Skil-Care BedPro Under Mattress Safety Alarm Manual

SENSOR PAD SETUP
Sensor Pad Setup For Bedpro Early Warning Undermattress System (contd.)
3. Pass sensor cable under headboard and tuck it under the Cable Strain-Relief tab before
inserting the plug into the Modular Connection (Illustration H). The strain-relief tab prevents
the plug from being accidentally dislodged and damaged. Be certain to keep cable away from
side rails and out of resident's reach. Keep cord away from side rails and out of resident's reach.
4. Place sensor pad on bed.
5. Sensor pad may be cleaned with a damp cloth and mild cleanser. Do not immerse pad in water or
cleaning solution. Do not sterilize.
6. Inspect pad before each use. Replace if damaged.
Read "Warnings" on sensor pad
Important: This UnderMattress sensor is designed to work with most mattresses and beds.
However, due to differences in mattress construction, bed designs , and resident weight, this
sensor pad may not work in all situations. Be certain to evaluate the alarm system's operation
for each bed and resident. If it does not work, you may want to consider Skil-Care's BedPro OverMattress sensor pad.
Proceed to "System Operation" on page 6. See page 6 for information about ordering replacement sensor pads.
SENSOR PAD SETUP
OverMattress
Safety Alarm
Reorder# Description Unit
BedPro OverMattress Safety Alarm with
909310 Set
10"x30" Sensor Pad - 45 Days
BedPro OverMattress Safety Alarm with
909311 Set
10"x30" Sensor Pad - 180 Days

Sensor Pad Setup for BedPro OverMattress System

1. Remove bed sheet and place sensor pad across width or length of bed (Illustration G).
2. Position connector cable toward headboard. The opposite end must be positioned below
the resident's pelvis.
3. Pass sensor cable under headboard and tuck it under the Cable Strain-Relief tab before
inserting the plug into the Modular Connection (Illustration H). The strain-relief tab prevents
the plug from being accidentally dislodged and damaged. Be certain to keep the cable away
from side rails and out of resident's reach. Keep cord away from side rails and out of resident's reach.
4. Cover mattress and sensor pad with sheet.
5. Sensor pad may be cleaned with a damp cloth and mild cleanser. Do not immerse pad in water
or cleaning solution. Do not sterilize.
6. Inspect pad before each use.
Read "Warnings" on sensor pad
Proceed to "System Operation" on page 6. See page 6 for information about
ordering replacement sensor pads.
29 Wells Ave, Yonkers, NY 10701
914.963.2040 • toll-free: 800.431.2972 • www.skil-care.com

