Assembly
The Wireless Speaker Kit, which includes one speaker unit with
connector wires and one control unit, can be mounted in solid
material or in a hollow or box-type structure.
If the two components are to be installed back to back, the
distance from the front of the material or box to the back
must be at least 2" but no more than 6" to allow wire connections
to be made.
1. Use a coping or scroll saw or a drill with a Forstner bit or
hole saw to cut a 1
⁄
" diameter hole for mounting the speaker
7
8
and control units. Fig. 1. Solid material will require a
through hole; a hollow box will require matching holes
in front and back.
2. Press fit or, if desired, epoxy the speaker unit into the front
of the mounting structure. Make sure you will have access
to the color-coded wires/connectors.
3. Connect the wires from the speaker unit to the control unit,
pressing the connector on the red and black wires into the
red port on the back of the control unit and the white and
black wires into the black port. Fig. 2.
4. Push the wires inside the opening and press fit or epoxy the
control unit into the rear mounting hole.
Use as a Speaker
Check to be sure your device supports Bluetooth
A2DP technology.
1. Charge the speaker by plugging the small end of the included
USB cord into the control unit and the other end into a
power source.
Note: The LED indicator light will be red while the battery is
charging and turn blue when the battery is fully charged.
Battery life is up to 6 hours.
2. Press the power/Bluetooth
unit to turn on the speaker. The blue LED will blink slowly.
®
3. Make sure Bluetooth
connectivity is enabled on your device.
4. Press and hold the power/Bluetooth
LED begins to blink quickly (about 4 seconds). This means
the speaker is ready to pair to your device.
5. "My BT Speaker" should appear on your device. Select it and
enter the password "0000," if necessary. Once a connection
has been established, the blue LED will stop flashing and
remain on. You can control speaker volume with the app you
are using to play audio.
Note: The speaker can be paired to only one device at
any given time.
®
2.1 with
®
button on the back of the control
®
button until the blue
PLEASE SEE OTHER SIDE FOR IMPORTANT SAFETY WARNINGS
Fig. 1
Fig. 2
Use as a Speaker Phone
When paired with a cellphone, the Wireless Speaker also can act
as a speaker phone.
1. Press the power/Bluetooth
answer a call.
Note: To reject a call, press and hold the button for 1 second.
2. When your conversation is over, press the power/Bluetooth
button on the speaker to end the call.
Check Rockler.com for updates to these instrutions. If you have
further questions, please contact our Technical Support Department
at 1-800-260-9663 or support@rockler.com
Wireless Speaker
Kit Instructions
®
button on the speaker to
®
