METRODATA NetTESTER FAMILY USER MANUAL
Metrodata NetTESTER Family
NT1003 • NT1005 • NT10G05
DATE:
DOCUMENT NO:
REVISION:
PREPARED BY:
76-02-107 Rev.A
User Manual
Software version 9.43
22nd February 2021
76-02-107
A
Martin Harvey
Metrodata Ltd
Laxton House, Crabtree Office Village
Eversley Way, Egham Surrey, TW20 8RY, UK
Tel +44 1 784 744700
E-Mail:
support@metrodata.co.uk
Website: www.metrodata.co.uk
Page 1 of 133

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NetTESTER NT1003 and is the answer not in the manual?

Questions and answers

Related Manuals for Metrodata NetTESTER NT1003

Summary of Contents for Metrodata NetTESTER NT1003

  • Page 1 METRODATA NetTESTER FAMILY USER MANUAL User Manual Metrodata NetTESTER Family NT1003 • NT1005 • NT10G05 Software version 9.43 DATE: 22nd February 2021 DOCUMENT NO: 76-02-107 REVISION: PREPARED BY: Martin Harvey Metrodata Ltd Laxton House, Crabtree Office Village Eversley Way, Egham Surrey, TW20 8RY, UK...
  • Page 2 Further, Metrodata Ltd reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Metrodata Ltd to notify any person of such revision or changes.
  • Page 3 METRODATA NetTESTER FAMILY USER MANUAL Document History 22/2/2021 Combined NetTESTER family manual, for version 9.43 software 76-02-107 Rev.A Page 3 of 133...
  • Page 4 METRODATA NetTESTER FAMILY USER MANUAL Introduction ....................... 18 Safety ......................19 Electro Magnetic Compatibility ..............19 1.2.1 EN55022 Statement ................19 1.2.2 FCC Declaration ................. 19 WEEE Directive ..................20 RoHS Compliance ..................20 Installation ......................21 Rack-Mounting ................... 21 Power Connection ..................
  • Page 5 METRODATA NetTESTER FAMILY USER MANUAL 3.2.3 Configuration Files ................28 Connecting to the Unit ..................29 Initial Serial Connection ................29 Initial LAN Connection ................30 Trouble-shooting ..................30 4.3.1 "Console Disabled" ................30 Access Control ....................31 Basic Password System................31 Password Recovery ...................
  • Page 6 METRODATA NetTESTER FAMILY USER MANUAL File Types ....................39 File System ....................39 Service Level Agreements (SLAs) ..............41 SLA Parameters ..................41 9.1.1 Bandwidth Parameters................ 41 9.1.2 Bandwidth Qualifying Parameters ............41 9.1.3 Performance Parameters ..............42 9.1.4 Others ....................42 SLA Definition and Use ................
  • Page 7 METRODATA NetTESTER FAMILY USER MANUAL 10.3.1.2.5 SLA Mode ................48 10.3.1.3 Y.1564 ................... 49 10.3.2 Test Peers ..................49 10.3.3 Test Reports ..................49 Optical Time-Domain Reflectometry (OTDR) Testing ........50 In-Service Performance Monitoring ............... 51 12.1 TWAMP...................... 51 12.1.1 Timestamp Format ................
  • Page 8 METRODATA NetTESTER FAMILY USER MANUAL 14.1.2.6 Cable Tester .................. 61 14.1.3 WAN Port (SFP interface) ..............61 14.1.3.1 SFP Type ..................61 14.1.3.2 SFP details ..................62 14.1.3.3 Speed .................... 62 14.1.3.4 Duplex ................... 63 14.1.3.5 Auto Negotiation ................63 14.1.3.6 Negotiated ..................
  • Page 9 METRODATA NetTESTER FAMILY USER MANUAL 14.1.5.10 Colour Marking ................67 14.1.5.10.1 PCP->Green ................. 67 14.1.5.11 Multiple SLA mode ..............67 14.1.6 SLA definition (multiple-SLA mode) ............ 67 14.1.6.1 Remove ..................68 14.1.7 Unit Information .................. 68 14.1.7.1 Node Name ................... 69 14.1.7.2 Software Version ................
  • Page 10 METRODATA NetTESTER FAMILY USER MANUAL 14.1.9.5.1 Destination, Mask ..............74 14.1.9.5.2 Gateway.................. 74 14.1.9.5.3 Interface .................. 74 14.1.9.5.4 Delete Entry ................74 Menu Tree: Main Set-Up ................. 74 14.1.9.6 Remote Management ..............74 14.1.9.7 TFTP Server, Interface ..............74 14.1.9.8 Time Server ................... 74 14.1.10...
  • Page 11 METRODATA NetTESTER FAMILY USER MANUAL 14.2.1.6 Results ..................78 14.2.2 Traceroute ..................78 14.2.2.1 Destination IP, Interface ..............78 14.2.2.2 Packet Size ................... 79 14.2.2.3 Max Hops ..................79 14.2.2.4 Receive Timeout ................79 14.2.2.5 Start / Stop ..................79 14.2.2.6 Results ..................
  • Page 12 METRODATA NetTESTER FAMILY USER MANUAL 14.2.6.1.2.3 Rate .................. 84 14.2.6.1.3 SLA ..................85 14.2.6.1.3.1 SLA selection ..............85 14.2.6.1.3.2 Bandwidth parameters ............. 85 14.2.6.1.3.2.1 Use Remote SLA ............86 14.2.6.1.3.3 Other Parameters ............. 86 14.2.6.2 Test Parameters (Basic Test) ............86 14.2.6.2.1 Packet Size/Mix ..............
  • Page 13 METRODATA NetTESTER FAMILY USER MANUAL 14.2.6.3.5.1 Perform Test ..............90 14.2.6.3.5.2 Upper Limit ............... 90 14.2.6.4 Test Parameters (Y.1564) ............. 91 14.2.6.4.1 Frame Size / Mix ..............91 14.2.6.4.2 User Defined Size ..............91 14.2.6.4.3 Colour Aware ................91 14.2.6.4.4 Stop on Fail ................91 14.2.6.4.5 Configuration Test ..............
  • Page 14 METRODATA NetTESTER FAMILY USER MANUAL 14.2.6.6.5 Peer Name ................96 14.2.6.6.6 MAC Address ................96 14.2.6.6.7 MAC Modifier ................96 14.2.6.7 Test Peer (Layer 3) ............... 97 14.2.6.7.1 C-VLAN................... 97 14.2.6.7.2 Remote IP ................97 14.2.6.7.3 Interface .................. 98 14.2.6.7.4 Ping ..................98 14.2.6.7.5 UDP Port .................
  • Page 15 METRODATA NetTESTER FAMILY USER MANUAL 14.2.9.2 Pattern ..................104 14.2.9.3 Polarity ..................104 14.2.9.4 Results ..................104 14.3 Performance Monitoring ................104 14.3.1 Name ....................105 14.3.2 Active ....................105 14.3.3 Peer Connection ................105 14.3.3.1 C-VLAN ..................106 14.3.3.2 Remote IP ................... 106 14.3.3.3 Interface ..................
  • Page 16 METRODATA NetTESTER FAMILY USER MANUAL 14.3.8 Reports ..................... 111 14.3.8.1 Temporary Report ............... 113 14.3.8.2 15 Minute Reports ............... 113 14.3.8.3 24 Hour Totals ................114 14.3.8.4 24 Hour Reports ................. 114 14.3.8.5 30 Day Totals ................114 14.3.8.6 Clear Data ................... 114 14.3.9...
  • Page 17 METRODATA NetTESTER FAMILY USER MANUAL 14.5.4.3 Transfer status ................119 14.5.4.4 Programming status ..............119 14.5.4.5 Get file from TFTP server ............120 14.5.4.6 Get file from browser (web) ............120 14.5.4.7 Use file to program software............120 14.5.4.8 Delete file ..................121 14.5.5...
  • Page 18 METRODATA NetTESTER FAMILY USER MANUAL 1 INTRODUCTION The Metrodata NetTESTER NT1003, NT1005 and NT10G05 form a family of highly featured, cost effective Ethernet service test and performance monitoring devices. Based on the same hardware platform as the Metrodata MetroCONNECT family of...

