Summary of Contents for Rockler 66992
- Page 1 AM/FM Stereo Wireless Speaker Kit Instructions Effective July 2022 Review full instructions prior to use for important safety information. Always check Rockler.com to confirm that you are using the most recent version of instructions for your product.
-
Page 2: General Safety Warnings
• Keep children and bystanders away instructions link on the product from the tool operating area; page at Rockler.com). • Do NOT use power tools in explosive environments, or in the presence of > Before using another tool with this product, flammable liquids, fumes or dust;... - Page 3 SAFETY WARNING KEY Danger indicates a hazardous situation that, if not avoided, will result in death or serious injury. Warning indicates a hazardous situation that, if not avoided, could result in death or serious injury. Caution indicates a hazardous situation that, if not avoided, may result in minor or moderate injury or property damage.
- Page 4 PRODUCT SPECIFIC SAFETY WARNINGS CONTINUED > When working with epoxy, make sure the > Do NOT make unauthorized alterations area is well-ventilated, wear nitrile gloves to the product; doing so may compromise and use an applicator. Avoid contact with safety, regulatory compliance and skin or clothing.
- Page 5 Fig. 1 Assembly Forstner bit to drill two 1 ⁄ " holes spaced 1 ⁄ " The wires for the AM apart on center and then cutting or chiseling and FM antennas are delicate. Handle away the remaining material in between. them with care when mounting them inside the speaker enclosure.
- Page 6 Fig. 2 4. Test fit the left and right speaker units into 7. Carefully remove the backing on the their respective mounting holes. Then adhesive tape on the AM and FM antenna press fit or, if desired, epoxy them in wires connected to the control unit.
-
Page 7: Connecting To Your Device
2. Once the battery is charged, disconnect the USB cord. Make sure Bluetooth ® Check Rockler.com for updates. If you have further connectivity is enabled on your device. questions, please contact our Technical Support Department at 1-800-260-9663 or... -
Page 8: Operating Controls
Operating Controls Other than the volume knob, the controls on the display function differently in different modes. Here’s how the controls function in each mode: Bluetooth Controls - Default mode when the unit is turned on ® Volume – displays level from 1 to 30 when turned, shows LED displays “BLUE”... - Page 9 AM/FM Controls Volume – displays level from 1 to 30 when turned, shows level for 3 seconds, Tuner for then returns to FM: 87.5-108 MHz LED displays station previous display AM: 522-1710 kHz Micro USB Go to previous charging port station set during initial preset scan...
- Page 10 IDENTIFICATION OF BLUETOOTH ® ASSEMBLED PRODUCT Version 66992 AM/FM STEREO BLUETOOTH WIRELESS SPEAKER KIT ® A2DP, AVRCP FCC ID: 2AT7N-66992 Profile Transducer 50mm Changes or Output Power 2*5W modifications to this unit not expressly approved by the party responsible Frequency 150Hz-20khz for compliance could void the user’s...
- Page 11 Shop Drawings Mounting Hole Template Scale: 1" = 1"...
- Page 12 The Bluetooth ® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc., and any use of such marks by Rockler Companies is under license. 66992 Distributed by Rockler Companies, Inc. 1-800-279-4441 Rev 07/22 4365 Willow Dr. Medina, MN 55340...
