SANSTAND AUTDISP User Manual

PACK CONTENTS

1 x pre-assembled base unit
1 x main panel with dispenser bracket attached
1 x dispenser with key to open lid
1 x 500ml sanitiser
4 x AA batteries
1 x fittings bag containing:
4 x bolts
4 x nuts
4 x white nut caps
1 x allen key
Floor Units

ASSEMBLY INSTRUCTIONS:

1. Open the large flat box containing the
front/side panel, and remove the base unit
from the other smaller box.
2. Stand the base unit on its rubber feet, and fold
up the flaps on the side to 90° (do not fold
them back down once folded up to 90°).
3. Carefully stand front panel upright, and fold
the triangular shaped sides so they are 90° to
the front (do not fold them back flat once
folded to 90°).
4. Insert the 4 bolts through the 4 holes on the
outside of the side panel, so they align with
the holes in the base unit.
5. Place the nuts on the bolts and tighten using
the tool provided on the bolt and the white
cap on the nut.
6. Insert 4 x AA batteries into battery
compartment on bottom of dispenser.
7. Take dispenser, remove lid using white key,
remove lid, fill with sanitiser GEL and attach
to bracket on the stand.
8. Please follow detailed instructions for the
dispenser overleaf.
