- Page 1 Self-regulating trace heating systems Design Guide Self-regulating trace heating systems for roof and gutter de-icing systems in ordinary environments with BARTEC BACAB FT “black” trace heaters...
-
Page 3: Table Of Contents
Table of contents Overview Technical data Certifications / Approvals Safety Personnel requirements System design Power connection components Trace heater splice / junction components End termination Accessories Trace heater installation Preparation Determination of the trace heater length Maximum heating circuit length Required tools / equipment Unrolling the trace heater Trace heater fixation on gutters... -
Page 4: Overview
BARTEC BACAB FT “black”; Typen FT115-1410P (120 V) und FT215-1410P (240 V) Self-regulating trace heater BARTEC BACAB FT “black” trace heater for roof and gutter de-icing Safety For safe installation and operation of BARTEC Self-regulating trace heating systems the technical requirements and instructions given in this manual must be followed. -
Page 5: System Design
TWISTO-N/B splice kit roof clip silicone end seal The following pages list all compatible components for BARTEC Self-regulating trace heating systems for roof and gutter applications. The respective installation instructions are included in the scope of delivery. 05-6066-7D0001/A Notice Technical data subject to change without notice. -
Page 6: Power Connection Components
Self-regulating trace heating systems Design Guide Power connection components The following components can be used for power connection with BARTEC Self-regulating trace heating systems for roof and gutter applications. 1/2" NPT cable gland kit for use with a 3 Catalog No.:... -
Page 7: Trace Heater Splice / Junction Components
Trace heater splice / junction components The following components can be used for trace heater splices / junctions with BARTEC Self-regulating trace heating systems in ordinary environments. TSK-F-A Heat shrink splice kit Catalog No.: TSK-F-A For direct connection of 2 trace heaters. The connection is established using splice lugs and sealed with heat shrink tubes.. -
Page 8: Accessories
The following original BARTEC accessories are available for the BARTEC Self-regulating trace heating systems for roof and gutter applications. NOTICE To ensure compliance with the existing technical regulations, use only original accessories from BARTEC. The use of original accessories from BARTEC is a precondition for the consideration of any warranty claims. -
Page 9: Trace Heater Installation
Trace heater installation Preparation Before installing any electric trace heating, the person installing must check if the trace heating has been designed and planned correctly. It is particu- larly essential to verify the following points: complete project planning documentation, operating instructions and installation instructions. ... - Page 10 Self-regulating trace heating systems Design Guide Step 2: Determine the required trace heater length for valleys. Snow and ice often accumulate in valleys. The trace heater should be routed up and down the valley to maintain a clear path of melted snow. Add approximately 6 ft.
- Page 11 Step 4: Determine the required trace heater length for downspouts. To allow melted snow and ice to be evacuated, the trace heater must be routed through downspouts (down and up). NOTICE If the downspout length exceeds 98 ft. (30 m) you must use a strain relief to prevent damage to the trace heater.
-
Page 12: Maximum Heating Circuit Length
Maximum heating circuit length The following table shows the maximum circuit lengths in ft (m) for BARTEC BACAB FT “black” trace heaters for different installation locations with standard circuit breaker amperages. Breaker sizing should be based on the National Electrical Code, Canadian Electrical Code or any other local or applicable code. -
Page 13: Required Tools / Equipment
Required tools / equipment Trace heater fixation on gutters The following tools are required for installation of the BARTEC Self- CAUTION regulating trace heating systems for roof and gutter applications: Risk of cutting on sharp edges. Wear safety gloves when bending ... -
Page 14: Installation Of Edge Protection
Self-regulating trace heating systems Design Guide Installation of edge protection Feed a UV-resistant cable tie through the mounting sheet. If necessary, use a hammer to fit the mounting sheet until it firmly CAUTION clamps into the gutter. Attach the trace heater using a UV-resistant cable tie. Risk of cutting on sharp edges. -
Page 15: Trace Heater Fixation On Roofs
Trace heater fixation on roofs Install the mounting sheet on the edge of the downspout to provide mechanical protection and support. Attach the clip to the roof as follows: Attach the trace heater using the cable ties. For wooden roof laths use nails or screws: NOTICE The bending radius of the trace heater must be at least... -
Page 16: Placement Of Connection / Splice Kits
Self-regulating trace heating systems Design Guide Standard sloped roofs Standing seam roofs On standard sloped roofs, locate the trace heater in a triangle pattern On sloped roofs with standing seams, run the trace heater along the according to the following table: seams according to the following table: Roof overhang Loop height... -
Page 17: Tests And Commissioning
The acceptance test reports for each heating circuit are complete and the trace heating system has been accepted. All components of the heating circuit are completely installed and are in working order. It has been ensured that the heating circuit is operated in conformance with the technical data specified by BARTEC. 05-6066-7D0001/A Notice Technical data subject to change without notice. -
Page 18: Operation
During operation of the electric trace heating system you must ensure that all components of the system are operated within the operating data speci- fied by BARTEC. This applies particularly to observation of the maximum temperature. Operation within these operating data is a precondition for possible later warran- ty claims. -
Page 19: Troubleshooting
Troubleshooting Problem Possible cause Remedy Trace heater remains cold No power supply Check the supply line Trace heater or cold lead cable not properly Connect the trace heater and cold lead cable connected according to the installation instructions Control unit adjusted incorrectly Adjust the control unit according to the installa- tion instructions Automatic circuit breaker disengages... -
Page 20: Acceptance Report
Self-regulating trace heating systems Design Guide Acceptance report Protocol type Acceptance test of the heating system Inspection before commissioning Maintenance and re-commissioning Project information Project Customer Heating circuit type Frost protection on pipes Roof and gutter de-icing Temperature maintenance Visual inspection Trace heaters Connection components Control units... -
Page 21: Limited Product Warranty
Limited product warranty Scope The term of this limited product warranty begins on the date of purchase and continues for a period of 2 years. It applies for all BARTEC products and accessories that are subject of this manual, against: ... - Page 22 Self-regulating trace heating systems Design Guide 05-6066-7D0001/A Notice Technical data subject to change without notice. Page 20 / 20 05/2021-EHT-405838 No claims for damage arising from alternations, errors or misprints shall be allowed.
- Page 24 BARTEC US Phone: +1 281 214-8542 BARTEC GmbH Phone: +49 7931 597-0 650 Century Plaza Drive, Suite D120 Fax: +1 281 214-8547 Max-Eyth-Straße 16 Fax: +49 7931 597-499 Houston, Texas 77073 sales@bartec.us 97980 Bad Mergentheim info@bartec.com www.bartec.us Germany www.bartec.com...
