RD-PLSTAIR-10
REDNECK DELUXE 10FT STAIRWAY ASSEMBLY
INSTRUCTIONS
READ THESE INSTRUCTIONS IN THEIR ENTIRETY PRIOR TO ASSEMBLING THIS PRODUCT
WARNING! Do not remove, modify and/or omit any portion or otherwise mechanically
modify this product(s) or its assemblies in any manner. Modification, misuse and/or
part substitution shall immediately void your factory warranty. If you suspect that a
part(s) is missing and/or defective, immediately discontinue all use of the product and
contact Redneck Outdoor Products at 877-523-9986 for replacement of missing or
defective parts.
NOTE: Some parts of this product are manufactured to be universal in use, so there
may be some parts containing holes that will not be used in the assembly of this
particular model. To minimize confusion in the assembly process, please read these
instructions in their entirety before beginning.
Should you have any questions about the assembly, installation or use of this product,
or any other Redneck Outdoor Products, please call one of our customer service
representatives toll free at 877-523-9986.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for RedNeck DELUXE RD-PLSTAIR-10
Summary of Contents for RedNeck DELUXE RD-PLSTAIR-10
- Page 1 To minimize confusion in the assembly process, please read these instructions in their entirety before beginning. Should you have any questions about the assembly, installation or use of this product, or any other Redneck Outdoor Products, please call one of our customer service representatives toll free at 877-523-9986.
- Page 2 FIGURE 1.1 TURN STAND PARTS INVENTORY WELDED PLATFORM ASSEMBLY QTY 1 QTY 4 RIGHT CORNER HANDRAIL QTY 2 LEG FOOT QTY 4 SMALL LEG STEM QTY 4 CROSS BRACE LEFT CORNER HANDRAIL QTY 4 QTY 2...
- Page 3 FIGURE 1.2 LADDER PARTS INVENTORY UPPER LADDER LOWER LADDER RIGHT ADAPTOR PLATE RIGHT ADAPTOR PLATE QTY 1 QTY 1 LOWER LADDER UPPER LADDER TREAD ASSY TREAD ASSY. QTY 1 QTY 1 LOWER LADDER UPPER LADDER LEFT ADAPTOR PLATE LEFT ADAPTOR PLATE QTY 1 QTY 1 LANDING LEFT...
- Page 4 FIGURE 1.3 HARDWARE INVENTORY ACTUAL SIZE 3/8" x 2 1/4" FLANGE BOLT QTY 2 3/8" FLANGE NUT QTY 75 3/8" x 2 1/4" CARRIAGE BOLT QTY 19 3/8" x 1.00" CARRIAGE BOLT QTY 42 3/8" x 3.00" CARRIAGE BOLT QTY 12...
- Page 5 PARTS & HARDWARE: STEP 2: STEM LEGS AND PLATFORM 1 - PLATFORM ASSEMBLE STEM LEG AS 4 - STEM LEGS SHOWN IN (FIGURE 2.2) REPEAT 8 - 3/8" x 2 1/4" CARRIAGE BOLTS PROCESS FOR OTHER 3 STEM LEGS. 8 - 3/8" FLANGE NUT 3/8"...
-
Page 6: Carriage Bolt
PARTS & HARDWARE: NOTE: DO NOT 2 - RIGHT CORNER HANDRAIL INSTALL THIS BOLT 5 - 3/8" x 3" CARRIAGE BOLTS AS IT WILL BE DONE 5 - 3/8" x 2 1/4" CARRIAGE BOLTS IN A LATER STEP 10 - FLANGE NUTS STEP 3: ASSEMBLE RIGHT FRONT CORNER HANDRAILS + TOP BOLTS FOR STEM LEGS... - Page 7 PARTS & HARDWARE: 7 - 3/8" x 3" CARRIAGE BOLTS 7 - 3/8" FLANGE NUTS 2 - LEFT CORNER HANRAIL STEP 4 ASSEMBLE LEFT CORNER HANDRAILS AS SHOWN LEFT CORNER HANDRAIL LEFT CORNER HANDRAIL 3/8" x 3" CARRIAGE BOLT 3/8" FLANGE NUT FIGURE 4.1...
