QUICK REFERENCE GUIDE - FUNCTIONS
Maxi Sky 2 PLUS
Hand control
Tilt function
Use Reclined and Sit button to position the patient in upright or reclined position.
It only activates the leading ceiling lift when adjusting the patient's position. Regardless of
which patient positioning button is pressed, only the "foot-end" spreader bar will rise or
lower.
Control panel
200
Up Button
Down Button
Reclined Button
Sit Button
Programming / Information Button
440
001-31325-EN Rev 0 • 05/2020 • Page 1/4
Auxiliary Up-Down Button
Use up and down buttons to complete a
transfer, if a problem occurs with the hand
control.
Status LED
The LED is a complement to the display to
draw attention that a message is being
displayed on the screen.
SWL
The label indicates the safe working load of
the lift.
USB Access Port
The USB port is intended for
MAXISMART users only.
