CommScope TC-96309-IP Quick Start

TC-96309-IP · Rev A · May 2021
Installing SC Converter
on Prodigy™ Connector
Locate SC converter and note the alignment key on the
1
prodigy connector core and the alignment guide on the
SC converter, which are used to guide the Prodigy
connector core into the SC comverter.
ALIGNMENT
KEY
SC
CONVERTER
NOTE:
Work on a clean
surface, taking
care to avoid
dust contamination
of mating
surfaces.
b 3
Electronic Only Document (EOD)
Quick
REAR
OPENING
OF
CONVERTER
a
3
c
3
LOCKING
NUT
FULLY
ASSEMBED
CommScope (logo), CommScope, and Prodigy are trademarks.
Install SC converter: (a) align alignment key on the
2 Prodigy connector core with the alignment guide in the
converter body (see detail), (b) insert connector core all
Start
the way in until it clicks into position as shown in (c).
ALIGNMENT
KEY
a
3
PRODIGY
CONNECTOR
CORE
© 2021, CommScope, Inc. All Rights Reserved.
ALIGNMENT
ALIGNMENT
DETAIL GUIDE
3 b
NOTE:
Hold converter body stationary while
inserting connector core into rear
opening of converter, as indicated
in (a). Align Prodigy connector using
alignment key and alignment guide
as shown in Alignment Detail above.
Prior to installing Prodigy connector
3
into adapter, remove
ferrule dust cap,
shown below.
FERRULE
DUST CAP
CONVERTER
BODY
LOCKING
NUT
PRODIGY
CONNECTOR
27424-A
Page 1 of 2
