5610 User's Manual
Doc. #02797 Rev 0291
OCTAGON SYSTEMS CORPORATION
®
6510 W. 91st Ave. Westminster, CO 80030
Tech. Support: 303–426–4521

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5610 and is the answer not in the manual?

Questions and answers

Summary of Contents for Octagon Systems 5610

  • Page 1 5610 User’s Manual Doc. #02797 Rev 0291 OCTAGON SYSTEMS CORPORATION ® 6510 W. 91st Ave. Westminster, CO 80030 Tech. Support: 303–426–4521...
  • Page 2 COPYRIGHT Copyright 1990–94—Octagon Systems Corporation. All rights reserved. However, any part of this document may be reproduced, provided that Octagon Systems Corporation is cited as the source. The contents of this manual and the specifications herein may change without notice.
  • Page 3 IMPORTANT! Please read before installing your product. Octagon's products are designed to be high in performance while consuming very little power. In order to maintain this advantage, CMOS circuitry is used. CMOS chips have specific needs and some special requirements that the user must be aware of.
  • Page 4 Using CMOS Circuitry in Industrial Control Industrial computers originally used LSTTL circuits. Because many PC components are used in laptop computers, IC manufac- turers are exclusively using CMOS technology. Both TTL and CMOS have failure mechanisms, but they are different. This section describes some of the common failures which are common to all manufacturers of CMOS equipment.
  • Page 5 Octagon has never found a single case where multiple IC failures were not caused by misuse or accident. It is very probable that multiple component failures indicate that they were user-induced. Testing “dead” cards - For a card that is “completely nonfunctional”, there is a simple test to determine accidental over voltage, reverse voltage or other “forced”...
  • Page 6 Serial and parallel - Customers sometimes connect the serial and printer devices to the Micro PC while the power is off. This can cause the failure mentioned in the above section, Failure upon power-up. Even if they are connected with the Micro PC on, there can be another failure mechanism.
  • Page 7: Table Of Contents

    CHAPTER 1: OVERVIEW ..........5 Description ..................5 Major Features ................... 5 CHAPTER 2: INSTALLATION ........7 Equipment ..................7 Installing the 5610 Relay Card ............7 Base Addresses ................8 Terminal Block Connections ............11 Programming Example ..............12 Troubleshooting ................12 Power Module ................
  • Page 9: Preface

    The 5610 Relay Card is an eight channel relay card designed to be used with any of Octagon’s Micro PC Control Cards. This combina- tion provides a modular system which is easy to set up, modify and use.
  • Page 10: Symbols And Terminology

    W[ – ] Denotes a jumper block and the pins to connect. NOTE Information under this heading presents helpful tips for using the 5610. Information under this heading warns you of WARNING: situations which might cause catastrophic or irreversible damage.
  • Page 11: Technical Support

    TECHNICAL SUPPORT If you have a question about the 5610 Control Card and can’t find the answer in this manual, call Technical Support. They will be ready to give you the support you need. When you call, please have the following at hand: •...
  • Page 12 This page intentionally left blank. Preface – 4...
  • Page 13: Chapter 1: Overview

    Chapter 1 OVERVIEW DESCRIPTION The 5610 Relay Card is an eight channel relay card that offers a simple and cost effective solution for interfacing Octagon’s Micro PC system with general switching applications. The 5610 offers dependable, isolated switching for control of AC/DC loads in industrial applications.
  • Page 14 Addressing The 5610 is I/O mapped and occupies 16 I/O addresses. Address- ing is jumper selectable to any of 8 base I/O addresses. Device Connection External device connections are made through screw terminal strips using 12 to 22 AWG wire.
  • Page 15: Chapter 2: Installation

    Chapter 2 INSTALLATION The 5610 Relay Card uses one slot of the Micro PC card cage. It may be used with any Micro PC Control Card. The 5610 contains static sensitive CMOS WARNING: components. The greatest danger occurs when the card is plugged into a card cage.
  • Page 16: Base Addresses

    CR16 Figure 2–1—5610 Component Diagram Base Addresses The 5610 is configured at the factory to operate in most systems without any jumper changes. Jumper block W1 defines the base address. As shipped, the base address is 100H, which is jumper configuration W1[1–2, 3–4, 5–6].
  • Page 17 160H Not jumpberd 170H * = default To install the 5610 in a Micro PC card cage: Take care to correctly position the 5610 in the WARNING: card cage. The V CC and ground signals must match those on the backplane. Figure 2–2 shows the relative position of the 5610 as it is installed in the backplane.
  • Page 18 Slide the 5610 into the card cage. The components on the card should face to the left. The lettering on the card (Octagon Systems Corp.) should be on the top edge of the card and the gold contact fingers toward the backplane.
  • Page 19: Terminal Block Connections

    TERMINAL BLOCK CONNECTIONS The following table shows the connections for each relay on the 5610: Terminal Block Connections Relay Connector & Bit # Function Position # S1: J1 Bit 0 S2: J2 Bit 1 S3: J3 Bit 2 S4: J4...
  • Page 20: Programming Example

    PROGRAMMING EXAMPLE The following software example illustrates how to access a relay on the 5610 card. A relay is turned on and its status is read back. The example was written in GW BASIC. ‘turn on relay 1 and LED 10 OUT &H100,1...
  • Page 21: Chapter 3: Technical Data

    Chapter 3 TECHNICAL DATA SPECIFICATIONS The 5610 is a general purpose relay module with six Single Pole, Double Throw (SPDT) relays and two Single Pole, Single Throw (SPST) relays. The dry contacts are suitable for switching transduc- ers, temperature sensors, low level signals, and low power levels.
  • Page 22: Software Support

    Software Support The 5610 is supported by Octagon’s CAMBASIC IV software. Any software that supports I/O input and output may be used. Bus Compatibility Electrically compatible with the PC bus; designed to be used in the Micro PC card cage with Octagon’s Micro PC control cards. May be used with standard–sized PCs if used in conjunction with adaptor...
  • Page 23: Warranty

    WARRANTY Octagon Systems Corporation (Octagon), warrants that its stan- dard hardware products will be free from defects in materials and workmanship under normal use and service for the current established warranty period. Octagon’s obligation under this warranty shall not arise until Buyer returns the defective product, freight prepaid to Octagon’s facility or another specified location.
  • Page 24 RETURNING A PRODUCT FOR REPAIR Upon determining that repair services are required, the customer must: Obtain an RMA (Return Material Authorization) number from the Customer Service Department, 303-430–1500. If the request is for an out of warranty repair, a purchase order number or other acceptable information must be sup- plied by the customer.
