- Page 1 Owner’s Manual Item #s: PEG1800, PEG3000, PEG4700, PEG5600 Have Questions or Issues? Need help with assembly? Contact us and we will resolve them within 12 hours. Support Hours: M-F 7:30-5:00 (U.S. Pacific Time) Call: Text: Email: 877-460-4511 323-201-4431 info@alpine4u.com v1.0...
-
Page 3: Table Of Contents
CONTENTS Introduction ..............4 Safety Information ............4 What’s Included ............6 Features ..............7 Specifications .............. 7 Component and Pump Parts ........8 Replacement Parts ............8 Installation Guidelines ..........9 Typical Installation: Pump Placement ......10 Typical Installation: Tube Connections .......11 Maintenance .............. -
Page 4: Introduction
At Alpine, our goal is to supply our customers with quality products that provide convenience and value to your life. We hope you enjoy your purchase and thank you for choosing Alpine: Your One Stop Shop for all your Solar, Gift, Garden and Pond Supplies. - Page 5 SAFETY INFORMATION WARNING: Risk of electric shock – This pump has not been approved for use in swimming pool or bodies of salt water. WARNING: To provide continued protection against risk of electric shock, connect to properly grounded, ground fault circuit interrupter (GFCI) outlets only, using the following guidelines: •...
-
Page 6: What's Included
WHAT’S INCLUDED WHAT’S INCLUDED Vortex™ Pump PEG1800 / PEG3000 PEG4700 / PEG5600 Hose Adapter x1 Hose Adapter x1 Mesh Bag Fits 1.25” and 1.5” Tubing Fits 1.5” and 2” Tubing Rubber Suction Feet (2 Extra) -
Page 7: Features
FEATURES Orient vertically or horizontally for maximum flexibility. Energy efficient and easy to maintain. Easy installation. No tools needed to install adapters. Operates on Land or Fully Submerged. Snap off Pre-Filter Cage for easy cleaning. SPECIFICATIONS Amps Watts GPH Flow Rate Outlet Cord Item #... -
Page 8: Component And Pump Parts
Pump Body Cover PEG1800/PEG3000 Multi Hose Adapter Fits 1.25” - 1.5” Tubing Impeller PEG4700/PEG5000 Multi Hose Adapter O-Ring Fits 1.5” - 2” Tubing REPLACEMENT PARTS Alpine Pump SKU# Alpine Replacement Part Description Impeller PEG1800 PEG1800-IMP Impeller for PEG1800 PEG3000 PEG3000-IMP... -
Page 9: Installation Guidelines
INSTALLATION GUIDELINES IMPORTANT: Only operate the pump when it has water running through it. Failure to do so will overheat the pump and cause it to fail, thus voiding the warranty. DO NOT OPERATE DRY! • You must prime the pump before plugging it in and turning it on. Priming a pump means to feed water into the tubing both in and out of the pump, to help create a suction effect to draw the water from the source. -
Page 10: Typical Installation: Pump Placement
TYPICAL INSTALLATION: PUMP PLACEMENT • The Vortex™ pump is designed to be either submerged directly into the pond or placed out of the pond as long as water is running through the pump. • To maximize pond circulation, locate the pump as far away as possible from the location of the water entering back into the water feature. -
Page 11: Typical Installation: Tube Connections
TYPICAL INSTALLATION: TUBE CONNECTIONS 1. When using the pump in the horizontal position, install the rubber suction feet. 2. The included adapter is designed to accommodate a range of tubing diameters. We recommend using the largest tubing size recommended for your pump for maximum flow. Trim the smaller sections with a hacksaw to avoid any flow restriction. - Page 12 Adapter Tubing (Trimmed) TYPICAL INSTALLATION: TUBE CONNECTIONS 5. Connect the other end of the pump tubing to an Alpine pond filter, waterfall, or water feature. Pump Pump 6. Place the pump in the mesh bag and securely tighten the drawstring around the tubing and power cord.
-
Page 13: Maintenance
MAINTENANCE WARNING: Always unplug or disconnect all appliances in the pond from the electrical supply before installing, repairing, maintaining or handling equipment in the water. To prolong the life of the pump, follow these simple maintenance procedures: • Place the pump inside the included mesh bag to protect it from damaging debris and reduce maintenance. -
Page 14: Cleaning And Replacing The Impeller
CLEANING AND REPLACING THE IMPELLER If you have thoroughly cleaned the mesh bag and pre-filter cage and still have diminished flow rates, then you will need to remove and inspect the impeller and internal pump body. IMPORTANT: The pump impeller includes a high quality ceramic shaft that provides long-lasting, reliable performance when properly maintained. - Page 15 CLEANING AND REPLACING THE IMPELLER 4. If your impeller and internal pump body have excessive scale build-up, soak with any cleaning solution that removes calcium, lime and rust. Rinse with warm water and a sponge or soft-bristled brush that won’t scratch the stainless steel.
-
Page 16: Adjusting The Adapter Angle
For 0 Degree turn Pump Cover upside down. WINTER PUMP CARE In cold climates, Alpine highly recommends to store your pump inside during the coldest months of the year. You may still use your Vortex™ pump during the winter time, but cannot be used in below freezing temperatures. -
Page 17: Troubleshooting
TROUBLESHOOTING If Your Pump Has Reduced Water Flow • Pump or tubing may be clogged, check area around pump to be sure there is no debris blocking water from entering into the pump. • It may be necessary to clean the pump pre-filter and impeller. For instructions on how to clean your pump please turn to pages 13 - 15. -
Page 18: Replacing And Disposing Of Batteries
REPLACING AND DISPOSING OF BATTERIES LIMITED 3 YEAR WARRANTY Thank you for choosing an Alpine product! We aim to please with our wide range of products including Fountains, Birdbaths, Statuary, Pond Supplies & More. All of our products are constructed from the highest quality materials. - Page 20 Purchased your product online? We would really appreciate it if you can share your experience with others by reviewing our product on the website from which you purchased. Copyright © Alpine Corporation 2021...
