- Page 1 Installation Guide for EdgeBox RI 4 Commerce Way Arden, NC 28704 Phone: (828) 676-1700 Fax: (828) 676-2330 WWW.HICKMANEDGESYSTEMS.COM DATE: 10/7/22 | DRN BY: PL | CKD BY: PL | DWG #: 64118-39642 | REV: A...
- Page 2 FASTENER OPTIONAL INSULATION TOP SECTION BY OTHERS MEMBRANE BY OTHERS CONCEALED JOINT SPLICE Installation Guide for EdgeBox RI Approved CORRUGATED ROOF DECK BY OTHERS ANSI/SPRI/FM4435/ES-1 TESTED FASTENER 6" F.E. / 12" O.C. (TYP. 4) BOTTOM SECTION NOTES: FINISH STRIP (TYPE 2 SHOWN) #1 - Isolate all metal parts from ACQ treated wood or other galvanically incompatible material with appropriate membrane material.
- Page 3 END CAP FASTENER @ 24" O.C. FIGURE 4 CLOSURE STEP 4 : Installing End Caps STRIP FINISH Place end cap in exposed end of bottom section, secure with STRIP provided fastener (2 per end cap). METAL DECK FIGURE 1 BY OTHERS SECTIONS STEP 1 : Installing Closure Strip &...