  • Page 19: Electromagnetic Compatibility

    METRODATA NetTESTER FAMILY USER MANUAL Figure 1.1 NetTESTER family All connectors and LED status indicators are accessible from the rear of the unit. 1.1 Safety The EDD unit must not be connected to cabling which would be required by BS6701 to be equipped with over voltage protection.

  • Page 20: Weee Directive

    METRODATA NetTESTER FAMILY USER MANUAL 1.3 WEEE Directive The unit is covered by Directive 2002/96/EC (OJ:L37/24/2003) on Waste Electrical and Electronic Equipment ( WEEE ). It must therefore not be disposed of in standard landfill. 1.4 RoHS Compliance The unit is compliant with the EU RoHS Directive 2002/95/EC. The RoHS directive bans the use of six hazardous materials in products placed on the market after July 2006.

  • Page 21: Installation

    METRODATA NetTESTER FAMILY USER MANUAL 2 INSTALLATION 2.1 Rack-Mounting The NT1003 and NT1005 are standalone, desktop units. However, they may be mounted in a standard 19-inch rack using the appropriate rack mounting kit. One or two single-supply units may be mounted in a 1U rack space using the mounting kit part number 80-05-256.

  • Page 22: Power Connection

    METRODATA NetTESTER FAMILY USER MANUAL Figure 2.2 Rack-mounting dual-supply NT1005 Note: When rack-mounting NT1003 and NT1005 units, ensure that the bit switches on the underside of the unit(s) are correctly configured prior to fitting the assembly in the rack (see section 2.3).
  • Page 23 METRODATA NetTESTER FAMILY USER MANUAL Figure 2.4 Dual-AC supply NT1005 Both AC- and DC-powered versions of all 3 NetTESTER units are available. Some are also available with dual redundant supplies, as shown below. Unit Single AC Single DC Dual AC...

  • Page 24: Configuration Switches

    METRODATA NetTESTER FAMILY USER MANUAL Power connection is via a standard 3-pin circular connector. Pin assignments are shown below. Function -48V / 24V Protective Earth Table 2.4 DC power connector pin assignment DC powered units also have an external earth stud which must be securely connected to an earth connection in order to ensure EMC compliance.
  • Page 25 METRODATA NetTESTER FAMILY USER MANUAL Switches 1 to 5 are used to configure the default setting for the WAN/Network port. These are intended primarily for use in conjunction with the Zero-Touch Configuration system (see below), where communication over the WAN port must operate immediately from cold-start.
  • Page 26 Table 2.8 Bit-switch 5 2.3.5 Switch 6: Proxy Client Switch 6 can be used to enable a client for the Metrodata Proxy protocol on the WAN/Network port. This switch should be left in the default position. Proxy client mode disabled Proxy client mode enabled Table 2.9 Bit-switch 6...

  • Page 27: Configuration Management

    METRODATA NetTESTER FAMILY USER MANUAL 3 CONFIGURATION The terms configuration and settings are used interchangeably to refer to the set of data that controls how the unit operates. The data can be modified, saved, retrieved and transferred in various ways.
  • Page 28 METRODATA NetTESTER FAMILY USER MANUAL 3.2.2 Saved Configuration The unit has a non-volatile store that holds a complete set of configuration data. It is important to note that this is separate from the 'running' configuration (the settings reflecting the current operation of the unit). When the 'save settings' option is selected (see section 14.5.5), the running configuration values are copied to the...

  • Page 29: Connecting To The Unit

    METRODATA NetTESTER FAMILY USER MANUAL 4 CONNECTING TO THE UNIT 4.1 Initial Serial Connection The unit is equipped with a standard RS-232/V.24 terminal interface presented on a 9-way female D-type connector (NT1003, NT1005) or RJ45 connector (NT10G05). The D-type connector uses the standard DCE pin-out, allowing direct connection to a PC serial port or USB serial adaptor.

  • Page 30: Troubleshooting

    METRODATA NetTESTER FAMILY USER MANUAL The default settings for the terminal port are shown below: Baud Rate 19200 Data Bits Parity None Stop Bits Table 4.3 Default terminal port settings 4.2 Initial LAN Connection The unit can always be accessed using a special fixed IP address via one specific interfaces, allowing management via SSH, even directly following a cold-start.

