- Page 1 USER MANUAL EX-G24-60C EX-G24-80C EX-G24-95XDP EX-G27-100C EX-G27-120XDP PLEASE KEEP THIS MANUAL FOR FUTURE REFERENCE...
- Page 2 Our technical support department has battery industry experts on standby to assist you, our valued customers, in every way they can. If, for any reason, you require assistance with your Expion360 battery system, contact us by phone or email any weekday during business hours and you will receive help from the best technical support in the industry.
- Page 3 DO NOT DISCHARGE THE BATTERY AT OR BELOW -4°F OR -20°C DO NOT DISCHARGE THE BATTERY ABOVE ITS MAXIMUM DISCHARGE RATE DO NOT LEAVE THE BATTERY CONNECTED WHEN IN STORAGE DO NOT LEAVE THE BATTERY FULLY DISCHARGED LONGER THAN 1 WEEK Expion360 Battery Manual, G24 and G27 Rev 2 07/18/2022...
-
Page 4: Table Of Contents
Battery Management System (BMS) ...................... 9 Battery Monitoring ..........................10 Charge ............................11 Discharge ............................13 Battery Life ............................17 Storage ............................18 Accessories ............................. 19 Battery Specifications ........................20 Warranty ............................21 Expion360 Battery Manual, G24 and G27 Rev 2 07/18/2022... -
Page 5: Installation
Expion360 batteries. When connecting multiple batteries with the Expion360 Bus Bars or power cables, tighten the M 8 x 1.25 hex bolts to 8 lb-ft (96 lb-in) using an adjustable torque wrench. Make sure all connections are bundled and well organized to prevent short circuits. - Page 6 Torque to 8 lb-ft (96 lb-in). Do not finger-tighten. Do not overtighten. Check thread depth vs. bolt length. The female thread depth of the battery terminals is 12 mm. Expion360 Battery Manual, G24 and G27 Rev 2 07/18/2022...
- Page 7 Battery Banks: Expion360 Battery Manual, G24 and G27 Rev 2 07/18/2022...
- Page 8 Please call technical support if your planned installation will be wired in a way not found in the provided wiring schematics. Expion360 Battery Manual, G24 and G27 Rev 2 07/18/2022...
-
Page 9: Battery Management System (Bms)
10.8 Vdc ± 0.4 Vdc, the BMS will reconnect. Some chargers will not charge if an open circuit is detected as the BMS has disconnected. We recommend using our DC-DC charger or AC-DC charger to avoid this open circuit problem and an Expion360 Battery Monitor to display voltage clearly. Overcurrent Protection: The BMS will monitor charge and discharge currents to protect the battery. -
Page 10: Battery Monitoring
The Expion360 Battery Monitor is easy to program, simple to install, and is compatible with all other brands and battery chemistries. It shows the remaining capacity (Ah), SoC (%), battery bank voltage (V), charge/discharge current (A), and charge/discharge power (W). -
Page 11: Charge
A single CC stage charger can charge the battery to nearly 100% SoC. Single-stage CC chargers with target voltage settings from 14.2 Vdc to 14.6 Vdc (14.4 Vdc preferred) may also be used to charge Expion360 batteries, however, a CC- CV charger is advised. - Page 12 25 A output current. The Expion360 DC/DC charger is simple to install and compatible with any other LiFePO battery. Within the limits of the battery bank and alternator specifications, up to two Expion360 DC/DC chargers can be used in parallel to achieve a higher charge rate.
-
Page 13: Discharge
For example, a battery bank has four 100 Ah Expion360 batteries connected in parallel. The maximum continuous discharge rate of a single Expion360 battery is 100 A (1C). The capacity of the battery bank is 400 Ah. The maximum continuous discharge rate of the battery bank is 400 A (1C). The same method applies to the recommended optimal discharge current and maximum pulse discharge current. - Page 14 Use only inverters that have been certified to conform to UL 458. For more information about pairing inverters and battery banks with capacities that are not listed above or further details about 24 Vdc, 36 Vdc, and 48 Vdc systems, please contact Expion360 technical support: Support@expion360.com...
- Page 15 ANL fuses are sufficient (at the cost of reduced system efficiency). Use fuse and breakers from the following approved manufacturers to protect against overcurrent events and ensure the safety of your Expion360 battery system: Blue Sea Systems, Littlefuse, Eaton, or Bussman. Single String Battery Bank: For small battery banks that have fewer than four batteries or have a single string configuration, circuit protection (fuse or circuit breaker) should be installed close to the battery bank’s positive terminal before connecting to the load.
- Page 16 800 A current. For more information about correctly sizing circuit protection for the battery power system, please contact an authorized installer or Expion360 technical support: Support@expion360.com +1 (541)797-6714 Expion360 Battery Manual, G24 and G27 Rev 2 07/18/2022...
-
Page 17: Battery Life
The battery is considered to reach the end-of-life (EoL) when the remaining available capacity is less than 80% of the original capacity. The cycle life of Expion360 batteries is tested at a charge/discharge rate of 0.2C/1C, 77°F, and 100% depth-of-discharge (DoD). Please note that many factors can affect battery cycle life. Using the recommended charge and discharge rates will offer longer life to your batteries. -
Page 18: Storage
Before storing, the battery bank needs to be completely isolated from any loads (DC load, inverter, etc.) and charging sources (converter charger, solar charger, etc.). The Expion360 Battery Monitor can be left on the battery bank to check the status of the battery bank. Charge the battery bank to full capacity and recalibrate the battery monitor, before using the battery bank after the storage. -
Page 19: Accessories
EX-G24_27-BUS: Aluminum bus bar (highly economic and efficient to connect batteries). EX-G24-TJ-KIT & EX-G27-TJ-KIT: Heating blanket kits for low-temperature use. EX-2000WIC & EX-3000WIC: Expion360 pure sine wave inverter chargers, 2000 W and 3000 W. For questions regarding these products, feel free to contact Expion360 technical support: Support@expion360.com... -
Page 20: Battery Specifications
-4 °F to 113 °F (-20 °C to 45 °C) Storage 3 months -4 °F to 95 °F (-20 °C to 35 °C) 6 months -4 °F to 77 °F (-20 °C to 25 °C) Discharge-Recharge Cycle every 6 months Expion360 Battery Manual, G24 and G27 Rev 2 07/18/2022... -
Page 21: Warranty
10 Warranty Online product registration is required for warranty coverage. For current warranty information please check our website: http://www.expion360.com Expion360 Battery Manual, G24 and G27 Rev 2 07/18/2022...
