PCB Piezotronics ICP 221B05 Installation And Operating Manual page 16

Model Number
221B05
Performance
Sensitivity(± 15 %)
Measurement Range(Compression)
Measurement Range(Tension)
Maximum Static Force(Compression)
Maximum Static Force(Tension)
Broadband Resolution(1 to 10,000 Hz)
Low Frequency Response(-5 %)
Upper Frequency Limit
Non-Linearity
Environmental
Temperature Range
Temperature Coefficient of Sensitivity
Electrical
Discharge Time Constant(at room temp)
Excitation Voltage
Constant Current Excitation
Output Impedance
Output Bias Voltage
Output Polarity(Compression)
Physical
Stiffness
Size (Diameter x Height)
Weight
Housing Material
Sealing
Electrical Connector
Electrical Connection Position
Mounting Thread
[5]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Group, Inc.
ICP® FORCE SENSOR
ENGLISH SI
1 mV/lb 224.82 mV/kN
5000 lb 22.24 kN
1000 lb 4.448 kN
6000 lb 26.69 kN
1200 lb 5.34 kN
0.10 lb-rms 0.445 N-rms
0.0003 Hz 0.0003 Hz
15 kHz 15 kHz
≤ 1.5 % FS ≤ 1.5 % FS
-65 to +250 °F -54 to +121 °C
≤ 0.03 %/°F ≤ 0.054 %/°C
≥ 2000 sec ≥ 2000 sec
20 to 30 VDC 20 to 30 VDC
2 to 20 mA 2 to 20 mA
≤ 100 Ohm ≤ 100 Ohm
8 to 14 VDC 8 to 14 VDC
Positive Positive
2 lb/µin 0.35 kN/µm
0.65 in x 1.25 in 16.51 mm x 31.75 mm
1.1 oz 31 gm
Stainless Steel Stainless Steel
Hermetic Hermetic
10-32 Coaxial Jack 10-32 Coaxial Jack
Side Side
1/4-28 Female 1/4-28 Female
OPTIONAL VERSIONS
Optional versions have identical specifications and accessories as listed for the standard model
except where noted below. More than one option may be used.
J
- Ground Isolated
[1]
M
- Metric Mount
[2]
Mounting Thread
[3]
[4]
N
- Negative Output Polarity
Output Polarity(Compression)
W
- Water Resistant Cable
Electrical Connector
Electrical Connection Position
NOTES:
[1]Typical.
[2]Calculated from discharge time constant.
[3]Estimated using rigid body dynamics calculations.
[1]
[4]Zero-based, least-squares, straight line method.
[5]See PCB Declaration of Conformance PS023 for details.
OPTIONAL ACCESSORIES:
Model 081A06 Mounting stud, 1/4-28 to 1/4-28 x .37 in. long, BeCu, no shoulder (1)
Entered: LK Engineer: APB
Date: 7/28/2016 Date: 7/28/2016
3425 Walden Avenue, Depew, NY 14043
Revision: G
ECN #: 45758
M6 x 0.75 Female
Negative Negative
Sealed Cable Sealed Cable
Side Side
Sales: KWW Approved: APB
Date: 7/28/2016 Date: 7/28/2016
Phone: 716-684-0001
Fax: 716-684-0987
E-Mail: info@pcb.com
Spec Number:
1239