  • Page 31: Access Control

    5.3 User Interface Advanced Mode The NetTESTER offer a simplified version of the user interface found on the Metrodata EDD family products. Parts of the EDD functionality that are not normally relevant to the tester application have been removed. Should they be needed, however, these hidden functions can still be accessed by switching the user interface to 'Advanced Mode'.
  • Page 32 METRODATA NetTESTER FAMILY USER MANUAL Reference should be made to the EDD family user manual [1] for more guidance on using the advanced mode. It is recommended that the mode is accessed in order to make simple changes to default settings that are not accessible from the normal tester user interface.
  • Page 33 METRODATA NetTESTER FAMILY USER MANUAL 6 VLANS AND TAGGING IEEE 802.1Q [2] defines the concept of a Virtual LAN (VLAN), a mechanism for partitioning traffic that is carried over a physical LAN so that it appears as a number of separate LAN connections. This is done by adding an extra 4-byte 'tag' near the start of each packet, which identifies the VLAN to which it belongs using a number in the range 1-4095 (the VLAN ID).

  • Page 34: Management Interfaces

    METRODATA NetTESTER FAMILY USER MANUAL 7 LAYER 3/4 OPERATION: TCP/IP AND UNIT MANAGEMENT The unit is primarily a Layer 2 (VLAN and Ethernet) device, but Layer 3/4 (TCP/IP) functionality is includes in order to provide the following: • Access to the unit's user interface via a network (as opposed to a terminal) connection.
  • Page 35 METRODATA NetTESTER FAMILY USER MANUAL Since a Windows PC will typically fall back to using an Automatic Private IP address if it fails to find a DHCP server, randomly selecting an address in the 169.254.x.x range, the unit should become accessible without having to change any settings on the PC.

  • Page 36: Telnet And Ssh

    METRODATA NetTESTER FAMILY USER MANUAL Note: Modern web browsers tend to open several TCP connections at once for a single session, so the connection limit is likely to be reached sooner than expected when using HTTP access. 7.5 Telnet and SSH Telnet [3] and SSHv2 [4] are both protocols offering terminal-like access to the unit over a network connection.
  • Page 37 METRODATA NetTESTER FAMILY USER MANUAL SNMP runs over UDP/IP. The messages support a small number of primitive operations (read, write, etc.) Unsolicited messages from the agent, known as notifications or traps, are also supported. Various versions of the protocol exist. The unit support versions 1 and 2c.
  • Page 38 METRODATA NetTESTER FAMILY USER MANUAL tftp -i 192.168.0.11 put demo.cfg settings/demo.cfg To transfer a file from the unit, the command line would be: tftp –i <unit ip address> get <unit filename> <pc filename> As an example, the following command would read a configuration file named demo.cfg from the unit and save this on the PC.

  • Page 39: File System

    METRODATA NetTESTER FAMILY USER MANUAL 8 FILE SYSTEM 8.1 File Types Files can be of 3 different types: Software File This type of file contains software to be programmed into the unit. Configuration File This type of file contains the information necessary to define all the configuration settings of a unit (see section 3.2.3).
  • Page 40 METRODATA NetTESTER FAMILY USER MANUAL Figure 8.1 File system, as seen by SFTP client Files contained in each of the folders may be read and (except for the report files) written, over-written, renamed or deleted by an external client (though only SFTP supports renaming and deleting).
  • Page 41 METRODATA NetTESTER FAMILY USER MANUAL 9 SERVICE LEVEL AGREEMENTS (SLAS) The unit uses the concept of a Service Level Agreement (SLA) as proposed by MEF [6] This defines the service supplied to the customer by the provider in terms of a list of measurable parameters with minimum acceptable values for each.
  • Page 42 METRODATA NetTESTER FAMILY USER MANUAL 3. Utilisation. As above, but both the preamble and inter-packet gap (IPG, 12 bytes) are included. Include Tags Where packets are tagged, the tag bytes may be included or excluded for IR purposes. Separate controls are available for c-tags, s- tags and tags that are to be added by external equipment.
  • Page 43 METRODATA NetTESTER FAMILY USER MANUAL FTD/IFDV In order to comply with the SLA, FTD and Percentile IFDV parameters must be satisfied by a portion of packets specified by this percentile value. Maximum Performance parameters apply only to Transmission Unit packets up to the size specified. Larger packets may be passed at the provider's discretion, with no performance assurances.

  • Page 44: Loopback Function

    METRODATA NetTESTER FAMILY USER MANUAL 10 SERVICE ACTIVATION TESTING Service Activation Testing is the term used to describe testing of a service prior to it carrying any live traffic. Simulated traffic is generated and used to measure aspects of the service performance. This can then be compared to the Service Level Agreement (SLA), to provide confidence that this will be met in the live environment, or to give advance warning of potential problems.
  • Page 45 METRODATA NetTESTER FAMILY USER MANUAL 00:C0:81:4x.xx.xx* Any User * - x.xx.xx is the remainder of the unit MAC address, i.e. this is the unit MAC address modified by setting either bit 23 or 22. ** - These are referred to in places as "Magic MAC" addresses.
  • Page 46 Further, packets carrying a UDP payload will have their UDP source/destination ports swapped and the UDP checksum set to zero. The Layer 4 mode is intended for use where the traffic comes from a Metrodata device operating in 'Layer 3' tester mode (see below).
  • Page 47 METRODATA NetTESTER FAMILY USER MANUAL 10.3.1.1 Basic Test The basic test regime, as the name suggests, allows for simple tests with specified rate, duration and packet size(s). Two such tests, with independent parameters, may be run in sequence, allowing for a short 'go/no-go' phase, followed by a longer 'soak' phase.
  • Page 48 METRODATA NetTESTER FAMILY USER MANUAL Once the binary search has produced a result, it is normal to perform a longer test at this rate, although this may be disabled if the fastest possible execution is required. The longer test helps to eliminate results that are marginally higher than they should be, produced by a combination of the short test time used in the search phase and buffering within the network.
  • Page 49 METRODATA NetTESTER FAMILY USER MANUAL • Each element of the test for each packet size is awarded a pass or fail by comparison with the SLA, and these are combined to produce an overall pass/fail result. 10.3.1.3 Y.1564 Y.1564 [8] defines a testing methodology that is tied directly to the concept of the SLA, and which addresses the problem (with RFC2544) of excessively long testing times.
  • Page 50 METRODATA NetTESTER FAMILY USER MANUAL 11 OPTICAL TIME-DOMAIN REFLECTOMETRY (OTDR) TESTING The unit can be used with a range of special SFP single-mode fibre modules, supplied by Optical Zonu [9], which have an integrated Optical Time-Domain Reflectometry (OTDR) measurement facility. With an OTDR SFP module fitted, the...
  • Page 51 METRODATA NetTESTER FAMILY USER MANUAL 12 IN-SERVICE PERFORMANCE MONITORING In-Service Performance Monitoring (normally referred to simply as performance monitoring, or PM) is the process of ensuring that a service continues to meet the performance requirements (SLA) once it has started to carry live traffic.

