10), with an appropriate sized reservoir.
  • Page 81 Be certain that the front and rear valves are plumbed correctly. Each valve port is marked "IN" or "OUT". Plumbing the valves backward will cause an unsafe condition, resulting in possible injury and/or damage. © 2017 DMF, Inc. All Rights Reserved.
  • Page 83 ITEM PART NO. DESCRIPTION DMF P/N 240225 - SEAL KIT 240246 HYDRAULIC CYLINDER PISTON, LVLV, 3-1/2" (SEAL KIT INCLUDES ITEM #'s 4,5,6,7,8 & 9) 240202 HYDRAULIC CYLINDER GLAND, 3-1/2" 240103 NYLOCK NUT, 1" - 14 TO DETERMINE DRIVER SIDE VS. PASSENGER SIDE...
  • Page 84 PART NO. DESCRIPTION (SEAL KIT INCLUDES ITEM #'s 4,5,6,7,8 & 9) 240246 HYDRAULIC CYLINDER PISTON, LVLV, 3-1/2" DMF P/N 240225 - SEAL KIT 240202 HYDRAULIC CYLINDER GLAND, 3-1/2" 240103 NYLOCK NUT, 1" - 14 TO DETERMINE DRIVER SIDE VS. PASSENGER SIDE...
  • Page 85 241335 FITTING, #06 MJIC X #04 MJIC X 90 DEGREE 108129 TUBE NUT, 3/8" 108130 TUBE FERRULE, 3/8" DMF P/N 240225 - SEAL KIT (SEAL KIT INCLUDES ITEM #'S 4,5,6,7,8 & 9) TORQUE: 300 FT-LBS OPEN: 21.001 CLOSED: 13.633 11/10/14 21.001 WAS 20.908...
  • Page 86 FITTING, #06 MJIC X #04 MJIC X 90 DEGREE 108129 TUBE NUT, 3/8" 108130 TUBE FERRULE, 3/8" TORQUE: 300 FT-LBS DMF P/N 240225 - SEAL KIT (SEAL KIT INCLUDES ITEM #'S 4,5,6,7,8 & 9) OPEN : 21.001 CLOSED: 13.633 11/10/14 21.001 WAS 20.908 10/3/14 REDRAWN, OPEN 20.908 WASOPEN 21.068...
  • Page 87 NOTES: TOLERANCES (UNLESS SPECIFIED): TITLE: FRAC, MACH: ± 1/32" HYDRAULIC CYLINDER ASSEMBLY, FRONT DMF P/N 240125 SEAL KIT INCLUDES ITEM #'S 7, 8, 9, 10, 11, 12 FRAC, OTHER: ±1/16" RW-1630 / 1420 / ± .063 DRIVER SIDE, RW-1630/1420/1212/1019 ± .030 1212 / 1019 .XXX...
  • Page 88 NOTES: TOLERANCES (UNLESS SPECIFIED): TITLE: FRAC, MACH: ± 1/32" HYDRAULIC CYLINDER ASSEMBLY, FRONT DMF P/N 240125 SEAL KIT INCLUDES ITEM #'S 7, 8, 9, 10, 11, 12 FRAC, OTHER: ±1/16" RW-1630 / 1420 / ± .063 PASSENGER SIDE, RW-1630/1420/1212/1019 ± .030 1212 / 1019 .XXX...
  • Page 93 EXTRA-SHORT LINKS ..................7-7 SHORT LINKS ..................... 7-8 LONG LINKS ....................... 7-9 RW-1630 WHEEL & REAR AXLE ASSEMBLY (DETAIL) ........7-10 RW-1630 STUB AXLE ASSEMBLY, REAR, DOUBLE INSULATED ......7-11 7.10 RW-1650 WHEEL & REAR AXLE ASSEMBLY (DETAIL) ........7-12 7.11...
  • Page 94 Other Considerations for Ordering Parts: This is a list of considerations to make before placing a parts order with DMF. There are many variations and customer requirements that we strive to accommodate, and as a result, the more information you can provide to us when placing an order, the more likely that we will be able to help you quickly and efficiently.
