Daktronics DM-100 Gen III Quick Manual

Configuring the DM-100 Gen III
for Sapphire Interface Quick Guide
Handheld Controller Use and Setup
The first time you use your DM-100 handheld controller you may need to set the function to GAS PRICE
as described below.
LCD Screen
CURRENT FUNCTION
GAS PRICE
CHANGE FUNCTION?
PRESS SET FUNCT
SELECT FUNCTION
GAS PRICE {}
Menu Navigation
1. Press the MENU key.
2. Press the Up and Down Arrow keys to select between
available menu options.
3. Press ENTER to select the desired menu option.
4. Press the MENU key to exit.
Diagnostics Menu
Press the MENU key followed by ENTER to select the Diagnostics Menu.
Display Status
1. Press the MENU key followed by ENTER to select the Diagnostics Menu.
2. Press ENTER to open the Display Status menu item.
LCD Screen
DISPLAY STATUS
GET STATUS
SELECT NETWORK
1
SELECT DISPLAY
SIGN 1 LINE 1 }
DD2294807
Rev 04
14 September 2022
Action/Information Shown
For indoor installation only: Plug the wall pack transformer into a 120 VAC power
outlet, and connect it to the DM-100.
This display appears briefly.
If GAS PRICE is shown on the bottom line of the LCD during startup, do nothing. The
controller automatically defaults to previous Gas Price settings.
If a function other than GAS PRICE is shown on the bottom line of the LCD during
startup, press the SET FUNCTION key while the second LCD prompt is displayed.
Press the Up and Down Arrow keys until the gas price option is shown.
Press the ENTER key to accept.
Action/Information Shown
Press ENTER to get display status.
Press the Up Arrow key to select another network, if applicable.
Press the Down Arrow key to move to another sign and line number.
Press ENTER to view Display Status menu items:
{}
• Driver Firmware Version
• Dim Level
• Dimming Mode (Automatic or Manual)
• Light Sensor Status
• Com1 Device Detection (Wired or Radio)
201 Daktronics Drive
Brookings, SD 57006-5128
www.daktronics.com/support
800.325.8766
Page 1 of 8
Menu Items
Diagnostics Menu Display Menu
Display Status Price Options
Detect Displays Configuration
Test Patterns POS Settings
COM Diagnostics POS Price Offset
About Modem
DIAGNOSTICS MENU
ENT TO BEGIN
DISPLAY STATUS
ENT TO SELECT