  • Page 52: Timestamp Format

    TWAMP messages. This is controlled globally, and can only be changed from the Advance Mode user interface. For strict compliance with RFC5357, the NTP (TWAMP) option should be selected. Where the peer is a Metrodata product running software version 9.37 or older, the PTP (Y.1731) option should be selected. For Metrodata peers running newer software, either option may be used, but the same selection must be made on both units.

  • Page 53: User Interface

    METRODATA NetTESTER FAMILY USER MANUAL 13 USER INTERFACE The unit is configured and managed using a menu-driven user interface, accessible via terminal, Telnet, SSH or HTTP (web) connection. Refer to section 4 for guidance on establishing a connection, and section 7 for more on management of the unit via a network connection.
  • Page 54 METRODATA NetTESTER FAMILY USER MANUAL Metrodata NetTESTER NT1005 "NT1005_0017e4" Alarms: none MAIN SET-UP Settings <menu> Testing <menu> Perf monitoring <menu> Otdr <display> Maintenance <menu> CAPITAL letter - select item <escape> - exit menu In VT100/VT220 or ANSI mode, the same menu will appear as shown below.
  • Page 55 METRODATA NetTESTER FAMILY USER MANUAL If the item is a sub-menu (indicated by <menu> in the right-hand column), then the new menu will be displayed. The entire user interface is arranged as a tree structure, which is navigated by entering sub-menus in this way, and by returning to a parent menu by pressing the <ESCAPE>...
  • Page 56 METRODATA NetTESTER FAMILY USER MANUAL Mouse-clickable buttons replace the single-key selection system. The left-hand portion of the browser window shows the menu tree leading to the current screen. Items on this tree can be clicked in order to move to parent menus. A logout button is always accessible at the top left of the window.
  • Page 57 METRODATA NetTESTER FAMILY USER MANUAL 5400 5400s 1:30:00 13.3.2 Bandwidth Values Large values like bandwidths may be entered as a number followed by the letter k, m or g. These act as shorthand for 3, 6 and 9 zeros respectively. For example, the...

  • Page 58: User Interface Reference

    METRODATA NetTESTER FAMILY USER MANUAL 14 USER INTERFACE REFERENCE 14.1 Settings Menu Tree: Main Set-Up / Settings SETTINGS Wan port <menu> User port <menu> <menu> unit Info <menu> Access control <menu> Mgmt interface <menu> sNmp <menu> Store settings 14.1.1 WAN Port...
  • Page 59 METRODATA NetTESTER FAMILY USER MANUAL WAN PORT Interface Copper oper status max spEed 1000M max Duplex Full auto-negotiation Enabled negotiated 1000M/FD Mdi/mdix Auto caBle tester <display> 14.1.2.1 Speed / Max Speed Menu Tree: Main Set-Up / Settings / WAN Port / (Max) spEed The Speed parameter has two meanings depending upon whether auto negotiation is enabled or not.
  • Page 60 METRODATA NetTESTER FAMILY USER MANUAL Half Advertise Half Duplex Full Advertise Half Duplex, Full Duplex 14.1.2.3 Auto Negotiation Menu Tree: Main Set-Up / Settings / WAN Port / Auto-Negotiation Auto Negotiation allows the port to automatically determine the best operating parameters for the port.
  • Page 61 METRODATA NetTESTER FAMILY USER MANUAL LAN/RJ45 ports support auto switching technology whereby the port will automatically detect whether it should be MDI or MDIX and will configure itself accordingly. With auto switching ports, only straight patch cables are required. The options are:...
  • Page 62 METRODATA NetTESTER FAMILY USER MANUAL Brief type information from the SFP module is displayed here. If no module is present this will show Not Fitted. If type information cannot be read (usually because of incorrect module programming), Unknown will show.
  • Page 63 METRODATA NetTESTER FAMILY USER MANUAL For fibre ports, the speed setting sets the operating speed of the port with valid options of: 100M 100 Base FX Fast Ethernet 1000M 1000 Base X Gigabit Ethernet Auto In the auto mode, the SFP module is read and the port parameters are set according to the SFP type installed.
  • Page 64 METRODATA NetTESTER FAMILY USER MANUAL 14.1.3.6 Negotiated Menu Tree: Main Set-Up / Settings / WAN Port / Negotiated When auto negotiation is enabled, the negotiated display item shows the operating mode that has be negotiated between the link partners. 10M/HD...
  • Page 65 METRODATA NetTESTER FAMILY USER MANUAL 14.1.5.2 Bandwidth Menu Tree: Main Set-Up / Settings / SLA / Bandwidth The bandwidth menu enables the configuration of the data rate parameters for the SLA. BANDWIDTH bandWidth Utilisation include s-Tag Include c-tag eXternal tags 14.1.5.2.1...
  • Page 66 METRODATA NetTESTER FAMILY USER MANUAL 14.1.5.2.5 Bandwidth Menu Tree: Main Set-Up / Settings / SLA / Bandwidth / BandWidth The bandwidth configuration item defines what is actually included in the SLA bandwidth calculations: Information Rate Packet from DA to FCS...
  • Page 67 METRODATA NetTESTER FAMILY USER MANUAL 14.1.5.7 Severely Errored Second Threshold Menu Tree: Main Set-Up / Settings / SLA / SES Threshold The threshold used to determine SESs and availability. Specified as per FLR. 14.1.5.8 Delay Percentile Menu Tree: Main Set-Up / Settings / SLA / Delay Percentile The percentile value used in conjunction with the FTD and IFDV values.

