- Page 1 MuscleSquad 8 Pair A-Frame Dumbbell Rack Assembly & User Manual Important – Please read these instructions fully before assembly and use. These Instructions contain important information for assembly, safe use, and maintenance.
-
Page 2: Table Of Contents
Contents Safety Information Hardware Assembly Instructions Exploded Diagram Parts List Guarantee... -
Page 3: Safety Information
Safety Information – Important Please read fully before assembly or use This exercise equipment is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble, operate or use this equipment. -
Page 4: Hardware
Hardware... -
Page 5: Assembly Instructions
Assembly Instructions Step 1 Attached two Base Stabilizers (#7) to each side the Center Cross Base (#6), Aline the holes and secure each of them with two M10x60mm Allen Bolts (#9), four ¢10mm Washers (#5) and two M10 Aircraft Nuts (#8). - Page 6 Assembly Instructions Step 2 Connect the two Dumbbell Holders (#4) to the two Base Stabilizers (#7), Aline the hole and secure each of them with two M10x16mm Allen Bolts(#10) , Four ¢10mm Washers (#5) and two M10 Aircraft Nuts (#8). Attach the Connect Bracket (#1) to the top side of two Dumbbell Holders (#4), Aline the holes and secure each of them with two M10x16mm Allen Bolts(#10) , Four ¢10mm Washers (# 5) and two M10 Aircraft Nuts (#8).
-
Page 7: Exploded Diagram
Exploded Diagram... -
Page 8: Parts List
Parts List key No. Description key No. Description Connect Bracket Center Cross Base Rubber Sheet Base Stabilizer Rubber Foot M10 Aircraft Nut Dumbbell Holder M10x60mm Allen Bolt ¢10mm Washer M10x16mm Allen Bolt... -
Page 9: Guarantee
Guarantee Product Guarantee This product is guaranteed against manufacturing defects for a period of 12 Months. This product is guaranteed for twelve months from the date of original purchase. Any defect that arises due to faulty materials or workmanship will either be replaced, refunded or repaired free of charge where possible, during this period by the dealer from whom you purchased the unit.
