Models:
Accurate indicators
Per channel:
Mute
Fault
Signal present / High impedance
Bridge (per channel pair)
Voltage Peak Limiter (VPL / CLIP)
Current Peak Limiter (CPL)
Very High Frequency (VHF)
High Temperature (TEMP)
IEC Inlet Universal Power
Supply (100-240 V)
NomadLink
In and Out ports
®
Network indicator
C 20:8X (8 x 250 W)
C 10:4X (4 x 250 W)
DIP-switch matrix
Input gain, Fan masked
Bridge mode
VPL voltage select, VPL mode
C 10:8X (8 x 125 W)
C 5:4X (4 x 125 W)
All power ratings @ 16/8/4 ohms & 70 V
Common:
Power on
Power Average Limiter (PAL)
NomadLink
®
Mains power switch
Dust filters (accessible behind grille)
Remote power active
network active
Barrier strip 2-pole output
connectors
3-pin Phoenix,
electronically balanced
input connectors
