- Page 1 MODCO 14 - 10X10...
- Page 2 MODCO 14 - 10X10 - Use PARTS LIST to reference parts. Repeat twice for two walls. REF (E) MOD-CLA-CON REF (AJ) / (B) MOD-180D-CON / MOD-PC PARTS LIST (TOWER) PART NO. DESCRIPTION MOD-FRM-992x2418 Straight Frame, Corner Screw Connect 992mm x 2418mm...
- Page 3 MODCO 14 - 10X10 - Connect each horizontal frame to the main backwall. REF (C) / (B) MOD-90D-CON + MOD-PC REF (D) / (B) MOD-SM90D-CON / MOD-PC...
- Page 4 MODCO 14 - 10X10 - Insert clip connector into holes (exposed side). Attach cover pro le to each exposed side (3 sides total). Cover pro le locks into clip connectors. REF (AF) / (AC) MOD-CC / MOD-CP-3100 COVER PROFILES & ACCESSORIES PART NO.
- Page 5 GRAPHIC INSTALL...
