QUICK START GUIDE
2
CONNECTING
Connect the X2 BaseLink to the X2 Server.
Then enable the Onboard Feed to use the
Baselink to send messages to the Racers.
Use Orbits 5.3 or higher (or other supported
3rd party software).
4
BASELINK
A
Connect X2 server to the Timing Software
C
Enabling the Onboard Feed
Go to the Distribution tab (green = on, red = o )
E
Check the Enable Onboard Feed Checkbox
B
Connect to the X2 BaseLink*
* If you can't nd the X2 BaseLink check the "not con gured" section
D
Open the Onboard Feed Setting
Click the Onboard Feed section to open the Settings window
F
Check Onboard Feed and online App Feed status
