Summary of Contents for Gill MetConnect THP

  • Page 2: Table Of Contents

    Welcome ..........................5 1.1. Overview of Content........................5 1.2. Description of Icons ........................5 1.3. General Notes ..........................6 1.4. User Manual Revision History ....................... 6 Product Overview ........................ 7 2.1. MetConnect Product Range ......................7 2.2. MetConnect Specification ......................8 2.3.
  • Page 3 Earthing............................21 6.2.9. Additional Sensors ........................21 6.3. Calibration ........................... 21 6.3.1. Pressure Sensor ........................... 21 6.3.2. Other Gill Instruments Sensors....................21 6.3.3. Additional Sensors ........................21 6.4. Fault Finding ..........................22 6.5. Safe Mode ............................ 23 6.6. Product Repair ..........................23 6.6.1.
  • Page 4 Appendix A - Technical Specification ..................24 Appendix B - MetConnect Connector Pin Allocation ..............27 ........28 ................32 ..................33 ....................34 ............... 39 ..............41 ............... 44 ..............46 .................. 51 .................... 52 ................55 ............ 57...

  • Page 5: Welcome

    1. Welcome Welcome to the MetConnect user manual.      ...

  • Page 6: General Notes

    Document Version Release Date Key Changes 0.82 25 Nov 2021 “Final” draft for Review 15 Dec 2021 First Release...

  • Page 7: Product Overview

    2. Product Overview       MetConnect MetConnect Temperature Humidity Pressure Wind speed and direction S (integrated) Analogue Sensor Input 1 Analogue Sensor Input 2 Rain S = Sensor supplied as part of MetConnect model C = Connector available for user supplied sensor...

  • Page 8: Metconnect Specification

      ...

  • Page 9: Metconnect Accessories

    Accessory Gill Instruments Part Number Connector, M12, 8 way, field wireable 1733-PK-002 Cable, for power and communications, 2m 1733-PK-012 with M12, 8 way over moulded connector Cable, for power and communications, 10m 1733-PK-013 with M12, 8 way over moulded connector...

  • Page 10: Set-Up Metconnect

    3. Set-up MetConnect          ...

  • Page 12: Connect Metconnect To Metset

                       ...

  • Page 13: Install Metconnect

    4. Install MetConnect           ...

  • Page 14: Emc Interference

                 Cable Feature Recommendation Wire Size 24 AWG Strand Size 7 x 32 AWG Pairing Twisted pair with drain wire Screening Screened with aluminium tape Outer Diameter 6-8mm RS232 3 pairs, max.

  • Page 15: Connector Pin Allocation

      Wire RS-232 RS-422 RS-485 SDI-12 Colour White Power Ground Power Ground Power Ground Power Ground Brown Green Yellow Grey Pink Power (V+) Power (V+) Power (V+) Power (V+) Blue Signal Ground Signal Ground Signal Ground Signal Ground SDI-12 Signal Power...

  • Page 16: Earthing

    Earthing Earth Point...

  • Page 17: Install The Metconnect

         NORTH MARKER ARROWS  MOUNTING BRACKET PLATES...

  • Page 18: Install Metconnect To A Panel Or Wall

      ...
  • Page 19 5. Use MetConnect      ...
  • Page 20 6. Maintain MetConnect     ...
  • Page 22                     ...
  • Page 23        ...
  • Page 24 Appendix A - Technical Specification Values are dependent on anemometer being used                      ...
  • Page 25 ...
  • Page 26    ...
  • Page 27 Appendix B - MetConnect Connector Pin Allocation Cable Analog 1/Rain Analog 2/Rain PRT/Rain Power Ground/ Power Ground/ White Power Ground Analogue Ground Analogue Ground Brown PRT +ve Green Current Measure Current Measure PRT –ve sense Yellow PRT –ve Grey Voltage Measure Voltage Measure PRT +ve sense Pink...
  • Page 34 About MetSet...
  • Page 35   ...
  • Page 36 To change the set-up for To change the set-up for To change the set-up for...
  • Page 37 Using MetSet to change the output rate and output data To change the M    To change the Measurement Output Data   ...
  • Page 38 Using MetSet to control sensors, change units and set the scale of additional inputs To control sensors and change measurement units To set-up MetConnect standard sensors   To set up the measurement units and scale of additional sensors...
  • Page 39 MetConnect ASCII Q,249,000.01,1017.3,049.2,+021.4,+010.3,+040.45,+000.06,+000.04,0000.000,+11.6,00,7C...
  • Page 40 data or data order...
  • Page 41 MetConnect MODBUS specification...
  • Page 42 To change the output format to MODBUS...
  • Page 43 To change the use of the MODBUS registers...
  • Page 44 MetConnect NMEA0183   ...
  • Page 46 Using MetConnect to set up SDI-12 output SDI-12 Units of Measure...