  • Page 95 Shims are available to adapt wider brackets to different frame widths. If your exact measurements are not available on the parts list, please discuss this with the DMF Parts department and we will work with you to get the appropriate rear bracket and necessary shims.
  • Page 96 NUMBER 5/8-11 HEX BOLTS, 5/8-11 NYLOCK NUTS, & 5/8" FLAT WASHERS NOT PROVIDED. FASTEN TO 154 LB-FT. WHEEL & AXLE ASSY., REAR (RW-1630) REAR LINK ASSY., SHORT, SLOTTED MUST BE GRADE 5 FOR REAR ONLY. LENGTH TO BE DETERMINED REAR MOUNTING BRACKET ONCE BRACKET MOUNTED AND SHIMMED.
  • Page 97 BEFORE ORDERING REAR CYLINDERS, LINKS, AND/OR BRAKES ONLY: WHEN ORDERING REAR PARTS, IT IS IMPORTANT TO NOTE TRUCK FRONT WHICH WAY THE PIN-OFFS ARE FACING - IF THEY ARE FACING PASSENGER TOWARD THE REAR OF THE TRUCK, THEN THIS IS CONSIDERED SIDE OF TRUCK OUR STANDARD MOUNTING CONFIGURATION.
  • Page 99 X-SHORT LINKS X-SHORT (SLOTTED) LINKS Note: Links are sold individually unless you want a full set of all 8. Please refer to 818660 818661 full set p/n's shown below. The "Rear Set of Rear Links" differ in p/n's 818666 according to pin-off option. Your "Front Set 818670 818660 818661...
  • Page 100 SHORT LINKS SHORT (SLOTTED) LINKS Note: Links are sold individually unless 818265 818264 you want a full set of all 8. Please refer to 818285 818266 full set p/n's shown below. The "Rear Set of Rear Links" differ in p/n's 818264 818267 818243...
  • Page 101 LONG LINKS LONG (SLOTTED) LINKS 818279 Note: Links are sold individually unless you want a full set of all 8. Please refer to 818284 818650 full set p/n's shown below. 818230 The "Rear Set of Rear Links" differ in p/n's 818651 818284 818279...
  • Page 103 1. INSTALL ALL INSULATORS ON STUB DATE DESCRIPTION AXLE BEFORE PRESSING INTO AXLE TOLERANCES: TITLE: (UNLESS SPECIFIED) TUBE AXLE ASSEMBLY, 1630 REAR, STUB AXLE, RW-1630 FRAC, MACH: ± 1/32" DBL INSULATED 2. CHECK FOR ZERO CONTINUITY AFTER FRAC, OTHER: ± 1/16" ± .063 ASSEMBLY ±...
  • Page 104 ITEM NO. PART NUMBER QTY. DESCRIPTION 820458 BOLT INSULATOR, 1650 STUB AXLE 820461 INSULATOR DISC, 1650 STUB AXLE 820462 LOCK WASHER, 3/4", GRADE 8 820463 HEX HEAD CAP SCREW, 3/4-10 UNC x 5" LONG, GRADE 8 820541 AXLE TUBE WELDMENT - 1650 STUB AXLE, GEN 2 820547 INSULATOR TUBE, 1650 STUB AXLE, GEN 2 820543...
  • Page 105 ITEM PART NUMBER QTY. DESCRIPTION PARTS: (MUST HAVE SERIAL # WHEN ORDERING) 1650 REAR AXLE WELDMENT TUBE WIDE W/ BRAKES COMPLETE REAR AXLE ASSEMBLY OPTIONS (AXLE, AXLE TUBE, WHEELS): 1650 & BEHIND CAB WHEELS: 1650 REAR AXLE TUBES: 800108 HUBCAP BOLTS (HHCS 5/16"-18 X 3/4") NON-INSULATED, WITH BRAKES (1650) - 800213 NON-INSULATED, 1650 WHEEL W/ RACES - 800015 AXLE TUBE, WITH BRAKES - 818209...