  • Page 68: Unit Information

    METRODATA NetTESTER FAMILY USER MANUAL SLAs ---- Name ------------------------------------------------------------------------- Gold Service 1G <Esc> - exit, 1.. - details, * - new, <Enter> - refresh In this case, an SLA called 'Gold Service 1G' has already been defined which has a CIR of 1G.
  • Page 69 METRODATA NetTESTER FAMILY USER MANUAL UNIT INFO Node name NT10G05_001bde software version Main 9.43 / Boot 5.21 serial nUmber mac address 00:c0:81:00:1b:de Time/date <menu> 14.1.7.1 Node Name Menu Tree: Main Set-Up / Settings / Unit Info / Node name To enable identification of the unit, it is useful to enter a meaningful name. This will be displayed at the top of every user interface screen, appear in test reports (see section 8), and be used to identify the unit in a number protocols.
  • Page 70 METRODATA NetTESTER FAMILY USER MANUAL 14.1.7.7 Time Zone Menu Tree: Main Set-Up / Settings / Unit Info / Time/Date / time Zone Since NTP uses GMT as the baseline time, time zone adjustment is required to enable the correct time to be displayed wherever the unit is deployed globally, and to allow for daylight saving.
  • Page 71 METRODATA NetTESTER FAMILY USER MANUAL Enter new password Enter>******** Verify> Re-enter the new password to verify the change. If the password is verified the unit will assume the new password for the next logon. 14.1.8.1.1 Default Password The default unit password is the product name (nt1003, nt1005 or nt10g05) and must be entered in lower case.

  • Page 72: Management Interface

    METRODATA NetTESTER FAMILY USER MANUAL WELCOME SCREEN -------------- ******************************** * Metrodata NetTESTER NT10G05 Welcome Please Log In... ******************************** <Esc> - exit, <Enter> - refresh 14.1.8.4 Advanced Mode Menu Tree: Main Set-Up / Settings / Access Control / Advanced Mode 14.1.9...

  • Page 73: Ip Routing Table

    METRODATA NetTESTER FAMILY USER MANUAL DHCP is always enabled when ZTC is used. 14.1.9.3 IP Address Menu Tree: Main Set-Up / Settings / Mgmt Interface / IP Addr In order to access the unit remotely it must be configured with an IP address. This may be obtained either using DHCP, in which case this will be configured automatically, or Manually if DHCP is disabled.
  • Page 74 METRODATA NetTESTER FAMILY USER MANUAL ROUTING TABLE ENTRY Destination 0.0.0.0 Mask 0.0.0.0 Gateway 10.1.1.254 Interface MGMT dElete entry 14.1.9.5.1 Destination, Mask Menu Tree: Main Set-Up / Settings / Mgmt Interface / Routing table / [entry] / Destination Main Set-Up / Settings / Mgmt Interface / Routing table / [entry] / Mask Specify which destination addresses this entry applies to.
  • Page 75 METRODATA NetTESTER FAMILY USER MANUAL The unit supports management access via SNMP v1 or v2c, which may be configured using the SNMP menu, SNMP Read community public Write community public Trap community public Managers <menu> contact Person Metrodata Limited,Laxton House,C rabtree Office Village,Eversley Way,Egham,Surrey,England,Tel.
  • Page 76 METRODATA NetTESTER FAMILY USER MANUAL 1 - 192.168.100.45 IP address 192.168.100.45 interFace LAN1 Access rights Read-Write receives Traps snmp Version SNMPv2c Remove manager 14.1.10.2.1.1 IP Address Menu Tree: Main Set-Up / Settings / SNMP / Managers / [manager] / IP Address An IP address is required for the manager.
  • Page 77 METRODATA NetTESTER FAMILY USER MANUAL The SNMP Location is the MIB-2 SysLocation object. This item is used to show the detailed location of the device. This item is a string of up to 255 characters. 14.2 Testing Menu Tree: Main Set-Up / Testing The test menu serves two functions, it gives access to the Layer 1 port loopback functions and also gives access to the SAM (Service Assurance Module) functions.
  • Page 78 METRODATA NetTESTER FAMILY USER MANUAL 14.2.1.4 Menu Tree: Main Set-Up / Testing / Ping / TTL The TTL item defines the IP Time to Live parameter for the packet IP header. 14.2.1.5 Start / Stop Menu Tree: Main Set-Up / Testing / Ping / Start...
  • Page 79 METRODATA NetTESTER FAMILY USER MANUAL Main Set-Up / Testing / Traceroute / InterFace The destination IP address is used to define the TraceRoute target. 14.2.2.2 Packet Size Menu Tree: Main Set-Up / Testing / Traceroute / Packet SiZe The packet size may be defined in the range 64 to 1518 bytes 14.2.2.3...
  • Page 80 METRODATA NetTESTER FAMILY USER MANUAL SAM TESTER sam Function Disabled 14.2.3.1 SAM Function Menu Tree: Main Set-Up / Testing / SAM Tester / SAM Function The Mode menu item selects the operating mode of the SAM module. The item is a...
  • Page 81 METRODATA NetTESTER FAMILY USER MANUAL The loopback can be selected to operate at one of 3 different 'Layers': All packets addressed to either the 'magic' MAC address or the modified unit MAC address will be looped. Source and destination MAC addresses will be swapped.
  • Page 82 METRODATA NetTESTER FAMILY USER MANUAL Disabled The tester operates in single-test mode. Only one test may be defined. Sequential Multiple tests may be defined, and they will run in sequence (each starting immediately after the previous one finishes). See section 14.2.6.12.
  • Page 83 METRODATA NetTESTER FAMILY USER MANUAL Menu Tree: Main Set-Up / Testing / SAM Tester / Report Settings / report Header / Display header This screen displays the report header as it will appear: Test Report Header ------------------ *************************************************** Metrodata Service Configuration Test Test Method: Y.1564...
  • Page 84 METRODATA NetTESTER FAMILY USER MANUAL TEST PARAMETERS Regime Basic traIning <menu> <menu> Packet size/mix User user-defined Size 1518 phase 1 rAte phase 1 Duration disabled phase 2 raTe phase 2 dUration 2:00 stop on Fail dEtailed report 14.2.6.1.1 SAM Test Regime Menu Tree: Main Set-Up / Testing / SAM Tester / Test Parameters / Regime The test regime selects how the traffic generator is to be controlled.
  • Page 85 METRODATA NetTESTER FAMILY USER MANUAL Menu Tree: Main Set-Up / Testing / SAM Tester / Test Parameters / TraIning / Rate The training FPS (frames per second) defines the frame rate used during the training period. The packet size will be the same as the main test (or the smallest, if there are multiple sizes).
  • Page 86 METRODATA NetTESTER FAMILY USER MANUAL BANDWIDTH use remote sla 500M * bandwidth Utilisation include s-tag include c-tag external tags To revert a parameter to the value from the SLA definition, enter a value of zero. 14.2.6.1.3.2.1 Use Remote SLA Menu Tree: Main Set-Up / Testing / SAM Tester / Test Parameters / SLA / Bandwidth / Use Remote SLA bandwidth parameters can be communicated from a L2 peer via the MDP protocol and these may be used to override the local SLA values if required.
  • Page 87 METRODATA NetTESTER FAMILY USER MANUAL A system of standard packet sizes and letter codes (borrowed from Y.1564) is used for all regimes. These are shown below: Code Packet Size (bytes) 1024 1280 1518 2048 4000 6000 8000 10000 MTU - the service MTU size User - a user-defined size Packet sizes may be entered as letter codes or (for the fixed sizes) as numbers.
  • Page 88 METRODATA NetTESTER FAMILY USER MANUAL The rate can be specified as a bandwidth, entered in one of the standard formats (see section 13.3.2), or tied to the SLA CIR value by entering a value of zero. 14.2.6.2.4 Phase 1/2 Duration...
  • Page 89 METRODATA NetTESTER FAMILY USER MANUAL The default (RFC2544 compliant) setting is 64,128,256,512,1024,1280,1518. Values may be entered in letter or number format (see section14.2.6.2.1). 14.2.6.3.2 Frame Format Menu Tree: Main Set-Up / Testing / SAM Tester / Test Parameters / Frame Format RFC2544 specifies an IP payload for the test packets.