SYSTEM OPERATION

System Operation for when the BedPro UnderMattress, Early Warning UnderMattress or
OverMattress sensor pads have been properly installed.
Whenever the alarm is initiated, pressing the "Auto-Reset" button on top of the alarm unit will silence it. Pressing this button
puts the system into stand-by mode. The system will automatically go into monitoring mode when you put your resident to bed.
H
There's no need to remember to turn the system on. Skil-Care recommends the following procedure for using the BedPro
UnderMattress, Early Warning UnderMattress and OverMattress Safety Alarm System.
• Press "Power Test" button before putting resident to bed. If "In-Room Alarm" switch is set to the "Hi or Low" position, the
alarm signal will sound and the LED will flash while the button is held down. If the "In-Room" switch is to the "Off" position,
the LED will flash while the button is held down. If the LED and/or alarm signal are not activated when the button is pressed,
check the power source connections. If alarm is on battery, replace both AA batteries. Do not use alarm system if pressing
"Power Test" button cannot activate LED and/or alarm signal.
• Place resident in bed. The LED should flash indicating that the alarm is in the monitoring mode. If LED does not flash,
remove resident from the bed and examine sensor pad. If pad is damaged, replace it. Do not use alarm system if LED does
not flash when resident is in bed.
• If alarm is set to signal both at bedside and at the nurse's station, select the preferred sound option using the selector switch
on the top of the alarm unit. Adjust the high/low toggle on the back.
• If your resident leaves the bed and then returns, the alarm will silence and the system will reset itself. Be certain to visit the
resident to make sure he/she is safe.
• Press the "Auto-Reset" button after you have removed your resident from the bed. This will place the system in the
stand-by mode.
Keep a copy of these instructions in your procedures manual. If you require extra copies of these instructions,
call Skil-Care at 1-800-431-2972 or go to skil-care.com and click on "Product-Use Instructions."
G
Replacement Sensor Pads
All BedPro replacement sensor pads are available from your medical products supplier.
All BedPro sensor pads may also be used with Skil-Care's new MultiPro Alarm
UnderMattress Replacement Sensor Pads
Reorder# Size Reorder# Size
909325 10" x 30" 909328 20" x 30"
909326 10" x 30" 909329 20" x 30"
909327 10" x 30" 909330 20" x 30"
909331 10" x 30" 909337 20" x 30"
909332 10" x 30" 909338 20" x 30"
909333 10" x 30" 909339 20" x 30"
H 909401 10" x 30" 909403 20" x 30"
909402 10" x 30" 909404 20" x 30"
909345 For Light Mattresses 39-42lbs.
OverMattress Replacement Sensor Pads
Reorder# Guarantee Reorder# Guarantee
909314 45 Days 909317 180 Days
909315 45 Days 909318 180 Days
909316/P* 45 Days 909319 180 Days
*P= 11.5" Cord
Early Warning UnderMattress Replacement Sensor Pads
Reorder# Guarantee Reorder# Guarantee
909304 90 Days 909307 180 Days
909305 90 Days 909308 180 Days
909306 90 Days 909309 180 Days
You may also order the BedPro Alarm Unit with Accessories (nurse-call connector cable, A/C adaptor and Y-connector).
See BedPro Alarm Control Unit with Accessories on page 1 for more detail.
29 Wells Ave, Yonkers, NY 10701
5
914.963.2040 • toll-free: 800.431.2972 • www.skil-care.com
Safety Alarm
Reorder#
909320
909321
909322
909323
909340
909341
909343
This alarm features an under-mattress sensor pad that is
protected against incontinence and wear by the mattress.
Unlike sensor pads that are placed on the mattress, the BedPro
UnderMattress sensor will not compromise the pressure
relieving qualities of the mattress. Placed beneath the mattress,
the BedPro sensor pad stays in place to reduce false alarms.
This is especially important for restless residents.
Guarantee Unit
90 Days Ea.
90 Days 5/pk Under Mattress Safety Alarm
90 Days 10/pk
Reorder#
180 Days Ea.
180 Days 5/pk
909301
180 Days 10/pk
One Year Ea.
909302
One Year 10/pk
Two Years Ea. This alarm system features a unique under-mattress sensor pad
that is designed to activate an alarm signal before the resident
exits the bed. The diagonally tapered sensor pad initiates the
Size Unit
alarm when the resident sits on or moves toward the edge of the
bed. Placed beneath the mattress, the sensor will not
10" x 30" Ea.
compromise the pressure relieving qualities of the mattress.
10" x 30" 5/pk
The mattress protects the sensor pad against incontinence,
10" x 30" 10/pk
resident tampering, and incontinence.
1. The BedPro Alarm Systems are not substitutes for proper supervision. Staff on a regular basis must monitor fall-risk and
Length Unit
wander-risk patients/residents.
30" Ea.
2. If batteries are used as the source, batteryt power must be checked each time the alarm is used to monitor the resident.
30" 5/pk
If battery power is weak, the two AA batteries must be replaced. The alarm will sound if batteries are weak.
30" 10/pk
3. The LED should flash when the alarm is powered, and the resident is in bed, on top of the sensor pad. If the LED fails
to flash and you are using the A/C adaptor, check connections at wall outlet and alarm unit. If you are using battery power,
replace the two AA batteries. If the LED fails to flash after connections have been checked or the batteries replaced,
discontinue use of alarm.
Alarm unit and sensor pads made in China. Instructions printed in U.S.A
6
Rev: 062017
UnderMattress OverMattress
Safety Alarm
Description Unit Reorder# Description
BedPro UnderMattress Safety Alarm with BedPro OverMattress Safety Alarm with
Set 909310
10"x30" Sensor Pad - 90 Days 10"x30" Sensor Pad - 45 Days
BedPro UnderMattress Safety Alarm with BedPro OverMattress Safety Alarm with
Set 909311
20"x30" Sensor Pad - 90 Days 10"x30" Sensor Pad - 180 Days
BedPro UnderMattress Safety Alarm with
Set
10"x30" Sensor Pad - 180 Days
Alarm Control
BedPro UnderMattress Safety Alarm with
Unit with Accessories
Set
20"x30" Sensor Pad - 180 Days
Reorder# Description
BedPro UnderMattress Safety Alarm with
Set
10"x30" Sensor Pad - 1 Year
909334 BedPro Electronic Unit without Accessories
BedPro UnderMattress Safety Alarm with
909335 BedPro Electronic Unit with Accessories
Set
20"x30" Sensor Pad - 1 Year
909336 BedPro Electronic Unit with Accessories
BedPro UnderMattress Safety Alarm for
Set GUARANTEES
Light Mattresses 39-42lbs. - 2 Year
The BedPro Safety Alarm Control Unit is replacement
guaranteed for one year following the date of purchase
Sensor Pads
45 Day
BedPro UnderMattress
a
BedPro Early Warning
BedPro OverMattress
Early Warning
Description Unit
BedPro Early Warning System with
Set These guarantees cover defects in materials and
30-inch-long sensor pad - 90 Days
workmanship under conditions of normal use. Please
BedPro Early Warning System with
return defective part to dealer from whom it was
Set
30-inch-long sensor pad - 180 Days
purchased. The dealer will send the defective part to
Skil-Care and arrange for shipment of a replacement.
CAUTIONS
Safety Alarm Unit
Unit
Set
Set
Unit
Ea.
Set
10 Pk
90 Day 180 Day 1 Year 2 Years
a
a a a a
a a
