RedNeck RD-STD68BR Assembly Instructions

6x8 game changer front support bracket

RD-STD68BR

REDNECK 6X8 GAME CHANGER FRONT SUPPORT BRACKET

ASSEMBLY INSTRUCTIONS

6x8 BLIND CANNOT BE TIPPED UP LIKE OTHER BLINDS. BLIND

MUST BE PLACED ON TOP OF THE STAND AFTER STAND IS

ERECTED AND SECURED TO THE GROUND.

READ THESE INSTRUCTIONS IN THEIR ENTIRETY PRIOR TO ASSEMBLING THIS PRODUCT

WARNING! Do not remove, modify and/or omit any portion or otherwise

mechanically modify this product(s) or its assemblies in any manner.

Modification, misuse and/or part substitution shall immediately void

your factory warranty. If you suspect that a part(s) is missing and/or

defective, immediately discontinue all use of the product and contact

Redneck Outdoor Products at 877-523-9986 for replacement of missing

or defective parts.

NOTE: Some parts of this product are manufactured to be universal in

use, so there may be some parts containing holes that will not be used

in the assembly of this particular model. To minimize confusion in the

assembly process, please read these instructions in their entirety

before beginning.

Should you have any questions about the assembly, installation or use

of this product, or any other Redneck Outdoor Products, please call one

of our customer service representatives toll free at 877-523-9986.

-1-

Table of Contents

Need help?

Do you have a question about the RD-STD68BR and is the answer not in the manual?

Page 1 Should you have any questions about the assembly, installation or use of this product, or any other Redneck Outdoor Products, please call one of our customer service representatives toll free at 877-523-9986.
Page 2 VERT. SUPPORT VERT. SUPPORT UPPER RIGHT - EE UPPER LEFT - CC WELDED FRONT SUPPORT - AA VERT. SUPPORT VERT. SUPPORT LOWER RIGHT - DD LOWER LEFT - BB ITEM PART WELDED FRONT SUPPORT ASSY VERTICAL SUPPORT - LOWER LEFT VERTICAL SUPPORT - UPPER LEFT VERTICAL SUPPORT - LOWER RIGHT VERTICAL SUPPORT - UPPER RIGHT...
Page 3 STEP 1: With the Stand built, find the Welded Front Support AA. Slide the Front Support over the front of the stand as shown in Figure 10.1. Make sure the wider top flange is facing up as shown in Figure 10.2. Once the Support is pushed all the way in place the cross bar should hit with the front of the stand.
Page 4 STEP 2: Find the (4) Vertical Supports, there will be uppers, lowers and left and rights. Connect the upper and lower sections together with the (8) 3/8-16 x .1" Carriage Bolts as shown in Figure 11.2. There will be (4) bolts on each Vertical Support.
Page 5 STEP3: Once the stand is built and secured in place, and the blind is placed on top of the stand. Bolt the (4) bolts in place as instructed in the stand instructions. Once the stand is fastened to the stand locate the slots in the front of the 6x8 Support, as shown in Figure 12.2.