  • Page 90: Back-To-Back Test

    METRODATA NetTESTER FAMILY USER MANUAL When SLA mode is selected, a pass threshold for the throughput test can be specified (as a percentage of CIR). The default is 100%. 14.2.6.3.4 Latency Test Menu Tree: Main Set-Up / Testing / SAM Tester / Test Parameters / LAtency Test...
  • Page 91 METRODATA NetTESTER FAMILY USER MANUAL The upper limit sets the maximum result (in bytes) that will be tested. For a meaningful result, this must a value at which the test is known to fail. 14.2.6.4 Test Parameters (Y.1564) Menu Tree: Main Set-Up / Testing / SAM Tester / Test Parameters...
  • Page 92 METRODATA NetTESTER FAMILY USER MANUAL The configuration test phase is intended to be a rapid check of the defined SLA and performs a series of short tests to validate it. The configuration test menu is as shown below: CONFIGURATION TEST...
  • Page 93 METRODATA NetTESTER FAMILY USER MANUAL Menu Tree: Main Set-Up / Testing / SAM Tester / Test Parameters / CoNfiguration Test / Policing Test This test verifies that operation of any policing mechanism by using the full CIR and exceeding the EIR.
  • Page 94 METRODATA NetTESTER FAMILY USER MANUAL Menu Tree: Main Set-Up / Testing / SAM Tester / Test Parameters / PerfOrmance Test / Performance Test The performance test may be performed or skipped. 14.2.6.4.6.2 Test Time Menu Tree: Main Set-Up / Testing / SAM Tester / Test Parameters / PerfOrmance Test / Test Time The performance test is performed for the test time.
  • Page 95 METRODATA NetTESTER FAMILY USER MANUAL COLOUR & PCP Colour marking Green pcp Yellow pcp 14.2.6.5.2.1 Colour Marking, Green/Yellow PCP Menu Tree: Main Set-Up / Testing / SAM Tester / Peer / Colour Marking Menu Tree: Main Set-Up / Testing / SAM Tester / Peer / Green PCP...
  • Page 96 If a peer is selected by name (see above), then the MAC address will be filled automatically. An address may be entered manually if required. In the case of a Metrodata EDD device, this should be the device's unmodified address.
  • Page 97 If a peer is selected by name (see above), then this will be filled automatically. Where a MAC address has been manually entered, this item will also need to be set. Where it is a Metrodata EDD device, the modifier applied must match the direction from which the peer will see test traffic arrive.
  • Page 98 METRODATA NetTESTER FAMILY USER MANUAL 14.2.6.7.3 Interface Menu Tree: Main Set-Up / Testing / SAM Tester / Peer / Interface The local IP settings must be configured if the test runs over a C-VLAN that has not already been configured for use by another test channel or a performance monitoring session.
  • Page 99 METRODATA NetTESTER FAMILY USER MANUAL 14.2.6.9 Start Test, Stop Test Menu Tree: Main Set-Up / Testing / SAM Tester / Start Test Menu Tree: Main Set-Up / Testing / SAM Tester / Stop Test Use these commands to start the test or stop a test that is currently running.
  • Page 100 METRODATA NetTESTER FAMILY USER MANUAL Viewing the report whilst a test is running will show the report as it is compiled, in real-time. Once the test has ended, the completed report may be viewed. 14.2.6.12 Send Report Menu Tree: Main Set-Up / Testing / SAM Tester / SEnd Report Once a report has been generated, it will normally be sent to the TFTP server automatically.
  • Page 101 METRODATA NetTESTER FAMILY USER MANUAL TEST CHANNEL #1 Name Test1 Test parameters <menu> Peer <menu> state Running Stop tests proGress <display> View report <display> sEnd report Remove 14.2.7.1.1 Name Menu Tree: Main Set-Up / Testing / SAM Tester / Test Channels / [channel] / Name The test may be given a meaningful name that aids in its identification.
  • Page 102 METRODATA NetTESTER FAMILY USER MANUAL 14.2.7.1.3 Remove Menu Tree: Main Set-Up / Testing / SAM Tester / Test Channels / [channel] / Remove A test may be removed if not needed. 14.2.8 SAM Tester (Manual-Mode Tester Function) Menu Tree: Main Set-Up / Testing / SAM Tester The tester manual mode gives low-level access to the SAM functions.
  • Page 103 METRODATA NetTESTER FAMILY USER MANUAL FRAME CONTENT layer 3 remote mac 0a:01:01:64:00:00 local mac 00:c0:81:80:17:e6 flow s-vlan c-vlan None frAme size(s) Dscp peeR dest Ip 10.1.1.100 Udp port 14.2.8.1.2 Frame Rates Menu Tree: Main Set-Up / Testing / SAM Tester / Manual Setup / Frame Rates The frame rates menu contains all the setup items that affect exactly when frames are sent.