  • Page 106 3/8" FILLET WELD OTHER PLACES (TYP.) DATE DESCRIPTION TOLERANCES: TITLE: (UNLESS SPECIFIED) REAR MOUNTING 12" FORMED BRACKET ASSY FRAC, MACH: ± 1/32" RW-1630 3/4" HEAVY DUTY PLATE FRAC, OTHER: ± 1/16" ± .063 ± .030 DIVERSIFIED METAL FABRICATORS, INC. (404) 875-1512 .XXX ± .005 DRILL SIZES: + .015...
  • Page 107 34-7/8" 819511 35-5/8" 12.0 REF. 819313 36-11/16" Note: These are the most commonly used. Special widths are available, please contact DMF. .50 TYP. *MUST ORDER COMPLETE BRACKET DIMENSION "A" - SEE TABLE (FRAME WIDTH + 1/8") HALF "A" 10-3/4" REF.
  • Page 108 FRONT PARTS DETAIL DRAWING ............... 8-3 LONG ARM VARIATIONS ..................8-4 RW-1630 WHEEL & FRONT AXLE ASSEMBLY ............8-5 RW-1630 STUB AXLE ASSEMBLY, FRONT, DOUBLE INSULATED ......8-6 RW-1630 UNDER CAB FRONT RAILGEAR ASSEMBLY ........... 8-7 RW-1650 BEHIND CAB FRONT RAILGEAR ASSEMBLY ......... 8-8 RW-1630 MOUNTING TUBE VARIATIONS ............
  • Page 109 Other Considerations for Ordering Parts: This is a list of considerations to make before placing a parts order with DMF. There are many variations and customer requirements that we strive to accommodate, and as a result, the more information you can provide to us when placing an order, the more likely that we will be able to help you quickly and efficiently.
  • Page 110 ITEM PART NUMBER QTY DESCRIPTION ITEM PART NUMBER DESCRIPTION PIVOT ARMS FOR USE WITH CARGO ARMS 810453 2 RW-1630 CARGO PIVOT ARM ASSY., RIGHT HAND 818124 PIN ASSEMBLY, FRONT MOUNTING ( 1-1/4") 810452 RW-1630 CARGO PIVOT ARM ASSY., LEFT HAND 818149 TIE PIN ASSEMBLY, PIVOT ARM WHEEL &...
  • Page 111 808117 - PASSENGER SIDE OUTER DATE DESCRIPTION 808118 - DRIVER SIDE OUTER TOLERANCES: TITLE: (UNLESS SPECIFIED) 808152 - PASSENGER SIDE INNER VARIOUS RW-1630 LONG ARMS ± 1/32" 808153 - DRIVER SIDE INNER FRAC, MACH: FRAC, OTHER: ± 1/16" 15.000 808154 - INNER/OUTER SET ±...
  • Page 113 DESCRIPTION TOLERANCES: TITLE: INSTALL ALL INSULATORS ON STUB AXLE BEFORE (UNLESS SPECIFIED) 1630 STUB AXLE ASSEMBLY, FRONT, DOUBLE PRESSING INTO AXLE TUBE RW-1630 FRAC, MACH: ± 1/32" INSULATED FRAC, OTHER: ± 1/16" ± .063 CHECK FOR ZERO CONTINUITY AFTER ASSEMBLY ±...
  • Page 116 3.00" CROSS TUBE - P/N #810154 5.00" HIGH 3-PC. CROSS TUBE - P/N #810107 1/2" CROSS TUBE - P/N #810349 4.00 5.00 1.50 3.00 4.00 6.00" HIGH 3-PC. CROSS TUBE - P/N #810328 1.00" CROSS TUBE - P/N #810261 5.00 6.00 4.00"...
  • Page 117 2.875 4.000 5.500 6.625 8.000 4" SPRING HANGER - P/N #818155 10.000 6-5/8" OFFSET SPRING HANGER - P/N #818172 5.500 6.625 8.000 6-5/8" SPRING HANGER - P/N #818170 8.375 9.500 10.000 9-1/2" OFFSET SPRING HANGER - P/N #810136 7.875 9.000 DATE DESCRIPTION TOLERANCES:...
  • Page 118 United States and Canada. DMF shall not be liable for other loss, damage, or expense directly or indirectly arising from the use of its products.

This manual is also suitable for:
