3. Warnings always appear in this format:
WARNING:
4. Paired angle brackets are used to indicate a specific key on
your keyboard, for example, <ESC> means the escape key;
<CTRL> means the control key; <F1> means the F1 function
key.
5. All addresses are given in hexadecimal.

SYMBOLS AND TERMINOLOGY

Throughout this manual, the following symbols and terminology
are used:
W[ – ]
NOTE
WARNING:
PC
Reset
TTL Compatible
The warning message appears here.
Denotes a jumper block and the pins to connect.
Information under this heading presents helpful
tips for using the 5610.
Information under this heading warns you of
situations which might cause catastrophic or
irreversible damage.
Any personal computer with terminal emula-
tion software, such as an IBM PC with PC
SmartLINK.
Resetting the system hardware and software by
pushing the reset switch. Has the same results
as disconnecting power to the system, without
the potential side effects of a cold reset.
0–5V logic levels.
Preface – 2