  • Page 104: Performance Monitoring

    METRODATA NetTESTER FAMILY USER MANUAL FIBRE PRBS State Disabled pattern PRBS7 pOlarity Inverted Results <display> 14.2.9.1 State Menu Tree: Main Set-Up / Testing / Fibre PRBS / State The PRBS test can be started or stopped from this item. 14.2.9.2 Pattern Only PRBS7 pattern is supported.
  • Page 105 METRODATA NetTESTER FAMILY USER MANUAL Performance-Monitoring Peers ---------------------------- Name St Type Interf Address Alarm ----------------------------------------------------------------------------- Customer 1 192.168.0.11 Customer 2 <Esc> - exit, 1.. - details, * - new, <Enter> - refresh To view or edit the settings of an existing session, press the key shown in the left- hand column.
  • Page 106 Menu Tree: Main Set-Up / Perf Monitoring / [peer] / TWAMP Setup The TWAMP setup menu allows various options for the TWAMP protocol to be specified. The default settings are should work correctly when a Metrodata unit is acting as the reflector. When interworking with other vendors' reflectors these parameters may need adjusting to be compatible.
  • Page 107 METRODATA NetTESTER FAMILY USER MANUAL TWAMP SETUP Dscp Message length pAdding Pseudo-Random transmit Rate receive timeOut 14.3.4.1 DSCP Menu Tree: Main Set-Up / Perf Monitoring / [peer] / TWAMP Setup / DSCP The DSCP parameter defines the priority to be used by the TWAMP messages.
  • Page 108 METRODATA NetTESTER FAMILY USER MANUAL The default setting is 3 seconds. 14.3.5 SLA Settings Menu Tree: Main Set-Up / Perf Monitoring / [peer] / SLA The SLA menu is as shown below: PM PEER #1 SLA 1 "Gold Service 1G"...
  • Page 109 METRODATA NetTESTER FAMILY USER MANUAL 24 hours Recommended setting for FLR, FTD and IFDV alarms. 30 days Recommended setting for Availability alarm. 14.3.5.2.3 Minimum Data Menu Tree: Main Set-Up / Perf Monitoring / [peer] / SLA / SLA Alarms / Availability / Min Data Minimum Data defines how much valid performance data must have been logged before the SLA alarm can be generated.

  • Page 110: Snmp Traps

    METRODATA NetTESTER FAMILY USER MANUAL MONITOR ALARM Window 1:00 <menu> <menu> Ifdv <menu> 14.3.6.1 Window Menu Tree: Main Set-Up / Perf Monitoring / [peer] / Monitor Alarm / Window The window configuration item defines the size of the monitoring window and can range from 1 minute to 15 minutes.
  • Page 111 METRODATA NetTESTER FAMILY USER MANUAL SNMP TRAPS Np alarm trap Disabled sLa alarm trap Disabled Monitor alarm trap Disabled Alarm summary trap Disabled Included here is the NP (No Peer) alarm that is generated by each session when the peer cannot be contacted.
  • Page 112 METRODATA NetTESTER FAMILY USER MANUAL TWAMP Performance Report ------------------------ Peer1 "Customer TWAMP" 192.168.0.11 Start: 1 Jan 00:30 2-way/ Logged time: 648s Outbound Inbound Alarms -------------------------------------- ------------- Sent Frames Received Frames Lost Frames Unavailable Availability 100% 99.99% Frame Loss Ratio 0.01% Min Delay 0.0087ms...
  • Page 113 METRODATA NetTESTER FAMILY USER MANUAL Average/Max Delay The variation is measured on the round-trip delay and Variation is compared frame by frame to the previous frame delay Good Delay Variations Alarms Shows the number of seconds during the report's logged time that the three possible alarms (No Peer, SLA and Monitor) were active.
  • Page 114 METRODATA NetTESTER FAMILY USER MANUAL Peer1 "Customer TWAMP" 1 of 7 | Time IFDVf IFDVb | Alarms(s): Start| (s) %Avail %FLR %Good %Good %Good | NP -----|-----------------------------------------|------------------ 1 00:30| 492 2 00:15| 900 3 00:00| 329 4 23:45| 0 5 23:30| 0...

  • Page 115: Store Settings

    METRODATA NetTESTER FAMILY USER MANUAL 14.3.9 Remove Peer Menu Tree: Main Set-Up / Perf Monitoring / [peer] / Remove Peer The remove option will remove the PM session and free the resources to be reused again. 14.3.10 Duplicate Peer Menu Tree: Main Set-Up / Perf Monitoring / [peer] / DUplicate Peer...

  • Page 116: Maintenance

    METRODATA NetTESTER FAMILY USER MANUAL See section 11 for more about OTDR testing. 14.5 Maintenance Menu Tree: Main Set-Up / MAintenance The Maintenance menu is shown below: MAINTENANCE Restart unit restore Defaults Settings file <menu> softWare file <menu> 14.5.1 Restart Unit...