-
Page 8: Parts & Hardware
PARTS & HARDWARE 3/8" x 1.00" CARRIAGE BOLT 24 - 3/8" x 1" CARRIAGE 24 - 3/8" FLANGE NUT 3/8" FLANGE NUT 4 - LEGS 4 - FEET STEP 5: LEGS & FEET ASSEMBLE LEGS (FIGURE 5.2) AND FEET (FIGURE 5.3) AS SHOWN. REPEAT PROCESS FOR THE OTHER 3 LEGS AND FEET NOTE: IN THIS STEP ALL CARRIAGE... - Page 9 PARTS & HARDWARE: 3/8" x 1.00" CARRIAGE BOLTS 3/8" FLANGE NUTS 4 CROSS BRACES STEP 6: CROSS BRACES ASSEMBLE CROSS BRACES TO LEGS AS SHOWN IN FIGURE 6.2 3/8" FLANGE NUT FIGURE 6.2 NOTE: IN THIS STEP ALL CARRIAGE BOLTS ARE INSTALLED FROM THE OUTSIDE WITH THE THREADS FACING 3/8"...
- Page 10 3/8" 1.00" CARRIAGE BOLT PARTS & HARDWARE 3/8" x 1" CARRIAGE BOLTS 3/8" FLANGE NUT 3/8" x 2 1/4" CARRIAGE BOLTS 3/8" FLANGE NUTS 2 UPPER STAIR CONNECTOR PLATES 2 UPPER STAIR TO PLATFORM CONNECTOR LEFT UPPER RIGHT UPPER 2 STAIR HAND RAILS STAIR ADAPTOR STAIR ADAPTOR PLATE...
- Page 11 PARTS 1 10' STAND 1 TURN PLATFORM 1 UPPER STAIR STEP 8.1: • CONNECT 10ft STAND TO TURN PLATFORM WITH UPPER STAIR. YOU WILL NEED 3 PEOPLE AND TWO 10ft A-FRAME STYLE LADDERS. START BY PLACING THE TURN STAND APPROXIMATELY 54" TO NO MORE THAN 58"...
- Page 12 HARDWARE 3/8" x 1.00" CARRIAGE BOLTS 3/8" FLANGE NUTS STEP 8.2 • POSITION THE UPPER STAIR BETWEEN THE 10' STAND AND THE TURN PLATFORM ON THE GROUND. • WITH TWO PEOPLE USING THE TWO 10' A-FRAME LADDERS ON EACH SIDE OF THE UPPER STAIR, GRAB THE UPPER STAIR ON EACH SIDE AND WALK IT UP THE LADDERS AND HOOK THE CONNECTING BRACKETS OVER THE PORCH EXTENSION.
- Page 13 HARDWARE 3/8" FLANGE NUTS 3/8" x 2 1/4" CARRIAGE BOLTS STEP 8.3 • ADJUST POSITION OF TURN PLATFORM TO ALIGN HOLES ON TURN PLATFORM WITH THE HOLES IN LANDING CONNECTING BRACKETS ON UPPER STAIR. • ASSEMBLE THE UPPER STAIR TO TURN PLATFORM USING 3/8"...
- Page 14 PARTS & HARDWARE FLANGE NUTS 3/8" X 2 1/4" CARRIAGE BOLTS RIGHT LOWER STAIR 3/8" X 1" CARRIAGE BOLTS LEFT LOWER STAIR ADAPTOR PLATE 2 LOWER PLATFORM CONNECTOR BRACKET ADAPTOR PLATE 2 STAIR HAND RAILS 2 FEET STEP 9: LOWER STAIR ASSY •...
- Page 15 PARTS & HARDWARE 3/8" x 2 1/4" FLANGE BOLT 3/8" FLANGE NUT 1 LOWER STAIR ASSEMBLY 1 TURN PLATFORM STAND STEP 10 WITH TWO PEOPLE (ONE ON EACH SIDE OF THE LOWER STAIR) LIFT THE LOWER STAIR AND HOOK THE CONNECTING BRACKETS OVER THE TURN PLATFORM ALIGNING HOLES AND ASSEMBLE USING 3/8"...
- Page 16 217.256" OVERALL STAND 95.381" O.D. STAND FEET 121.875" O.D. STAND FEET TO PLATFORM FEET 92.581" C/C STAND FEET HOLES 60.267" C/C HOLES 63.067" O.D. PLATFORM FEET...
- Page 17 R D - P L S T A I R S - 5 B O X 1 : L a d d e r , H a n d r a i l s , B r a c k e t s &...