  • Page 117: Config File

    METRODATA NetTESTER FAMILY USER MANUAL CONFIG FILE File name demo.cfg get file from: Tftp server cOnsole Current settings send file to: tftp Server coNsole <display> cUrrent settings 14.5.3.1 File Name Menu Tree: Main Set-Up / MAintenance / Config File / File Name The name of the configuration file held on the unit is displayed, and can be changed if desired.
  • Page 118 If the captured file is to be loaded into a unit, care should be taken that no extraneous text or control characters have been included. The first line of the file should always be: # Metrodata DSU Configuration Dump # and the final line will include an '=', for example: snmp.91.i=MEP16 14.5.3.8...
  • Page 119 METRODATA NetTESTER FAMILY USER MANUAL 14.5.3.9 Send file to current settings Menu Tree: Main Set-Up / MAintenance / Config File / Send file to: CUrrent settings The file can be used to set the current configuration of the unit. Note that the content of the file replaces the running configuration of the unit, not the saved settings.
  • Page 120 METRODATA NetTESTER FAMILY USER MANUAL 14.5.4.5 Get file from TFTP server Menu Tree: Main Set-Up / MAintenance / SoftWare File / Get file from: TFTP server The TFTP server details must be set (see section 14.1.9.7), client mode selected, and the server accessible before a file can be transferred to the unit.
  • Page 121 METRODATA NetTESTER FAMILY USER MANUAL The Unit Description will contain the name of the corresponding EDD product (see APPENDIX E) rather than that of the NetTESTER. 14.5.4.8 Delete file Menu Tree: Main Set-Up / MAintenance / SoftWare File / Delete file During a normal software upgrade cycle, the unit will be restarted, and this will automatically delete the temporary software file.
  • Page 122 METRODATA NetTESTER FAMILY USER MANUAL 15 REFERENCES [1] Metrodata Ltd, EDD Family User Manual, 76-02-108 rev A. [2] IEEE, “802.1Q-2018, Standard for Local and Metropolitan Area Network-- Bridges and Bridged Networks,” July 2018. [Online]. Available: https://ieeexplore.ieee.org/document/8403927. [3] J Postel and J K Reynolds, “STD 8, Telnet Protocol & Options,” May 1983.
  • Page 123 METRODATA NetTESTER FAMILY USER MANUAL [13] Metro Ethernet Forum, “MEF10.2, Ethernet services Attributes Phase 2,” October 2009. [Online]. Available: https://wiki.mef.net/display/CESG/MEF+10.2+-+Services+Attributes. 76-02-107 Rev.A Page 123 of 133...
  • Page 124 METRODATA NetTESTER FAMILY USER MANUAL APPENDIX A TWAMP TECHNOLOGY PRIMER TWAMP, Two Way Active Measurement Protocol is mechanism for measuring the performance of a network. TWAMP uses peer to peer IP/UDP PDU’s along with hardware-based timestamping allowing accurate measurement of network latency and jitter.
  • Page 125 METRODATA NetTESTER FAMILY USER MANUAL By now excluding the processing time, the actual network latency can be calculated T_latency = T_rtt – T_soft And assuming a symmetric network with equal latency in both directions, the one way delay may be approximated as...
  • Page 126 METRODATA NetTESTER FAMILY USER MANUAL TWAMP OPERATION The diagram below shows a network configuration with a single generator using TWAMP to monitor the connection to three remote peer devices. In this application, the TWAMP Generator will send a test PDU to each remote peer at a rate of 1 packet per second to measure the round-trip latency, one-way jitter and the synthetic packet loss associated with the route to the peer.
  • Page 127 METRODATA NetTESTER FAMILY USER MANUAL The one issue with SLA monitoring is that SLA’s are typically defined over a long time period, for example 24 hours or 30 days. As an example, the latency may be defined as 95% of all frames must be within 100mS over 24 hours, which means that there could be 4320 latency violations before the SLA would be breached.
  • Page 128 IEEE 802.1Q IEEE8021-CFM-V2-MIB MEF-SOAM-FM-MIB MEF 31 MEF-SOAM-PM-MIB MEF 36.1 METROHDR-MIB File: metrohdr.mib Definition of Metrodata enterprises area and higher-level areas within. METROSYSOID-MIB File: metrosysoid.mib Definitions of sysObjectID values for the Metrodata products. METROIF-MIB File: metroif.mib Augmentation to ifTable, providing additional interface stats.
  • Page 129 METRODATA NetTESTER FAMILY USER MANUAL APPENDIX C EXAMPLE TEST REPORT *************************************************** configurable header Metrodata Service Configuration Test Test Method: Y.1564 Customer: CustomerA Link: London-NewYork Tester: A.N.Engineer *************************************************** general information Unit node name "VF_10G05_multichan" Run id Start time 00:06:43 Sat 1/1/2020 Test channel 3 "T3_Y1564"...
  • Page 130 METRODATA NetTESTER FAMILY USER MANUAL ------------ Frame-Loss: FTD (Latency): FDV (Jitter): (Mbps) Count Ratio(%) Ave(ms) Good(%) Ave(ms) Good(%) result ------------------------------------------------------------------- 9.000 0.000 910us 100.000 107us 89.998 pass Detailed report additional result details --------------- Channel/SLA Test Results -------------------------------- ------------------------------ Channel Tx Frames...
  • Page 131 METRODATA NetTESTER FAMILY USER MANUAL APPENDIX D MULTI-LEVEL LOGIN A 'Multi-Level Login' system is available that expands on the basic password system. This allows for 6 users, arranged hierachically, with the privileges of each user being a superset of the one below. Level 0 (the lowest privilege level) is equivalent to the basic system 'View' user, and Level 6 to the Admin user.
  • Page 132 METRODATA NetTESTER FAMILY USER MANUAL APPENDIX E ADVANCED-MODE NETTESTER VS EDD The Advanced Mode user interface makes the NetTESTER look much like the corresponding EDD device (see below). NetTESTER NT1003 FCM9003 NT1005 FCM9005 NT10G05 FCM10G05 Note, however, that advanced mode is intended to allow occasional access to advanced functions, and it is not intended to be used as the normal method of accessing the unit.
  • Page 133 METRODATA NetTESTER FAMILY USER MANUAL 76-02-107 Rev.A Page 133 of 133...
